- Net volume
- 110L
- Tuning
- 40Hz
Eighteen Sound gives the volume and tuning; the port is sized for the driver when you open it.
15-inch LF driver · 500 W
Eighteen Sound 15ND930 16Ω
40–4100 Hz
£266.78
SteadyLean Audio · In stock · All 3 offers
- Fs
- 38Hz
- Xmax
- 7.5mm
- SPL
- 96dB
- Pe
- 500W
- BL
- 24.2T·m
- Vd
- 638cm³
- Qts
- 0.39
- Vas
- 195L
Published graphs
Eighteen Sound 15ND930 is a 15-inch 16 ohm LF driver rated at 500 W RMS. The validated T/S data includes Fs 38 Hz, Qts 0.39, Vas 195 L, Xmax 7.5 mm, sensitivity 96.3 dB, plus 638 cm³ Vd and 95 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £266.78.
The published T/S values agree with each other
Thiele/Small
- Fs
- 38Hz
- Qts
- 0.39
- Qes
- 0.40
- Qms
- 9.5
- Vas
- 195L
- Re
- 10.9Ω
- Le
- 2.50mH
Motor and cone
- BL
- 24.2T·m
- Sd
- 850cm²
- Mms
- 92g
- Xmax
- 7.5mm
- Vd †
- 638cm³
Power and response
- Sensitivity †
- 96.3dB
- Manufacturer sensitivity
- 97dB
- Power
- 500W
- Nominal power
- 500W
- Impedance
- 16Ω
- Range
- 40–4100Hz
- EBP †
- 95 · Sealed or vented
Size and mounting
- Diameter
- 387mm
- Cutout
- 353mm
- Bolt circle
- 370mm
- Depth
- 177mm
- Weight
- 4kg
Other published values
- Power Program
- 800
† Calculated by bits from the published values
What this validation status means
Everything else Eighteen Sound lists
LF · Primary · 15″
- BL
- 24.2T·m
- Fs
- 38Hz
- Le
- 2.50mH
- Re
- 10.9Ω
- Sd
- 850cm²
- Mms
- 92g
- Qes
- 0.40
- Qms
- 9.5
- Qts
- 0.39
- SPL
- 96.3dB
- Vas
- 195L
- Xmax
- 7.5mm
- Power
- 500W
- Impedance
- 16Ω
- Sensitivity
- 97dB
- Low limit
- 40Hz
- Nominal power
- 500W
- Power Program
- 800
- Calculated sensitivity †
- 96.3dB
- High limit
- 4100Hz
- Manufacturer sensitivity
- 97dB
- Weight
- 4kg
- Diameter
- 387mm
- Depth
- 177mm
- Cutout
- 353mm
- Bolt circle
- 370mm
02
Designs
What Eighteen Sound suggests for the 15ND930. No published designs name it yet.
How we find designsEighteen Sound’s suggested box
From Eighteen Sound’s 15ND930 page
Open this box in 00 Simulator
Modelling the box in 00 Simulator…
03
Compare
Same-size drivers, compared with the 15ND930. Clear differences are green when better and red when worse.
This driver15ND930
Best price
£266.78
Fs
38 Hz
Qts
0.39
Vas
195 L
BL
24.2 T·m
Xmax
7.5 mm
Sensitivity
96.3 dB
Power
500 W
GRS15PT-8
£52.90 · 80% less, betterFs28 Hz −26%, better
Qts0.41 +5%
Vas242.1 L +24%, worse
BL20.2 T·m −17%, worse
Xmax7.8 mm +4%
Sensitivity92.9 dB −3.4, worse
SB AudienceBIANCO-15MW500
£110.00 · 59% less, betterFs39 Hz –
Qts0.40 –
Vas171 L −12%, better
BL18.8 T·m −22%, worse
Xmax7.6 mm –
Sensitivity96 dB –
PRV Audio15W1600
£134.07 · 50% less, betterFs54 Hz +41%, worse
Qts0.42 +8%
Vas91.2 L −53%, better
BL24.1 T·m –
Xmax7 mm −7%
Sensitivity97.1 dB +0.8
CIAREPWA15.75
£146.26 · 45% less, betterFs44 Hz +16%, worse
Qts0.39 –
Vas135 L −31%, better
BL19.3 T·m −20%, worse
Xmax7 mm −7%
Sensitivity96.5 dB –
£152.00 · 43% less, better
Fs40 Hz +5%
Qts0.37 −5%
Vas188 L −4%
BL19.7 T·m −19%, worse
Xmax6.9 mm −8%
Sensitivity97 dB +0.7
REDCATT15FIND
£167.07 · 37% less, betterFs42 Hz +11%, worse
Qts0.36 −8%
Vas96.4 L −51%, better
BL24.6 T·m –
Xmax6.8 mm −10%, worse
Sensitivity94.9 dB −1.4
RCFL15P540
£173.78 · 35% less, betterFs50 Hz +32%, worse
Qts0.39 –
Vas100 L −49%, better
BL21.4 T·m −12%, worse
Xmax7 mm −7%
Sensitivity96.9 dB +0.6
CIAREPW396
£186.38 · 30% less, betterFs43 Hz +13%, worse
Qts0.41 +5%
Vas129 L −34%, better
BL20.5 T·m −15%, worse
Xmax6.5 mm −13%, worse
