- Net volume
- 60L
- Tuning
- 55Hz
Eighteen Sound gives the volume and tuning; the port is sized for the driver when you open it.
12-inch LF driver · 450 W
Eighteen Sound 12MB606 8Ω
8 Ω · 50–5200 Hz
No current price
- Fs
- 50Hz
- Xmax
- 6.5mm
- SPL
- 97dB
- Pe
- 450W
- BL
- 16T·m
- Vd
- 345cm³
- Qts
- 0.32
- Vas
- 84L
Published graphs
Eighteen Sound 12MB606 is a 12-inch 8 ohm LF driver rated at 450 W RMS. The validated T/S data includes Fs 50 Hz, Qts 0.32, Vas 84 L, Xmax 6.5 mm, sensitivity 96.9 dB, plus 345 cm³ Vd and 147 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 50Hz
- Qts
- 0.32
- Qes
- 0.34
- Qms
- 6.3
- Vas
- 84L
- Re
- 5.7Ω
- Le
- 1.50mH
Motor and cone
- BL
- 16T·m
- Sd
- 531cm²
- Mms
- 47g
- Xmax
- 6.5mm
- Vd †
- 345cm³
Power and response
- Sensitivity †
- 96.9dB
- Manufacturer sensitivity
- 98dB
- Power
- 450W
- Nominal power
- 450W
- Impedance
- 8Ω
- Range
- 50–5200Hz
- EBP †
- 147 · Leans vented
Size and mounting
- Diameter
- 315mm
- Cutout
- 282mm
- Bolt circle
- 296mm
- Depth
- 133mm
- Weight
- 5.7kg
Other published values
- Power Program
- 600
Sensitivity shows 96.9 dB, calculated from the T/S values. Eighteen Sound publishes 98.0 dB, 1.1 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Eighteen Sound lists
LF · Primary · 12″
- BL
- 16T·m
- Fs
- 50Hz
- Le
- 1.50mH
- Re
- 5.7Ω
- Sd
- 531cm²
- Mms
- 47g
- Qes
- 0.34
- Qms
- 6.3
- Qts
- 0.32
- SPL
- 96.9dB
- Vas
- 84L
- Xmax
- 6.5mm
- Power
- 450W
- Impedance
- 8Ω
- Sensitivity
- 98dB
- Low limit
- 50Hz
- Nominal power
- 450W
- Power Program
- 600
- Calculated sensitivity †
- 96.9dB
- High limit
- 5200Hz
- Manufacturer sensitivity
- 98dB
- Weight
- 5.7kg
- Diameter
- 315mm
- Depth
- 133mm
- Cutout
- 282mm
- Bolt circle
- 296mm
02
Designs
What Eighteen Sound suggests for the 12MB606. No published designs name it yet.
How we find designsEighteen Sound’s suggested box
From Eighteen Sound’s 12MB606 page
Open this box in 00 Simulator
Modelling the box in 00 Simulator…
03
Compare
Same-size drivers, compared with the 12MB606. Clear differences are green when better and red when worse.
This driver12MB606
Best price
–
Fs
50 Hz
Qts
0.32
Vas
84 L
BL
16 T·m
Xmax
6.5 mm
Sensitivity
96.9 dB
Power
450 W
SB AudienceROSSO-12MW300
£106.55Fs48 Hz −4%
Qts0.27 −16%, better
Vas85.9 L –
BL17.4 T·m +9%
Xmax6.7 mm –
Sensitivity97.3 dB –
B&C12HPL64
£118.27Fs52 Hz +4%
Qts0.32 –
Vas85 L –
BL14.9 T·m −7%
Xmax4 mm −38%, worse
Sensitivity97.4 dB +0.5
PRV Audio12MB1000FT
£120.82Fs53 Hz +5%
Qts0.37 +16%, worse
Vas74.6 L −11%, better
BL16.5 T·m +3%
Xmax6.9 mm +6%
Sensitivity96.6 dB –
Beyma12WRS400
£122.29Fs42 Hz −16%, better
Qts0.29 −9%
Vas91 L +8%
BL17.4 T·m +9%
Xmax6.3 mm −3%
Sensitivity95.4 dB −1.5
£129.00
Fs43 Hz −14%, better
Qts0.31 –
Vas107 L +27%, worse
BL16 T·m –
Xmax6 mm −8%
Sensitivity95.9 dB −1
Beyma12G40
£154.94Fs44 Hz −12%, better
Qts0.30 −6%
Vas81 L −4%
BL18.4 T·m +15%, better
Xmax7 mm +8%
Sensitivity95.6 dB −1.3
EminenceKAPPALITE 3012LF
£175.00Fs37 Hz −26%, better
Qts0.32 –
Vas106.7 L +27%, worse
BL16.7 T·m +4%
Xmax9.1 mm +40%, better
Sensitivity94 dB −2.9, worse
EminenceKAPPALITE 3012HO
£188.89Fs52 Hz +4%
Qts0.32 –
Vas81.1 L −3%
BL15.9 T·m –
Xmax6.2 mm −5%
Sensitivity97.4 dB +0.5
