Fane COLOSSUS 15XB 8Ω
8 Ω · 40–1000 Hz
No current price
- Fs
- 38Hz
- Xmax
- 7.5mm
- SPL
- 96dB
- Pe
- 800W
- BL
- 22.1T·m
- Vd
- 641cm³
- Qts
- 0.32
- Vas
- 168L
Fane COLOSSUS 15XB is a 15-inch 8 ohm LF driver rated at 800 W RMS. The validated T/S data includes Fs 38 Hz, Qts 0.32, Vas 168 L, Xmax 7.5 mm, sensitivity 96.4 dB, plus 641 cm³ Vd and 113 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 38Hz
- Qts
- 0.32
- Qes
- 0.34
- Qms
- 7.5
- Vas
- 168L
- Re
- 6.2Ω
- Le
- 1.50mH
Motor and cone
- BL
- 22.1T·m
- Sd
- 855cm²
- Mms
- 108g
- Xmax
- 7.5mm
- Vd †
- 641cm³
Power and response
- Sensitivity †
- 96.4dB
- Manufacturer sensitivity
- 99dB
- Power
- 800W
- Impedance
- 8Ω
- Range
- 40–1000Hz
- EBP †
- 113 · Leans vented
Size and mounting
- Diameter
- 406.4mm
- Depth
- 181mm
- Weight
- 12.4kg
Other published values
- Cms
- 0.16mm/N
- Power Peak
- 3200
- Power Program
- 1600
Sensitivity shows 96.4 dB, calculated from the T/S values. Fane publishes 99.0 dB, 2.6 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Fane lists
LF · Primary · 15″
- BL
- 22.1T·m
- Fs
- 38Hz
- Le
- 1.50mH
- Re
- 6.2Ω
- Sd
- 855cm²
- Cms
- 0.16mm/N
- Mms
- 108g
- Qes
- 0.34
- Qms
- 7.5
- Qts
- 0.32
- SPL
- 96.4dB
- Vas
- 168L
- Xmax
- 7.5mm
- Power
- 800W
- Impedance
- 8Ω
- Power Peak
- 3200
- Sensitivity
- 99dB
- Low limit
- 40Hz
- Power Program
- 1600
- Calculated sensitivity †
- 96.4dB
- High limit
- 1000Hz
- Manufacturer sensitivity
- 99dB
- Weight
- 12.4kg
- Diameter
- 406.4mm
- Depth
- 181mm
