Overview
LF Driver
Sica
Sica 10 FE 3 CP
Sica 10 FE 3 CP is a 10" 8 ohm LF driver rated at 450W RMS. The validated T/S data includes Fs 52Hz, Qts 0.31, Vas 38.6L, Xmax 5mm, sensitivity 94.3dB, plus 173cm³ Vd and 163 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
10"
Impedance
8Ω
RMS Power
450W
Sensitivity
94.3dB
95.9dBmanufacturer; using T/S-derived value (1.6dB delta).
EBP
163
Vented alignment
Vd
173cm³
T/S Parameters
Valid
Fs52Hz
Qts0.31
Qes0.32
Qms7.5
Vas38.6L
Re5.6Ω
Le0.67mH
BL15.3Tm
Sd346cm²
Mms41g
Xmax5.0mm
SPL94dB
Power450W
Impedance8Ω
Voice Coil75mm
Flux Density1.08T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight6.6kg
Diameter268.0mm
Overall Depth122.5mm
Cutout Diameter232.0mm
Bolt Circle Diameter247.0mm
