PRV Audio15W1600
£135.95 · 20% less, betterFs54 Hz +28%, worse
Qts0.42 +17%, worse
Vas91.2 L −5%
BL24.1 T·m –
Xmax7 mm +4%
Sensitivity97.1 dB +2.2, better
15-inch LF driver · 102 mm voice coil · 1,000 W
REDCATT 15FIND 8Ω
8 Ω
£170.67
Lautsprecherteile · 6 in stock · All 1 offer
- Fs
- 42Hz
- Xmax
- 6.8mm
- SPL
- 95dB
- Pe
- 1000W
- BL
- 24.6T·m
- Vd
- 595cm³
- Qts
- 0.36
- Vas
- 96L
REDCATT 15FIND is a 15-inch 8 ohm LF driver rated at 1000 W RMS. The validated T/S data includes Fs 42 Hz, Qts 0.36, Vas 96.4 L, Xmax 6.8 mm, sensitivity 94.9 dB, plus 595 cm³ Vd and 114 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £170.67.
The published T/S values agree with each other
Thiele/Small
- Fs
- 42Hz
- Qts
- 0.36
- Qes
- 0.37
- Qms
- 8.3
- Vas
- 96.4L
- Re
- 5.4Ω
- Le
- 1.18mH
Motor and cone
- BL
- 24.6T·m
- Sd
- 881cm²
- Mms
- 160g
- Xmax
- 6.8mm
- Vd †
- 595cm³
- Voice coil
- 102mm
Power and response
- Sensitivity †
- 94.9dB
- Manufacturer sensitivity
- 96.7dB
- Power
- 1000W
- Impedance
- 8Ω
- EBP †
- 114 · Leans vented
Size and mounting
- Diameter
- 392mm
- Cutout
- 360mm
- Bolt circle
- 373mm
- Weight
- 12kg
Other published values
- Xmech
- 18.75
- Power Peak
- 4000
Other dimensions
- Mounting Depth
- 150
Sensitivity shows 94.9 dB, calculated from the T/S values. REDCATT publishes 96.7 dB, 1.8 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 15″
- BL
- 24.6T·m
- Fs
- 42Hz
- Le
- 1.18mH
- Re
- 5.4Ω
- Sd
- 881cm²
- Mms
- 160g
- Qes
- 0.37
- Qms
- 8.3
- Qts
- 0.36
- SPL
- 94.9dB
- Vas
- 96.4L
- Xmax
- 6.8mm
- Xmech
- 18.75
- Power
- 1000W
- Impedance
- 8Ω
- Power Peak
- 4000
- Sensitivity
- 96.7dB
- Calculated sensitivity †
- 94.9dB
- Manufacturer sensitivity
- 96.7dB
- Voice coil
- 102mm
- Weight
- 12kg
- Diameter
- 392mm
- Mounting Depth
- 150
- Cutout
- 360mm
- Bolt circle
- 373mm
02
Compare
Same-size drivers, compared with the 15FIND. Clear differences are green when better and red when worse.
This driver15FIND
Best price
£170.67
Fs
42 Hz
Qts
0.36
Vas
96.4 L
BL
24.6 T·m
Xmax
6.8 mm
Sensitivity
94.9 dB
Power
1000 W
B&C15CL76
£138.54 · 19% less, betterFs42 Hz –
Qts0.33 −8%
Vas135 L +40%, worse
BL21 T·m −15%, worse
Xmax7 mm +4%
Sensitivity96.7 dB +1.8
£156.00 · 9% less, better
Fs40 Hz −5%
Qts0.37 –
Vas188 L +95%, worse
BL19.7 T·m −20%, worse
Xmax6.9 mm –
Sensitivity97 dB +2.1, better
FaitalPRO15HP1010
£161.93 · 5% less, betterFs40 Hz −5%
Qts0.37 –
Vas107.5 L +12%, worse
BL22 T·m −11%, worse
Xmax9.8 mm +44%, better
Sensitivity94.6 dB –
RCFL15P540
£173.78 · 2% moreFs50 Hz +19%, worse
Qts0.39 +8%
Vas100 L +4%
BL21.4 T·m −13%, worse
Xmax7 mm +4%
Sensitivity96.9 dB +2, better
SB AudienceROSSO-15MW500
£173.91 · 2% moreFs42 Hz –
Qts0.33 −8%
Vas121.3 L +26%, worse
BL23.2 T·m −6%
Xmax8.4 mm +24%, better
Sensitivity96.1 dB +1.2
Beyma15MCB700
£211.91 · 24% more, worseFs44 Hz +5%
Qts0.34 −6%
Vas148 L +54%, worse
BL20 T·m −19%, worse
Xmax7 mm +4%
Sensitivity97.5 dB +2.6, better
Beyma15LEX1000FE
£230.47 · 35% more, worseFs41 Hz –
Qts0.34 −6%
Vas116 L +20%, worse
BL23.2 T·m −6%
Xmax11 mm +63%, better
Sensitivity95.4 dB +0.5
Beyma15MC700ND
£231.21 · 35% more, worseFs49 Hz +17%, worse
Qts0.31 −14%, better
Vas105 L +9%
BL22.6 T·m −8%
Xmax7 mm +4%
Sensitivity97.6 dB +2.7, better
RCFMB15X351
