Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespOberton 15XL601 8Ω
LF DriverMedia
Auto-advancing
Overview
LF Driver15XL series
Oberton
Oberton 15XL601
Oberton 15XL601 is a 15" 8 ohm LF driver rated at 600W RMS. The validated T/S data includes Fs 41Hz, Qts 0.22, Vas 150.3L, Xmax 5.3mm, sensitivity 98.7dB, plus 436cm³ Vd and 186 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
15"
Impedance
8Ω
RMS Power
600W
Sensitivity
98.7dB
200.0dBmanufacturer; using T/S-derived value (101.3dB delta).
EBP
186
Vented alignment
Vd
436cm³
T/S Parameters
Valid
Fs41Hz
Qts0.22
Qes0.22
Qms10.9
Vas150.3L
Re5.4Ω
Le1.09mH
BL24.7Tm
Sd830cm²
Mms97g
Xmax5.3mm
SPL99dB
Power600W
Impedance8Ω
Min Impedance6.7Ω
F Low50Hz
F High3000Hz
Voice Coil100mm
Flux Density1.25T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight10.8kg
Diameter388.0mm
Overall Depth181.0mm
Cutout Diameter355.0mm
Bolt Circle Diameter372.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Oberton
15XL601
15"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
100%
Similarity
Oberton
15XL600
15"
Xmax5.3mm0%
Qts0.220%
BL24.7Tm0%
Vas150.3L0%
Qes0.220%
78%
Similarity
BMS
15S420
15"
Xmax5mm-5%
Qts0.25+16%
BL25.5Tm+3%
Vas152L+1%
Qes0.26+18%
76%
Similarity
Precision Devices
PD.153ER/2
15"
Xmax5.7mm+9%
Qts0.21-3%
BL22.4Tm-9%
Vas218.8L+46%
Qes0.220%
76%
Similarity
Oberton
15MB601
15"
Xmax5.5mm+5%
Qts0.18-14%
BL27.1Tm+10%
Vas139L-8%
Qes0.19-14%
75%
Similarity
£261.07
RCF
MB15N351
15"
Xmax6mm+14%
Qts0.22+2%
BL22.5Tm-9%
Vas191L+27%
Qes0.24+9%
73%
Similarity
Oberton
15NMB600
15"
Xmax5.3mm0%
Qts0.17-19%
BL27.4Tm+11%
Vas145.2L-3%
Qes0.18-19%
73%
Similarity
Oberton
15NMB601
15"
Xmax5.3mm0%
Qts0.17-19%
BL27.4Tm+11%
Vas145.2L-3%
Qes0.18-19%
72%
Similarity
£191.58
B&C
15PLB76
15"
Xmax5mm-5%
Qts0.25+16%
BL22.1Tm-11%
Vas164L+9%
Qes0.26+18%
70%
Similarity
£285.89
Eighteen Sound
15NMB1000
15"
Xmax6.5mm+24%
Qts0.24+11%
BL25.2Tm+2%
Vas124L-18%
Qes0.24+9%
69%
Similarity
Peerless
FSL-1530R01-08
15"
Xmax4.7mm-11%
Qts0.24+11%
BL21.8Tm-12%
Vas180L+20%
Qes0.25+15%
67%
Similarity
BMS
15N820
15"
Xmax4.5mm-14%
Qts0.26+20%
BL24.2Tm-2%
Vas159L+6%
Qes0.27+23%
59%
Similarity
£453.72
RCF
CX15N351
15"
Xmax6mm+14%
Qts0.26+20%
BL23.5Tm-5%
Vas110L-27%
Qes0.27+23%
