Size
12"
Impedance
8Ω
RMS Power
350W
EBP
136
Vented alignment
Vd
319cm³
Overall Parameters
Valid
Fs53Hz
Qts0.36
Qes0.39
Qms5.3
Vas71.4L
Re5.3Ω
Le0.82mH
BL15.2Tm
Sd531cm²
Mms50g
Xmax6.0mm
Power350W
Impedance8Ω
Min Impedance6.0Ω
F Low50Hz
F High18000Hz
Voice Coil75mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
Pricing & availability
No standard offers found
Check the manufacturer website for current pricing.
Dimensions & Physical
Weight7.1kg
Driver Components
LF
Fs53 Hz
Qts0.36
Qes0.39
Qms5.3
Vas71.4 L
Re5.3 Ω
Le0.82 mH
BL15.2 Tm
Sd531 cm²
Mms50 g
Xmax6.0 mm
Power350 W
Impedance8 Ω
Min Impedance6.0 Ω
F Low50 Hz
F High3500 Hz
Voice Coil75 mm
Cms0.179
Power Program700
Sensitivity98
Xmech10
Section dimensions
Weight7100.0 kg
HF
Power80 W
Impedance8 Ω
Min Impedance8.0 Ω
F Low600 Hz
F High18000 Hz
Xover1200 Hz
Throat36 mm
Voice Coil75 mm
Flux Density1.60 T
Power Program160
Sensitivity105.5
