CelestionTF1225
£83.50 · 68% less, betterFs56 Hz +5%
Qts0.37 –
Vas67.3 L −6%
BL14.3 T·m −6%
Xmax4.5 mm −25%, worse
Sensitivity96.4 dB –
12-inch LF driver · CAF123 series · 75 mm voice coil · 350 W
Lavoce CAF123.00T 8Ω
8 Ω · 50–18000 Hz
No price for delivery to the UK
- Fs
- 53Hz
- Xmax
- 6mm
- SPL
- 96dB
- Pe
- 350W
- BL
- 15.2T·m
- Vd
- 319cm³
- Qts
- 0.36
- Vas
- 71L
Lavoce CAF123.00T is a 12-inch 8 ohm LF driver rated at 350 W RMS. The validated T/S data includes Fs 53 Hz, Qts 0.36, Vas 71.4 L, Xmax 6 mm, sensitivity 96.4 dB, plus 319 cm³ Vd and 136 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £257.89.
The published T/S values agree with each other
Thiele/Small
- Fs
- 53Hz
- Qts
- 0.36
- Qes
- 0.39
- Qms
- 5.3
- Vas
- 71.4L
- Re
- 5.3Ω
- Le
- 0.82mH
Motor and cone
- BL
- 15.2T·m
- Sd
- 531cm²
- Mms
- 50g
- Xmax
- 6mm
- Vd †
- 319cm³
- Voice coil
- 75mm
Power and response
- Sensitivity †
- 96.4dB
- Manufacturer sensitivity
- 98dB
- Power
- 350W
- Impedance
- 8Ω
- Min. impedance
- 6Ω
- Range
- 50–18000Hz
- EBP †
- 136 · Leans vented
Size and mounting
- Weight
- 7kg
Other published values
- Cms
- 0.18mm/N
- Xmech
- 10
- Power Program
- 700
- High limit
- 3500Hz
Sensitivity shows 96.4 dB, calculated from the T/S values. Lavoce publishes 98.0 dB, 1.6 dB apart.
Excursion and motor values come from the LF section; the frequency range spans every section.
† Calculated by bits from the published values
What this validation status means
Components and manufacturer details
LF
- BL
- 15.2T·m
- Fs
- 53Hz
- Le
- 0.82mH
- Re
- 5.3Ω
- Sd
- 531cm²
- Cms
- 0.18mm/N
- Mms
- 50g
- Qes
- 0.39
- Qms
- 5.3
- Qts
- 0.36
- SPL
- 96.4dB
- Vas
- 71.4L
- Xmax
- 6mm
- Xmech
- 10
- Power
- 350W
- Impedance
- 8Ω
- Sensitivity
- 98dB
- Low limit
- 50Hz
- Power Program
- 700
- Calculated sensitivity †
- 96.4dB
- High limit
- 3500Hz
- Manufacturer sensitivity
- 98dB
- Min. impedance
- 6Ω
- Voice coil
- 75mm
- Weight
- 7kg
HF
- SPL
- 105.5dB
- Power
- 80W
- Impedance
- 8Ω
- Flux density
- 1.60T
- Sensitivity
- 105.5dB
- Low limit
- 600Hz
- Power Program
- 160
- High limit
- 18000Hz
- Throat
- 36mm
- Manufacturer sensitivity
- 105.5dB
- Min. impedance
- 8Ω
- Voice coil
- 75mm
- Crossover
- 1200Hz
02
Compare
Same-size drivers, compared with the CAF123.00T. Clear differences are green when better and red when worse.
This driverCAF123.00T
Best price
£257.89
Fs
53 Hz
Qts
0.36
Vas
71.4 L
BL
15.2 T·m
Xmax
6 mm
Sensitivity
96.4 dB
Power
350 W
CelestionTF1225E
£99.00 · 62% less, betterFs53 Hz –
Qts0.33 −7%
Vas67.7 L −5%
BL17.7 T·m +16%, better
Xmax5.3 mm −13%, worse
Sensitivity96.3 dB –
LavoceWSN122.50
£99.64 · 61% less, betterFs53 Hz –
Qts0.36 –
Vas69.4 L –
BL15.8 T·m +4%
Xmax4.7 mm −22%, worse
Sensitivity96.3 dB –
PRV Audio12MB1000FT
£119.62 · 54% less, betterFs53 Hz –
Qts0.37 –
Vas74.6 L +4%
BL16.5 T·m +9%
Xmax6.9 mm +15%, better
Sensitivity96.6 dB –
FaitalPRO12PR310
£135.00 · 48% less, betterFs54 Hz –
Qts0.40 +11%, worse
Vas73.5 L –
BL14.4 T·m −5%
Xmax4.9 mm −18%, worse
Sensitivity96.5 dB –
FaitalPRO12PR300
£135.81 · 47% less, betterFs50 Hz −6%
Qts0.36 –
Vas92.6 L +30%, worse
BL14.1 T·m −7%
Xmax4.9 mm −18%, worse
Sensitivity97 dB +0.6
Sica12 PF 3
£166.62 · 35% less, betterFs47 Hz −11%, better
Qts0.39 +8%
Vas76.5 L +7%
BL15.4 T·m –
Xmax5.5 mm −8%
Sensitivity94.8 dB −1.6
Eighteen Sound12W700
