Overview
LF Driver
RCF
RCF MB15N351
RCF MB15N351 is a 15" 8 ohm LF driver rated at 650W RMS. The validated T/S data includes Fs 42Hz, Qts 0.22, Vas 191L, Xmax 6mm, sensitivity 99.7dB, plus 540cm³ Vd and 175 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £261.07.
Size
15"
Impedance
8Ω
RMS Power
650W
Sensitivity
99.7dB
EBP
175
Vented alignment
Vd
540cm³
T/S Parameters
Valid
Fs42Hz
Qts0.22
Qes0.24
Qms4.0
Vas191.0L
Re5.6Ω
Le1.65mH
BL22.5Tm
Sd900cm²
Mms80g
Xmax6.0mm
SPL100dB
Power650W
Impedance8Ω
Min Impedance6.8Ω
F Low40Hz
F High3000Hz
Voice Coil89mm
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorthomann
Updated 11 Sept 2026
Source: inc VAT · 20%
£299.00
inc VAT
In stock2–3 weeks
Best current price
Updated 11 Sept 2026
bluearan
£261.07
inc VAT·approx 2 months
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight5.2kg
Diameter393.0mm
Cutout Diameter354.0mm
Bolt Circle Diameter376.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
RCF
MB15N351
15"
Best current price
£261.07
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
63%
Similarity
60% cheaper£103.54
Dayton Audio
PA380-8
15"
Lower price
Xmax5mm-17%
Qts0.27+23%
BL25.8Tm+15%
Vas175L-8%
Qes0.27+13%
63%
Similarity
41% cheaper£153.00
B&C
15CL76
15"
Lower price
Xmax7mm+17%
Qts0.25+14%
BL19.1Tm-15%
Vas140L-27%
Qes0.27+13%
69%
Similarity
31% cheaper£181.02
B&C
15FW76
15"
Lower price
Xmax7mm+17%
Qts0.21-5%
BL26.2Tm+16%
Vas138L-28%
Qes0.22-8%
90%
Similarity
29% cheaper£184.99
B&C
15NDL76
15"
Lower price
Xmax7mm+17%
Qts0.220%
BL22.5Tm0%
Vas195L+2%
Qes0.240%
74%
Similarity
27% cheaper£191.58
B&C
15PLB76
15"
Lower price
Xmax5mm-17%
Qts0.25+14%
BL22.1Tm-2%
Vas164L-14%
Qes0.26+8%
76%
Similarity
26% cheaper£193.05
Eighteen Sound
15W930
15"
Lower price
Xmax7.5mm+25%
Qts0.220%
BL22.1Tm-2%
Vas240L+26%
Qes0.23-4%
40%
Similarity
18% cheaper£215.00
Precision Devices
PD.154/2
15"
Lower price
Xmax7.7mm+28%
Qts0.27+23%
BL29.4Tm+31%
Vas114.9L-40%
Qes0.27+13%
58%
Similarity
16% cheaper£219.28
RCF
MB15N405
15"
Lower price
Xmax7mm+17%
Qts0.27+23%
BL23.5Tm+4%
Vas124L-35%
Qes0.28+17%
80%
Similarity
2% more£266.78
Eighteen Sound
15ND930
15"
Higher price
Xmax7.5mm+25%
Qts0.220%
BL23.8Tm+6%
Vas206L+8%
Qes0.23-4%
74%
Similarity
10% more£285.89
Eighteen Sound
15NMB1000
15"
Higher price
Xmax6.5mm+8%
Qts0.24+9%
BL25.2Tm+12%
Vas124L-35%
Qes0.240%
70%
Similarity
74% more£453.72
RCF
CX15N351
15"
Higher price
Xmax6mm0%
Qts0.26+18%
BL23.5Tm+4%
Vas110L-42%
Qes0.27+13%
86%
Similarity
Precision Devices
PD.153ER/2
15"
Xmax5.7mm-5%
Qts0.21-5%
BL22.4Tm0%
Vas218.8L+15%
Qes0.22-8%