FaitalPRO12FH520
£197.29Fs50 Hz –
Qts0.29 −9%
Vas73.7 L −12%, better
BL17.3 T·m +8%
Xmax7.3 mm +12%, better
Sensitivity96.9 dB –
SB AcousticsSB34SWPL76-4
£202.67Fs19 Hz −62%, better
Qts0.32 –
Vas79 L −6%
BL18.3 T·m +14%, better
Xmax30 mm +362%, better
Sensitivity84.2 dB −12.7, worse
Sica12 N 3 PL
£209.51Fs46 Hz −8%
Qts0.30 −6%
Vas87.9 L +5%
BL16 T·m –
Xmax5.5 mm −15%, worse
Sensitivity96.4 dB −0.5
Eighteen Sound12ND830
£242.46Fs55 Hz +10%, worse
Qts0.28 −12%, better
Vas72 L −14%, better
BL17.6 T·m +10%, better
Xmax6.5 mm –
Sensitivity98 dB +1.1
B&C12FCX76
£294.14Fs47 Hz −6%
Qts0.34 +6%
Vas82 L –
BL15.6 T·m –
Xmax5 mm −23%, worse
Sensitivity95.9 dB −1
Eighteen Sound12NCX910
£436.54Fs57 Hz +14%, worse
Qts0.30 −6%
Vas58 L −31%, better
BL18.1 T·m +13%, better
Xmax6.9 mm +6%
Sensitivity97.4 dB +0.5
Eighteen Sound12NCX910N
£478.98Fs57 Hz +14%, worse
Qts0.30 −6%
Vas58 L −31%, better
BL18.1 T·m +13%, better
Xmax6.9 mm +6%
Sensitivity97.4 dB +0.5
Scanspeak28W/8878T01
£591.32Fs22 Hz −56%, better
Qts0.31 −3%
Vas116 L +38%, worse
BL14.9 T·m −7%
Xmax7.5 mm +15%, better
Sensitivity87.8 dB −9.1, worse
CelestionCNX1230
No current priceFs54 Hz +8%
Qts0.34 +5%
Vas68.4 L −19%, better
BL16.3 T·m –
Xmax6.5 mm –
Sensitivity96.8 dB –
Eighteen Sound12W600
No current priceFs50 Hz –
Qts0.30 −6%
Vas73 L −13%, better
BL17.3 T·m +8%
Xmax6.5 mm –
Sensitivity96.6 dB –
Sica12 S 3 PL
No current priceFs42 Hz −16%, better
Qts0.34 +6%
Vas76.9 L −8%
BL16.8 T·m +5%
Xmax7 mm +8%
Sensitivity94 dB −2.9, worse
PRV Audio12MB2000FT
No current priceFs56 Hz +11%, worse
Qts0.32 –
Vas66.9 L −20%, better
BL17.7 T·m +11%, better
Xmax6 mm −8%
Sensitivity97.5 dB +0.6
REDCATT121XR
No current priceFs46 Hz −8%
Qts0.33 +3%
Vas69.1 L −18%, better
BL16 T·m –
Xmax6.3 mm –
Sensitivity94.1 dB −2.8, worse
Eighteen Sound12NTLX3500
No current priceFs39 Hz −22%, better
Qts0.33 +3%
Vas79.6 L −5%
BL17.1 T·m +7%
Xmax7.9 mm +22%, better
Sensitivity93.3 dB −3.6, worse
CIARE12.75W1
No current priceFs49 Hz –
Qts0.33 +3%
Vas67 L −20%, better
BL18.9 T·m +18%, better
Xmax6 mm −8%
Sensitivity95.7 dB −1.2
JensenBP12250-8
No current priceFs50 Hz –
Qts0.32 –
Vas73.5 L −13%, better
BL16.4 T·m –
Xmax3.1 mm −52%, worse
Sensitivity96.4 dB −0.5
PRV Audio12MB2000FT-NDY
No current priceFs55 Hz +10%, worse
Qts0.30 −6%
Vas71.5 L −15%, better
BL17.7 T·m +11%, better
Xmax6 mm −8%
Sensitivity97.9 dB +1
MonacorSP-12A/302PA
No current priceFs50 Hz –
Qts0.34 +6%
Vas77 L −8%
BL17.0 T·m +6%
Xmax5 mm −23%, worse
Sensitivity96.4 dB −0.5
Sica12 C 2.5 CP
No current priceFs51 Hz –
Qts0.30 −6%
Vas84.5 L –
BL17.3 T·m +8%
Xmax5 mm −23%, worse
Sensitivity97.5 dB +0.6
LavoceCAF123.00T
No current priceFs53 Hz +6%
Qts0.36 +12%, worse
Vas71.4 L −15%, better
BL15.2 T·m −5%
Xmax6 mm −8%
Sensitivity96.4 dB −0.5
LavoceCAF123.00TH
No current priceFs53 Hz +6%
Qts0.36 +12%, worse
Vas71.4 L −15%, better
BL15.2 T·m −5%
Xmax6 mm −8%
Sensitivity96.4 dB −0.5
Eighteen Sound12NCX910BE
No current priceFs57 Hz +14%, worse
Qts0.30 −6%
Vas58 L −31%, better
BL18.1 T·m +13%, better
Xmax6.9 mm +6%
Sensitivity97.4 dB +0.5
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
No current price found. Pricing may appear after the next vendor refresh.
