Overview
LF DriverKappaLITE series
Eminence
Eminence KAPPALITE 3012HO
Eminence KAPPALITE 3012HO is a 12" 8 ohm LF driver rated at 400W RMS. The validated T/S data includes Fs 52Hz, Qts 0.32, Vas 81.1L, Xmax 6.2mm, sensitivity 97.4dB, plus 330cm³ Vd and 158 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £184.90.
Size
12"
Impedance
8Ω
RMS Power
400W
Sensitivity
97.4dB
100.5dBmanufacturer; using T/S-derived value (3.1dB delta).
EBP
158
Vented alignment
Vd
330cm³
T/S Parameters
Valid
Fs52Hz
Qts0.32
Qes0.33
Qms8.4
Vas81.1L
Re5.5Ω
Le0.57mH
BL15.9Tm
Sd532cm²
Mms47g
Xmax6.2mm
SPL97dB
Power400W
Impedance8Ω
F Low51Hz
F High3000Hz
Pricing & availability
Price definitionsPrice movement
Other offers
3 vendorsbluearan
Updated 11 Sept 2026· 8Ω
Source: inc VAT · 20%
£198.05
inc VAT
2 in stock
leanaudio
Updated 11 Sept 2026· 8Ω
Source: inc VAT · 20%
£210.00
inc VAT
Out of stock
leanbusiness
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£215.00
inc VAT
Best current price
Updated 11 Sept 2026
partsexpress
£184.90
Avg £199.32£14.41 below avg (-7.2%)
inc VAT·2 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.2kg
Diameter314.5mm
Overall Depth143.0mm
Cutout Diameter280.9mm
Bolt Circle Diameter295.1mm
