12-inch LF driver · WSN122 series · 65 mm voice coil · 250 W
Lavoce WSN122.50 8Ω
8 Ω · 50–3000 Hz
No price for delivery to the UK
- Fs
- 53Hz
- Xmax
- 4.7mm
- SPL
- 96dB
- Pe
- 250W
- BL
- 15.8T·m
- Vd
- 250cm³
- Qts
- 0.36
- Vas
- 69L
Lavoce WSN122.50 is a 12-inch 8 ohm LF driver rated at 250 W RMS. The validated T/S data includes Fs 53 Hz, Qts 0.36, Vas 69.4 L, Xmax 4.7 mm, sensitivity 96.3 dB, plus 250 cm³ Vd and 136 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £99.75.
The published T/S values agree with each other
Thiele/Small
- Fs
- 53Hz
- Qts
- 0.36
- Qes
- 0.39
- Qms
- 4.3
- Vas
- 69.4L
- Re
- 5.7Ω
- Le
- 0.77mH
Motor and cone
- BL
- 15.8T·m
- Sd
- 531cm²
- Mms
- 52g
- Xmax
- 4.7mm
- Vd †
- 250cm³
- Voice coil
- 65mm
Power and response
- Sensitivity †
- 96.3dB
- Manufacturer sensitivity
- 97.5dB
- Power
- 250W
- Impedance
- 8Ω
- Min. impedance
- 6.3Ω
- Range
- 50–3000Hz
- EBP †
- 136 · Leans vented
Size and mounting
- Weight
- 2.1kg
Other published values
- Cms
- 0.17mm/N
- Xmech
- 8.8
- Power Program
- 500
Sensitivity shows 96.3 dB, calculated from the T/S values. Lavoce publishes 97.5 dB, 1.2 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 12″
- BL
- 15.8T·m
- Fs
- 53Hz
- Le
- 0.77mH
- Re
- 5.7Ω
- Sd
- 531cm²
- Cms
- 0.17mm/N
- Mms
- 52g
- Qes
- 0.39
- Qms
- 4.3
- Qts
- 0.36
- SPL
- 96.3dB
- Vas
- 69.4L
- Xmax
- 4.7mm
- Xmech
- 8.8
- Power
- 250W
- Impedance
- 8Ω
- Sensitivity
- 97.5dB
- Low limit
- 50Hz
- Power Program
- 500
- Calculated sensitivity †
- 96.3dB
- High limit
- 3000Hz
- Manufacturer sensitivity
- 97.5dB
- Min. impedance
- 6.3Ω
- Voice coil
- 65mm
- Weight
- 2.1kg
