Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespFaitalPRO 10FE300 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverFE series
FaitalPRO
FaitalPRO 10FE300
FaitalPRO 10FE300 is a 10" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 50Hz, Qts 0.52, Vas 50.5L, Xmax 5.5mm, sensitivity 92.7dB, plus 198cm³ Vd and 93 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £67.00.
Size
10"
Impedance
8Ω
RMS Power
250W
Sensitivity
92.7dB
96.0dBmanufacturer; using T/S-derived value (3.3dB delta).
EBP
93
Either alignment
Vd
198cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
0 degrees98 ptsp1medium
45 degrees240 ptsp1medium
Curve provenanceInspect 3 tracesHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
0 degrees
Frequency response
98 plotted pointsMedium confidence637 selected pixels of 1,341 - Trace datasheet-response-trace-poc/v1
45 degrees
Frequency response
240 plotted pointsMedium confidence1,633 selected pixels of 1,633 - Trace datasheet-response-trace-poc/v1
impedance
Impedance response
240 plotted pointsMedium confidence1,410 selected pixels of 1,410
T/S Parameters
Valid
Fs50Hz
Qts0.52
Qes0.54
Qms13.1
Vas50.5L
Re5.8Ω
Le0.60mH
BL11.3Tm
Sd358cm²
Mms36g
Xmax5.5mm
SPL93dB
Power250W
Impedance8Ω
F Low50Hz
F High4000Hz
Pricing & availability
Price definitionsPrice movement
Other offers
2 vendorsleanaudio
Updated 11 Sept 2026· 8Ω
Source: inc VAT · 20%
£67.00
inc VAT
2 in stock
partsexpress
Updated 11 Sept 2026· 8Ω
Source: ex VAT
£105.03
inc VAT
6 in stock
Best current price
Updated 11 Sept 2026
bluearan
£67.00
Avg £79.68£12.68 below avg (-15.9%)
inc VAT
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.2kg
Diameter260.0mm
Overall Depth110.0mm
Cutout Diameter233.0mm
Bolt Circle Diameter246.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
FaitalPRO
10FE300
10"
Best current price
£67.00
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
59%
Similarity
50% cheaper£33.27
Dayton Audio
PCS10-4
10"
Lower price
Xmax5.6mm+1%
Qts0.64+23%
BL9.1Tm-19%
Vas49L-3%
Qes0.73+35%
42%
Similarity
24% cheaper£50.73
SB Audience
BIANCO-10MW150
10"
Lower price
Xmax5.6mm+2%
Qts0.39-25%
BL15.1Tm+34%
Vas25.8L-49%
Qes0.4-26%
82%
Similarity
17% cheaper£55.28
FaitalPRO
10FE400
10"
Lower price
Xmax5.4mm-2%
Qts0.47-10%
BL11.5Tm+2%
Vas35.3L-30%
Qes0.52-4%
66%
Similarity
17% cheaper£55.46
Dayton Audio
PA255-8
10"
Lower price
Xmax5mm-9%
Qts0.61+17%
BL10.6Tm-6%
Vas41.2L-18%
Qes0.66+22%
73%
Similarity
17% cheaper£55.54
Lavoce
WSF102.00
10"
Lower price
Xmax5.2mm-6%
Qts0.45-13%
BL11.6Tm+3%
Vas34L-33%
Qes0.48-11%
56%
Similarity
14% cheaper£57.63
PRV Audio
10W650A
10"
Lower price
Xmax4.5mm-18%
Qts0.46-12%
BL14.1Tm+25%
Vas34L-33%
Qes0.47-13%
52%
Similarity
14% cheaper£57.63
PRV Audio
10W650A-4
10"
Lower price
Xmax4mm-28%
Qts0.39-25%
BL11.2Tm-1%
Vas41.2L-18%
Qes0.4-26%
78%
Similarity
5% cheaper£63.54
PRV Audio
10MR650A
10"
Lower price
Xmax5.7mm+4%
Qts0.47-10%
BL12.3Tm+8%
Vas41.9L-17%
Qes0.48-11%
Image unavailable
61%
Similarity
52% more£101.72
Eminence
DELTA-10A-2
10"
Higher price
Xmax6.4mm+16%
Qts0.44-15%
BL12.2Tm+8%
Vas29.7L-41%
Qes0.48-11%
61%
Similarity
112% more£141.89
Lavoce
CSF102.50K
10"
Higher price
Xmax6.3mm+13%
Qts0.45-13%
BL12.9Tm+14%
Vas29.9L-41%
Qes0.48-11%
65%
Similarity
146% more£165.00
Celestion
FTX1025
10"
Higher price
Xmax5mm-9%
Qts0.44-15%
BL12.3Tm+9%
Vas25.9L-49%
Qes0.52-3%
52%
Similarity
254% more£237.42
B&C
10FCX64
10"
Higher price
Xmax6mm+9%
Qts0.42-19%
BL13.4Tm+19%
Vas25L-50%
Qes0.44-19%
