Overview
LF Driver
Sica
Sica 10 C 2 CP
Sica 10 C 2 CP is a 10" 8 ohm LF driver rated at 200W RMS. The validated T/S data includes Fs 50Hz, Qts 0.31, Vas 63.2L, Xmax 4mm, sensitivity 95.8dB, plus 139cm³ Vd and 152 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
10"
Impedance
8Ω
RMS Power
200W
Sensitivity
95.8dB
96.9dBmanufacturer; using T/S-derived value (1.1dB delta).
EBP
152
Vented alignment
Vd
139cm³
T/S Parameters
Valid
Fs50Hz
Qts0.31
Qes0.33
Qms4.7
Vas63.2L
Re6.2Ω
Le0.81mH
BL12.7Tm
Sd346cm²
Mms27g
Xmax4.0mm
SPL96dB
Power200W
Impedance8Ω
Voice Coil50mm
Flux Density1.08T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.5kg
Diameter268.0mm
Overall Depth111.5mm
Cutout Diameter232.0mm
Bolt Circle Diameter247.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Sica
10 C 2 CP
10"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
96%
Similarity
£115.00
Eminence
BASSLITE S2010
10"
Xmax4mm0%
Qts0.310%
BL11.9Tm-6%
Vas63.4L0%
Qes0.34+3%
77%
Similarity
Oberton
10NMB200
10"
Xmax4.3mm+6%
Qts0.32+2%
BL14.1Tm+11%
Vas34.9L-45%
Qes0.33-1%
77%
Similarity
PRV Audio
10MB500-4
10"
Xmax4.5mm+13%
Qts0.29-6%
BL12.3Tm-3%
Vas47.6L-25%
Qes0.3-9%
73%
Similarity
Monacor
SP-10A/302PA
10"
Xmax4mm0%
Qts0.3-3%
BL15.8Tm+25%
Vas40L-37%
Qes0.31-6%
73%
Similarity
£98.03
PRV Audio
10MB800FT
10"
Xmax3.5mm-12%
Qts0.32+3%
BL14.4Tm+13%
Vas36.7L-42%
Qes0.330%
71%
Similarity
Monacor
TF1020/8
10"
Xmax4mm0%
Qts0.32+4%
BL14.1Tm+11%
Vas28.8L-54%
Qes0.37+13%
71%
Similarity
£72.50
Celestion
TF1020
10"
Xmax4mm0%
Qts0.32+4%
BL14.1Tm+11%
Vas28.8L-55%
Qes0.37+13%
71%
Similarity
£108.78
FaitalPRO
10PR310
10"
Xmax4.9mm+23%
Qts0.310%
BL11.5Tm-9%
Vas40.3L-36%
Qes0.32-3%
70%
Similarity
Celestion
NTR10-2520D
10"
Xmax4mm0%
Qts0.29-7%
BL15.8Tm+25%
Vas34.7L-45%
Qes0.32-2%
69%
Similarity
Celestion
FTR10-2055D
10"
Xmax4mm0%
Qts0.34+11%
BL13.8Tm+9%
Vas36.9L-42%
Qes0.39+19%
69%
Similarity
£52.81
Dayton Audio
MB1025-8
10"
Xmax3mm-25%
Qts0.34+10%
BL13.2Tm+4%
Vas50.7L-20%
Qes0.36+9%
68%
Similarity
Fane
SOVEREIGN PRO 10-300SC
10"
Xmax4.8mm+19%
Qts0.33+6%
BL14.8Tm+17%
Vas45.4L-28%
Qes0.34+3%