Sensitivity96 dB –
BMS15S330
£194.97 · 27% less, betterFs39 Hz –
Qts0.32 −18%, better
Vas152 L −22%, better
BL23 T·m −5%
Xmax8 mm +7%
Sensitivity96.3 dB –
Beyma15MCB700
£207.45 · 22% less, betterFs44 Hz +16%, worse
Qts0.34 −13%, better
Vas148 L −24%, better
BL20 T·m −17%, worse
Xmax7 mm −7%
Sensitivity97.5 dB +1.2
BMS15N630
£225.93 · 15% less, betterFs39 Hz –
Qts0.42 +8%
Vas152 L −22%, better
BL19.8 T·m −18%, worse
Xmax8 mm +7%
Sensitivity95 dB −1.3
Eighteen Sound15NW530
£243.16 · 9% less, betterFs43 Hz +13%, worse
Qts0.33 −15%, better
Vas154 L −21%, better
BL22 T·m −9%
Xmax7.5 mm –
Sensitivity97.5 dB +1.2
Sica15 PFS 4
£266.61 · Same priceFs39 Hz –
Qts0.34 −13%, better
Vas103.9 L −47%, better
BL24.2 T·m –
Xmax8 mm +7%
Sensitivity94.2 dB −2.1, worse
Eighteen Sound15NTLW3500
£319.26 · 20% more, worseFs45 Hz +18%, worse
Qts0.39 –
Vas131 L −33%, better
BL19.5 T·m −19%, worse
Xmax8.3 mm +11%, better
Sensitivity96.8 dB +0.5
Beyma15CXA400ND
£401.13 · 50% more, worseFs40 Hz +5%
Qts0.36 −8%
Vas196 L –
BL19 T·m −21%, worse
Xmax6 mm −20%, worse
Sensitivity97.1 dB +0.8
Eighteen Sound15W750
No current priceFs40 Hz +5%
Qts0.42 +8%
Vas182 L −7%
BL23.5 T·m –
Xmax8 mm +7%
Sensitivity96.3 dB –
P.Audio15FT-100SW
No current priceFs42 Hz +11%, worse
Qts0.40 –
Vas90 L −54%, better
BL23.5 T·m –
Xmax7.5 mm –
Sensitivity94 dB −2.3, worse
EminenceCANNABASS CB3015N-8
No current priceFs41 Hz +7%
Qts0.39 –
Vas162.9 L −16%, better
BL17.8 T·m −27%, worse
Xmax7.2 mm −4%
Sensitivity96.1 dB –
RCFM15P550
No current priceFs45 Hz +18%, worse
Qts0.37 −5%
Vas140 L −28%, better
BL19.8 T·m −18%, worse
Xmax7 mm −7%
Sensitivity97 dB +0.7
Sica15 S 3 PL
No current priceFs33 Hz −13%, better
Qts0.38 –
Vas230 L +18%, worse
BL17.1 T·m −29%, worse
Xmax8 mm +7%
Sensitivity95.3 dB −1
CelestionFTR15-3070E
No current priceFs46 Hz +21%, worse
Qts0.38 –
Vas145.8 L −25%, better
BL17.9 T·m −26%, worse
Xmax7.8 mm +3%
Sensitivity97.2 dB +0.9
FaneCOLOSSUS 15XB
No current priceFs38 Hz –
Qts0.32 −18%, better
Vas168 L −14%, better
BL22.1 T·m −9%
Xmax7.5 mm –
Sensitivity96.4 dB –
B&C15RBX100
No current priceFs44 Hz +16%, worse
Qts0.38 –
Vas100 L −49%, better
BL24 T·m –
Xmax9 mm +20%, better
Sensitivity95.3 dB −1
Precision DevicesPD.154NR1
No current priceFs46 Hz +21%, worse
Qts0.40 –
Vas158 L −19%, better
BL18.5 T·m −24%, worse
Xmax8.5 mm +13%, better
Sensitivity97.6 dB +1.3
Oberton15NCX
No current priceFs44 Hz +15%, worse
Qts0.36 −8%
Vas138.4 L −29%, better
BL18.6 T·m −23%, worse
Xmax7.8 mm +3%
Sensitivity96.9 dB +0.6
Oberton15CX
No current priceFs38 Hz –
Qts0.35 −11%, better
Vas163.8 L −16%, better
BL18.4 T·m −24%, worse
Xmax7 mm −7%
Sensitivity95.9 dB –
CelestionTSQ1535
No current priceFs50 Hz +32%, worse
Qts0.40 –
Vas94.0 L −52%, better
BL20.6 T·m −15%, worse
Xmax8 mm +7%
Sensitivity96.4 dB –
Eighteen Sound15ND940
No current priceFs41 Hz +8%
Qts0.36 −8%
Vas166 L −15%, better
BL26.6 T·m +10%
Xmax9.5 mm +27%, better
Sensitivity96.7 dB –
LavoceNBASS15-30
No current priceFs42 Hz +11%, worse
Qts0.36 −8%
Vas143.1 L −27%, better
BL19.2 T·m −21%, worse
Xmax6.6 mm −12%, worse
Sensitivity96.5 dB –
No current price
Fs37 Hz –
Qts0.39 –
Vas236 L +21%, worse
BL15.9 T·m −34%, worse
Xmax6.5 mm −13%, worse
Sensitivity96.6 dB –
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Lean Audio | £266.78, the lowest price | In stock | Visit shop at Lean Audio | |
Lean Business | £266.78 | Stock not listed | Visit shop at Lean Business |
Best price over time
Tracked since 1 Apr