£179.00 · 31% less, betterFs58 Hz +9%
Qts0.36 –
Vas55 L −23%, better
BL17.7 T·m +16%, better
Xmax6.5 mm +8%
Sensitivity96.7 dB –
EminenceKAPPALITE 3012HO
£187.01 · 27% less, betterFs52 Hz –
Qts0.32 −11%, better
Vas81.1 L +14%, worse
BL15.9 T·m +5%
Xmax6.2 mm +3%
Sensitivity97.4 dB +1
CelestionFTX1225
£239.00 · 7% less, betterFs47 Hz −11%, better
Qts0.40 +10%, worse
Vas84.6 L +18%, worse
BL14 T·m −8%
Xmax6 mm –
Sensitivity95.1 dB −1.3
LavoceCAF123.00TH
£268.19 · 4% moreFs53 Hz –
Qts0.36 –
Vas71.4 L –
BL15.2 T·m –
Xmax6 mm –
Sensitivity96.4 dB –
B&C12FCX76
£294.14 · 14% more, worseFs47 Hz −11%, better
Qts0.34 −6%
Vas82 L +15%, worse
BL15.6 T·m –
Xmax5 mm −17%, worse
Sensitivity95.9 dB −0.5
FaitalPRO12HX240
£325.71 · 26% more, worseFs56 Hz +6%
Qts0.37 –
Vas61.1 L −14%, better
BL16 T·m +5%
Xmax7.4 mm +23%, better
Sensitivity96.5 dB –
REDCATT121XR
No current priceFs46 Hz −13%, better
Qts0.33 −8%
Vas69.1 L −3%
BL16 T·m +5%
Xmax6.3 mm +6%
Sensitivity94.1 dB −2.3, worse
CelestionCNX1230
No current priceFs54 Hz –
Qts0.34 −6%
Vas68.4 L −4%
BL16.3 T·m +7%
Xmax6.5 mm +8%
Sensitivity96.8 dB –
FaneCOLOSSUS 12MBH
No current priceFs48 Hz −9%
Qts0.34 −7%
Vas75 L +5%
BL17.5 T·m +15%, better
Xmax6 mm –
Sensitivity95.8 dB −0.6
CelestionTF1230SL
No current priceFs57 Hz +7%
Qts0.39 +8%
Vas53.8 L −25%, better
BL15.7 T·m +3%
Xmax6 mm –
Sensitivity95.6 dB −0.8
HiViF12
No current priceFs26 Hz −51%, better
Qts0.36 –
Vas145.6 L +104%, worse
BL16.1 T·m +6%
Xmax6 mm –
Sensitivity90.2 dB −6.2, worse
P.Audio12BM-500B
No current priceFs52 Hz –
Qts0.35 –
Vas69.8 L –
BL16.6 T·m +9%
Xmax4.8 mm −20%, worse
Sensitivity96.3 dB –
Oberton12NMB35
No current priceFs54 Hz –
Qts0.36 –
Vas54.3 L −24%, better
BL17 T·m +12%, better
Xmax6.8 mm +13%, better
Sensitivity95.7 dB −0.7
P.Audio12NT-76MB
No current priceFs55 Hz +4%
Qts0.36 –
Vas71.6 L –
BL17.4 T·m +15%, better
Xmax4.5 mm −25%, worse
Sensitivity97.1 dB +0.7
Sica12 S 3 PL
No current priceFs42 Hz −21%, better
Qts0.34 −6%
Vas76.9 L +8%
BL16.8 T·m +11%, better
Xmax7 mm +17%, better
Sensitivity94 dB −2.4, worse
PRV Audio12MB2000FT
No current priceFs56 Hz +5%
Qts0.32 −11%, better
Vas66.9 L −6%
BL17.7 T·m +17%, better
Xmax6 mm –
Sensitivity97.5 dB +1.1
Oberton12CX
No current priceFs51 Hz −3%
Qts0.35 −4%
Vas58.5 L −18%, better
BL17.4 T·m +14%, better
Xmax5.3 mm −13%, worse
Sensitivity95.4 dB −1
CIARE12.75W1
No current priceFs49 Hz −8%
Qts0.33 −8%
Vas67 L −6%
BL18.9 T·m +24%, better
Xmax6 mm –
Sensitivity95.7 dB −0.7
Oberton12CX1
No current priceFs58 Hz +9%
Qts0.37 –
Vas68.5 L −4%
BL13.9 T·m −8%
Xmax4.3 mm −29%, worse
Sensitivity97.2 dB +0.8
No photo
PHL Audio4511
No current priceFs48 Hz −9%
Qts0.40 +11%, worse
Vas74.1 L +4%
BL15.1 T·m –
Xmax7 mm +17%, better
Sensitivity94.6 dB −1.8
P.Audio12BMA-500B
No current priceFs57 Hz +8%
Qts0.34 −6%
Vas61.4 L −14%, better
BL16.7 T·m +10%
Xmax5 mm −17%, worse
Sensitivity97 dB +0.6
Eighteen Sound12MB606
No current priceFs50 Hz −6%
Qts0.32 −11%, better
Vas84 L +18%, worse
BL16 T·m +5%
Xmax6.5 mm +8%
Sensitivity96.9 dB +0.5
Sica12 L1 2.5 SL
No current priceFs48 Hz −10%, better
Qts0.36 –
Vas81.8 L +15%, worse
BL14.2 T·m −7%
Xmax3.7 mm −38%, worse
Sensitivity95.7 dB −0.7
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Blue Aran 3-5 months | £213.97 | Usually available in 3-5 months | Visit shop at Blue Aran |