£238.26 · 40% more, worseFs46 Hz +10%
Qts0.31 −14%, better
Vas114 L +18%, worse
BL22.8 T·m −7%
Xmax7 mm +4%
Sensitivity97.3 dB +2.4, better
EminenceLAB 15
£253.13 · 48% more, worseFs28 Hz −33%, better
Qts0.35 –
Vas103.6 L +7%
BL26.7 T·m +9%
Xmax11.8 mm +75%, better
Sensitivity89.9 dB −5, worse
FaitalPRO15HP1030
£268.93 · 58% more, worseFs40 Hz −5%
Qts0.34 −6%
Vas95 L –
BL24.3 T·m –
Xmax12.4 mm +84%, better
Sensitivity94.4 dB −0.5
Beyma15LEX1600FE
£281.52 · 65% more, worseFs38 Hz −10%
Qts0.33 −8%
Vas106 L +10%
BL25.8 T·m +5%
Xmax13 mm +93%, better
Sensitivity94.4 dB −0.5
Dayton AudioSS15-22
£375.61 · 120% more, worseFs27 Hz −36%, better
Qts0.38 +6%
Vas98 L –
BL24.9 T·m –
Xmax22 mm +226%, better
Sensitivity88.4 dB −6.5, worse
BMS15CN682
£384.52 · 125% more, worseFs41 Hz −3%
Qts0.36 –
Vas137 L +42%, worse
BL20.6 T·m −16%, worse
Xmax5.5 mm −19%, worse
Sensitivity95.9 dB +1
Beyma15LEX1600ND
£389.22 · 128% more, worseFs41 Hz –
Qts0.36 –
Vas91 L −6%
BL25.7 T·m +4%
Xmax14.5 mm +115%, better
Sensitivity94.2 dB −0.7
Eighteen Sound15NCX910
£497.18 · 191% more, worseFs55 Hz +31%, worse
Qts0.33 −8%
Vas107 L +11%, worse
BL21 T·m −15%, worse
Xmax7 mm +4%
Sensitivity99.2 dB +4.3, better
Dayton AudioPN395-8
No current priceFs44 Hz +5%
Qts0.35 –
Vas96.8 L –
BL25.3 T·m –
Xmax6.5 mm −4%
Sensitivity95.7 dB +0.8
Sica15 PFS 4
No current priceFs39 Hz −7%
Qts0.34 −6%
Vas103.9 L +8%
BL24.2 T·m –
Xmax8 mm +19%, better
Sensitivity94.2 dB −0.7
Oberton15MB35
No current priceFs48 Hz +14%, worse
Qts0.34 −7%
Vas115.1 L +19%, worse
BL20.1 T·m −18%, worse
Xmax6.8 mm –
Sensitivity97.6 dB +2.7, better
Eighteen Sound15NCX910BE
No current priceFs55 Hz +31%, worse
Qts0.33 −8%
Vas107 L +11%, worse
BL21 T·m −15%, worse
Xmax7 mm +4%
Sensitivity99.2 dB +4.3, better
Eighteen Sound15NCX910N
No current priceFs55 Hz +31%, worse
Qts0.33 −8%
Vas107 L +11%, worse
BL21 T·m −15%, worse
Xmax7 mm +4%
Sensitivity99.2 dB +4.3, better
P.AudioP150/2228
No current priceFs51 Hz +21%, worse
Qts0.35 –
Vas88.3 L −8%
BL23.9 T·m –
Xmax4.0 mm −41%, worse
Sensitivity97 dB +2.1, better
P.Audio15FT-100SW
No current priceFs42 Hz –
Qts0.40 +11%, worse
Vas90 L −7%
BL23.5 T·m −4%
Xmax7.5 mm +11%, better
Sensitivity94 dB −0.9
LavoceNBASS15-30
No current priceFs42 Hz –
Qts0.36 –
Vas143.1 L +48%, worse
BL19.2 T·m −22%, worse
Xmax6.6 mm –
Sensitivity96.5 dB +1.6
P.AudioP150/2227
No current priceFs45 Hz +7%
Qts0.34 −6%
Vas117.9 L +22%, worse
BL22.5 T·m −8%
Xmax5.5 mm −19%, worse
Sensitivity96.9 dB +2, better
PeerlessNCP-1540R01-08
No current priceFs54 Hz +29%, worse
Qts0.32 −11%, better
Vas86.5 L −10%, better
BL23.9 T·m –
Xmax8.2 mm +21%, better
Sensitivity98.2 dB +3.3, better
Sica15 PNS 4
No current priceFs37 Hz −11%, better
Qts0.35 –
Vas116.3 L +21%, worse
BL22.7 T·m −8%
Xmax9 mm +33%, better
Sensitivity94 dB −0.9
RCFM15P550
No current priceFs45 Hz +7%
Qts0.37 –
Vas140 L +45%, worse
BL19.8 T·m −20%, worse
Xmax7 mm +4%
Sensitivity97 dB +2.1, better
BMS15CN680
No current priceFs41 Hz −3%
Qts0.36 –
Vas137 L +42%, worse
BL20.6 T·m −16%, worse
Xmax5.5 mm −19%, worse
Sensitivity95.9 dB +1
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Lautsprecherteile | £170.67, the lowest price | 6 in stock | Visit shop at Lautsprecherteile |
Best price over time
Tracked since 1 Oct
