Eminence FS10.20A8 8Ω
8 Ω · 60–4000 Hz
No current price
- Fs
- 56Hz
- Xmax
- 5.5mm
- SPL
- 94dB
- Pe
- 250W
- BL
- 10.4T·m
- Vd
- 191cm³
- Qts
- 0.48
- Vas
- 45L
Eminence FS10.20A8 is a 10-inch 8 ohm LF driver rated at 250 W RMS. The validated T/S data includes Fs 56 Hz, Qts 0.48, Vas 45 L, Xmax 5.5 mm, sensitivity 93.7 dB, plus 191 cm³ Vd and 104 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 56Hz
- Qts
- 0.48
- Qes
- 0.54
- Qms
- 4.2
- Vas
- 45L
- Re
- 5.4Ω
- Le
- 0.53mH
Motor and cone
- BL
- 10.4T·m
- Sd
- 346cm²
- Mms
- 30g
- Xmax
- 5.5mm
- Vd †
- 191cm³
Power and response
- Sensitivity †
- 93.7dB
- Manufacturer sensitivity
- 94.7dB
- Power
- 250W
- Impedance
- 8Ω
- Range
- 60–4000Hz
- EBP †
- 104 · Leans vented
Size and mounting
- Diameter
- 256.5mm
- Cutout
- 233.7mm
- Depth
- 111.8mm
- Weight
- 3.4kg
Other published values
- Power Program
- 500
Sensitivity shows 93.7 dB, calculated from the T/S values. Eminence publishes 94.7 dB, 1.0 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Eminence lists
LF · Primary · 10″
- BL
- 10.4T·m
- Fs
- 56Hz
- Le
- 0.53mH
- Re
- 5.4Ω
- Sd
- 346cm²
- Mms
- 30g
- Qes
- 0.54
- Qms
- 4.2
- Qts
- 0.48
- SPL
- 93.7dB
- Vas
- 45L
- Xmax
- 5.5mm
- Power
- 250W
- Impedance
- 8Ω
- Sensitivity
- 94.7dB
- Low limit
- 60Hz
- Power Program
- 500
- Calculated sensitivity †
- 93.7dB
- High limit
- 4000Hz
- Manufacturer sensitivity
- 94.7dB
- Weight
- 3.4kg
- Diameter
- 256.5mm
- Depth
- 111.8mm
- Cutout
- 233.7mm
