10-inch LF driver · MT series · 76 mm voice coil
PRV Audio MT10W1200-NDY-4 4Ω
4 Ω · 40–4000 Hz
No current price
- Fs
- 47Hz
- Xmax
- 6.5mm
- SPL
- 93dB
- Pe
- –
- BL
- 12.3T·m
- Vd
- 242cm³
- Qts
- 0.30
- Vas
- 41L
PRV Audio MT10W1200-NDY-4 is a 10-inch 4 ohm LF driver. The validated T/S data includes Fs 47 Hz, Qts 0.30, Vas 41.2 L, Xmax 6.5 mm, sensitivity 93.4 dB, plus 242 cm³ Vd and 151 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 47Hz
- Qts
- 0.30
- Qes
- 0.31
- Qms
- 7.9
- Vas
- 41.2L
- Re
- 3Ω
- Le
- 0.38mH
Motor and cone
- BL
- 12.3T·m
- Sd
- 373cm²
- Mms
- 54g
- Xmax
- 6.5mm
- Vd †
- 242cm³
- Voice coil
- 76mm
Power and response
- Sensitivity †
- 93.4dB
- Manufacturer sensitivity
- 97dB
- Impedance
- 4Ω
- Range
- 40–4000Hz
- Crossover
- 65Hz
- EBP †
- 151 · Leans vented
Size and mounting
- Diameter
- 261mm
- Cutout
- 230mm
- Depth
- 127mm
- Weight
- 3.8kg
Other published values
- Cms
- 0.21mm/N
Other dimensions
- Mounting Depth
- 114
Sensitivity shows 93.4 dB, calculated from the T/S values. PRV Audio publishes 97.0 dB, 3.6 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else PRV Audio lists
LF · Primary · 10″
- BL
- 12.3T·m
- Fs
- 47Hz
- Le
- 0.38mH
- Re
- 3Ω
- Sd
- 373cm²
- Cms
- 0.21mm/N
- Mms
- 54g
- Qes
- 0.31
- Qms
- 7.9
- Qts
- 0.30
- SPL
- 93.4dB
- Vas
- 41.2L
- Xmax
- 6.5mm
- Impedance
- 4Ω
- Sensitivity
- 97dB
- Low limit
- 40Hz
- Calculated sensitivity †
- 93.4dB
- High limit
- 4000Hz
- Manufacturer sensitivity
- 97dB
- Voice coil
- 76mm
- Crossover
- 65Hz
- Weight
- 3.8kg
- Diameter
- 261mm
- Depth
- 127mm
- Mounting Depth
- 114
- Cutout
- 230mm
02
Compare
Same-size drivers, compared with the MT10W1200-NDY-4. Clear differences are green when better and red when worse.
This driverMT10W1200-NDY-4
Best price
–
Fs
47 Hz
Qts
0.30
Vas
41.2 L
BL
12.3 T·m
Xmax
6.5 mm
Sensitivity
93.4 dB
Power
–
Beyma10WR300
£102.66Fs52 Hz +11%, worse
Qts0.35 +17%, worse
Vas42 L –
BL14.2 T·m +16%, better
Xmax6 mm −8%
Sensitivity93.8 dB –
Eighteen Sound10W500
£119.37Fs53 Hz +13%, worse
Qts0.29 −3%
Vas45.2 L +10%
BL14.6 T·m +19%, better
Xmax5.5 mm −15%, worse
Sensitivity95.4 dB +2, better
FaitalPRO10RS350
£119.58Fs40 Hz −15%, better
Qts0.31 +3%
Vas40.6 L –
BL12.5 T·m –
Xmax7.2 mm +10%, better
Sensitivity91 dB −2.4, worse
FaitalPRO10PR310
£120.85Fs55 Hz +17%, worse
Qts0.31 +3%
Vas40.3 L –
BL11.5 T·m −6%
Xmax4.9 mm −24%, worse
Sensitivity95.2 dB +1.8
CIAREPW257
£132.36Fs57 Hz +22%, worse
Qts0.30 –
Vas31 L −25%, better
BL15.9 T·m +29%, better
Xmax5.5 mm −15%, worse
Sensitivity94.4 dB +1
FaitalPRO10PR320
£135.67Fs48 Hz –
Qts0.29 −3%
Vas52.7 L +28%, worse
BL13.5 T·m +10%
Xmax7.4 mm +13%, better
Sensitivity94.8 dB +1.4
Beyma10G40
£137.27Fs45 Hz −4%
Qts0.30 –
Vas49 L +19%, worse
BL17 T·m +38%, better
Xmax7 mm +8%
Sensitivity93.5 dB –
B&C10PS26
£145.77Fs54 Hz +15%, worse
Qts0.29 −3%
Vas38 L −8%
BL14.1 T·m +15%, better
Xmax5.5 mm −15%, worse
Sensitivity94.6 dB +1.2
Eighteen Sound10NW650
£160.01Fs51 Hz +9%
Qts0.28 −7%
Vas48 L +16%, worse
