Overview
LF Driver
Sica
Sica 10 SR 2.5 CP
Sica 10 SR 2.5 CP is a 10" 8 ohm LF driver rated at 300W RMS. The validated T/S data includes Fs 35Hz, Qts 0.32, Vas 66.7L, Xmax 6mm, sensitivity 91.1dB, plus 212cm³ Vd and 101 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
10"
Impedance
8Ω
RMS Power
300W
Sensitivity
91.1dB
93.0dBmanufacturer; using T/S-derived value (1.9dB delta).
EBP
101
Vented alignment
Vd
212cm³
T/S Parameters
Valid
Fs35Hz
Qts0.32
Qes0.34
Qms6.3
Vas66.7L
Re5.2Ω
Le1.16mH
BL13.7Tm
Sd353cm²
Mms57g
Xmax6.0mm
SPL91dB
Power300W
Impedance8Ω
Voice Coil65mm
Flux Density1.05T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight5.0kg
Diameter270.0mm
Overall Depth122.0mm
Cutout Diameter232.0mm
Bolt Circle Diameter252.0mm
