Sica 12 L1 2.5 SL 8Ω
8 Ω
No current price
- Fs
- 48Hz
- Xmax
- 3.7mm
- SPL
- 96dB
- Pe
- 300W
- BL
- 14.2T·m
- Vd
- 182cm³
- Qts
- 0.36
- Vas
- 82L
Sica 12 L1 2.5 SL is a 12-inch 8 ohm LF driver rated at 300 W RMS. The validated T/S data includes Fs 48 Hz, Qts 0.36, Vas 81.8 L, Xmax 3.7 mm, sensitivity 95.7 dB, plus 182 cm³ Vd and 125 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 48Hz
- Qts
- 0.36
- Qes
- 0.38
- Qms
- 7.5
- Vas
- 81.8L
- Re
- 5.5Ω
- Le
- 0.75mH
Motor and cone
- BL
- 14.2T·m
- Sd
- 491cm²
- Mms
- 47g
- Xmax
- 3.7mm
- Vd †
- 182cm³
- Voice coil
- 65mm
- Flux density
- 1.15T
Power and response
- Sensitivity †
- 95.7dB
- Manufacturer sensitivity
- 97.3dB
- Power
- 300W
- Impedance
- 8Ω
- EBP †
- 125 · Leans vented
Size and mounting
- Diameter
- 318mm
- Cutout
- 287mm
- Bolt circle
- 300mm
- Depth
- 130.2mm
- Weight
- 2.3kg
Other published values
- Cms
- 0.24mm/N
- Power Program
- 600
Sensitivity shows 95.7 dB, calculated from the T/S values. Sica publishes 97.3 dB, 1.6 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Sica lists
LF · Primary · 12″
- BL
- 14.2T·m
- Fs
- 48Hz
- Le
- 0.75mH
- Re
- 5.5Ω
- Sd
- 491cm²
- Cms
- 0.24mm/N
- Mms
- 47g
- Qes
- 0.38
- Qms
- 7.5
- Qts
- 0.36
- SPL
- 95.7dB
- Vas
- 81.8L
- Xmax
- 3.7mm
- Power
- 300W
- Impedance
- 8Ω
- Flux density
- 1.15T
- Sensitivity
- 97.3dB
- Power Program
- 600
- Calculated sensitivity †
- 95.7dB
- Manufacturer sensitivity
- 97.3dB
- Voice coil
- 65mm
- Weight
- 2.3kg
- Diameter
- 318mm
- Depth
- 130.2mm
- Cutout
- 287mm
- Bolt circle
- 300mm
02
Compare
Same-size drivers, compared with the 12 L1 2.5 SL. Clear differences are green when better and red when worse.
This driver12 L1 2.5 SL
Best price
–
Fs
48 Hz
Qts
0.36
Vas
81.8 L
BL
14.2 T·m
Xmax
3.7 mm
Sensitivity
95.7 dB
Power
300 W
PRV Audio12W750A
£63.52Fs60 Hz +26%, worse
Qts0.43 +19%, worse
Vas81 L –
BL14.3 T·m –
Xmax3.6 mm –
Sensitivity98 dB +2.3, better
CelestionTF1225
£83.50Fs56 Hz +17%, worse
Qts0.37 –
Vas67.3 L −18%, better
BL14.3 T·m –
Xmax4.5 mm +22%, better
Sensitivity96.4 dB +0.7
LavoceWSN122.50
£99.64Fs53 Hz +12%, worse
Qts0.36 –
Vas69.4 L −15%, better
BL15.8 T·m +12%, better
Xmax4.7 mm +27%, better
Sensitivity96.3 dB +0.6
B&C12HPL64
£117.22Fs52 Hz +9%
Qts0.32 −11%, better
Vas85 L +4%
BL14.9 T·m +5%
Xmax4 mm +8%
Sensitivity97.4 dB +1.7
PRV Audio12MB1000FT
£119.62Fs53 Hz +11%, worse
Qts0.37 –
Vas74.6 L −9%
BL16.5 T·m +16%, better
Xmax6.9 mm +86%, better
Sensitivity96.6 dB +0.9
Eighteen Sound12W500
£128.11Fs46 Hz −3%
Qts0.36 –
Vas123 L +50%, worse
BL12.1 T·m −15%, worse
Xmax4 mm +8%
Sensitivity97 dB +1.3
FaitalPRO12PR310
£135.00Fs54 Hz +14%, worse
Qts0.40 +11%, worse
Vas73.5 L −10%, better
BL14.4 T·m –
Xmax4.9 mm +33%, better
Sensitivity96.5 dB +0.8
FaitalPRO12PR300
£135.81Fs50 Hz +5%
Qts0.36 –
Vas92.6 L +13%, worse
BL14.1 T·m –
Xmax4.9 mm +33%, better
Sensitivity97 dB +1.3
CelestionTN1230