BL14 T·m +14%, better
Xmax7 mm +8%
Sensitivity95.4 dB +2, better
Sica10 S 3 CP
£166.71Fs42 Hz −10%, better
Qts0.30 –
Vas42.8 L +4%
BL15.6 T·m +27%, better
Xmax7 mm +8%
Sensitivity92.1 dB −1.3
PRV Audio10MB1000FT
£178.39Fs75 Hz +60%, worse
Qts0.32 +7%
Vas32.3 L −22%, better
BL14.5 T·m +18%, better
Xmax5.9 mm −10%
Sensitivity98.2 dB +4.8, better
PRV Audio10W1000-NDY-4
£186.83Fs50 Hz +7%
Qts0.27 −10%
Vas46.4 L +12%, worse
BL12.0 T·m –
Xmax6.5 mm –
Sensitivity95.2 dB +1.8
Sica10 N 3 PL
£200.22Fs51 Hz +9%
Qts0.29 −3%
Vas40.5 L –
BL15.9 T·m +29%, better
Xmax5.5 mm −15%, worse
Sensitivity94.6 dB +1.2
Eighteen Sound10NW750
£211.47Fs53 Hz +13%, worse
Qts0.31 +3%
Vas34 L −18%, better
BL16.4 T·m +33%, better
Xmax7.5 mm +15%, better
Sensitivity94 dB +0.6
FaitalPRO10HX240
£309.12Fs65 Hz +39%, worse
Qts0.28 −7%
Vas31.8 L −23%, better
BL15.5 T·m +26%, better
Xmax7.4 mm +13%, better
Sensitivity96.7 dB +3.3, better
Sica10 CX 3 PL P
No current priceFs59 Hz +26%, worse
Qts0.29 −3%
Vas36.1 L −12%, better
BL15.3 T·m +25%, better
Xmax6 mm −8%
Sensitivity95.8 dB +2.4, better
RCFMB10G350
No current priceFs58 Hz +24%, worse
Qts0.31 +3%
Vas34 L −18%, better
BL14.7 T·m +20%, better
Xmax7 mm +8%
Sensitivity95.2 dB +1.8
PRV Audio10MB500-4
No current priceFs56 Hz +19%, worse
Qts0.29 −3%
Vas47.6 L +15%, worse
BL12.3 T·m –
Xmax4.5 mm −31%, worse
Sensitivity96.4 dB +3, better
No current price
Fs58 Hz +24%, worse
Qts0.32 +7%
Vas41 L –
BL15.3 T·m +24%, better
Xmax5.5 mm −15%, worse
Sensitivity95.7 dB +2.3, better
Sica10 K 3 PL
No current priceFs51 Hz +8%
Qts0.26 −13%, better
Vas40 L −3%
BL16.1 T·m +31%, better
Xmax6.5 mm –
Sensitivity94.9 dB +1.5
Sica10 FE 3 CP
No current priceFs52 Hz +11%, worse
Qts0.31 +3%
Vas38.6 L −6%
BL15.3 T·m +25%, better
Xmax5 mm −23%, worse
Sensitivity94.3 dB +0.9
No photo
PHL Audio3400
No current priceFs53 Hz +13%, worse
Qts0.28 −7%
Vas30.6 L −26%, better
BL18.1 T·m +47%, better
Xmax6.5 mm –
Sensitivity94 dB +0.6
MonacorSP-10A/302PA
No current priceFs55 Hz +17%, worse
Qts0.30 –
Vas40 L −3%
BL15.8 T·m +29%, better
Xmax4 mm −38%, worse
Sensitivity95.3 dB +1.9
MonacorSP-310CX
No current priceFs60 Hz +28%, worse
Qts0.32 +7%
Vas41 L –
BL13.3 T·m +8%
Xmax2.5 mm −62%, worse
Sensitivity95.9 dB +2.5, better
Sica10 S 3 PL
No current priceFs43 Hz −8%
Qts0.27 −10%
Vas39.9 L −3%
BL16.9 T·m +37%, better
Xmax7 mm +8%
Sensitivity92.6 dB −0.8
Sica10 PN 3
No current priceFs48 Hz –
Qts0.26 −13%, better
Vas40.1 L –
BL16.1 T·m +31%, better
Xmax7 mm +8%
Sensitivity94.1 dB +0.7
Eighteen Sound10MB400
No current priceFs70 Hz +49%, worse
Qts0.33 +10%, worse
Vas41 L –
BL12 T·m –
Xmax2.5 mm −62%, worse
Sensitivity97.8 dB +4.4, better
MonacorSP-10/250PRO
No current priceFs47 Hz –
Qts0.33 +10%, worse
Vas40.7 L –
BL18.3 T·m +49%, better
Xmax7 mm +8%
Sensitivity92.8 dB −0.6
Oberton10NMB200
No current priceFs59 Hz +25%, worse
Qts0.32 +5%
Vas34.9 L −15%, better
BL14.1 T·m +14%, better
Xmax4.3 mm −35%, worse
Sensitivity95.4 dB +2, better
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