£145.00Fs47 Hz –
Qts0.35 –
Vas64.3 L −21%, better
BL18.6 T·m +31%, better
Xmax3.8 mm –
Sensitivity94.5 dB −1.2
FaitalPRO12PR320
£154.90Fs42 Hz −12%, better
Qts0.37 –
Vas113.3 L +39%, worse
BL13.5 T·m −5%
Xmax7.4 mm +99%, better
Sensitivity95.4 dB –
Sica12 PF 3
£166.62Fs47 Hz –
Qts0.39 +8%
Vas76.5 L −6%
BL15.4 T·m +8%
Xmax5.5 mm +49%, better
Sensitivity94.8 dB −0.9
CelestionFTX1225
£239.00Fs47 Hz –
Qts0.40 +10%, worse
Vas84.6 L +3%
BL14 T·m –
Xmax6 mm +62%, better
Sensitivity95.1 dB −0.6
Dayton AudioRSS315HF-4
£251.11Fs24 Hz −49%, better
Qts0.39 +8%
Vas84.1 L –
BL14.0 T·m –
Xmax14.3 mm +286%, better
Sensitivity86.3 dB −9.4, worse
LavoceCAF123.00T
£257.89Fs53 Hz +12%, worse
Qts0.36 –
Vas71.4 L −13%, better
BL15.2 T·m +7%
Xmax6 mm +62%, better
Sensitivity96.4 dB +0.7
LavoceCAF123.00TH
£268.19Fs53 Hz +12%, worse
Qts0.36 –
Vas71.4 L −13%, better
BL15.2 T·m +7%
Xmax6 mm +62%, better
Sensitivity96.4 dB +0.7
B&C12FCX76
£294.14Fs47 Hz –
Qts0.34 −6%
Vas82 L –
BL15.6 T·m +10%
Xmax5 mm +35%, better
Sensitivity95.9 dB –
FaitalPRO12HX240
£325.71Fs56 Hz +18%, worse
Qts0.37 –
Vas61.1 L −25%, better
BL16 T·m +13%, better
Xmax7.4 mm +99%, better
Sensitivity96.5 dB +0.8
Oberton12CX1
No current priceFs58 Hz +21%, worse
Qts0.37 –
Vas68.5 L −16%, better
BL13.9 T·m –
Xmax4.3 mm +15%, better
Sensitivity97.2 dB +1.5
P.Audio12BM-300B-V3
No current priceFs55 Hz +16%, worse
Qts0.34 −6%
Vas62.4 L −24%, better
BL17.1 T·m +20%, better
Xmax3.9 mm +5%
Sensitivity96.6 dB +0.9
P.Audio12BM-400B
No current priceFs55 Hz +16%, worse
Qts0.34 −6%
Vas62.4 L −24%, better
BL17.1 T·m +20%, better
Xmax3.9 mm +5%
Sensitivity96.6 dB +0.9
EminenceFS12.30A8
No current priceFs55 Hz +16%, worse
Qts0.36 –
Vas61 L −25%, better
BL17 T·m +20%, better
Xmax4.3 mm +16%, better
Sensitivity96.3 dB +0.6
P.Audio12NT-76MB
No current priceFs55 Hz +16%, worse
Qts0.36 –
Vas71.6 L −12%, better
BL17.4 T·m +23%, better
Xmax4.5 mm +22%, better
Sensitivity97.1 dB +1.4
PRV Audio12MR1000
No current priceFs49 Hz +4%
Qts0.39 +8%
Vas92.3 L +13%, worse
BL15.9 T·m +12%, better
Xmax3 mm −19%, worse
Sensitivity96.5 dB +0.8
MonacorSP-12/200PA
No current priceFs45 Hz −5%
Qts0.33 −8%
Vas114 L +39%, worse
BL15.4 T·m +8%
Xmax4 mm +8%
Sensitivity96.8 dB +1.1
CIAREHSB322
No current priceFs36 Hz −24%, better
Qts0.37 –
Vas83 L –
BL17 T·m +20%, better
Xmax7.5 mm +103%, better
Sensitivity91.9 dB −3.8, worse
JensenBP12250-8
No current priceFs50 Hz +6%
Qts0.32 −11%, better
Vas73.5 L −10%, better
BL16.4 T·m +15%, better
Xmax3.1 mm −16%, worse
Sensitivity96.4 dB +0.7
P.Audio12BM-500B
No current priceFs52 Hz +9%
Qts0.35 –
Vas69.8 L −15%, better
BL16.6 T·m +17%, better
Xmax4.8 mm +30%, better
Sensitivity96.3 dB +0.6
P.AudioEX12-500S
No current priceFs56 Hz +18%, worse
Qts0.40 +11%, worse
Vas54.5 L −33%, better
BL16.3 T·m +15%, better
Xmax3.9 mm +5%
Sensitivity95.5 dB –
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
