LavoceWSF101.70G
£47.14 · 15% less, betterFs78 Hz +20%, worse
Qts0.50 +11%, worse
Vas36 L +6%
BL11.9 T·m –
Xmax2.7 mm −48%, worse
Sensitivity97.1 dB +2.2, better
10-inch LF driver · WSF102 series · 51 mm voice coil · 175 W
Lavoce WSF102.00 8Ω
8 Ω · 60–4000 Hz
£55.54
SteadyBlue Aran · 3 in stock · All 3 offers
- Fs
- 65Hz
- Xmax
- 5.2mm
- SPL
- 95dB
- Pe
- 175W
- BL
- 11.6T·m
- Vd
- 182cm³
- Qts
- 0.45
- Vas
- 34L
Lavoce WSF102.00 is a 10-inch 8 ohm LF driver rated at 175 W RMS. The validated T/S data includes Fs 65 Hz, Qts 0.45, Vas 34.0 L, Xmax 5.2 mm, sensitivity 94.9 dB, plus 182 cm³ Vd and 135 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £55.54.
The published T/S values agree with each other
Thiele/Small
- Fs
- 65Hz
- Qts
- 0.45
- Qes
- 0.48
- Qms
- 5.7
- Vas
- 34.0L
- Re
- 5.2Ω
- Le
- 0.50mH
Motor and cone
- BL
- 11.6T·m
- Sd
- 350cm²
- Mms
- 30g
- Xmax
- 5.2mm
- Vd †
- 182cm³
- Voice coil
- 51mm
Power and response
- Sensitivity †
- 94.9dB
- Manufacturer sensitivity
- 97dB
- Power
- 175W
- Impedance
- 8Ω
- Min. impedance
- 5.9Ω
- Range
- 60–4000Hz
- EBP †
- 135 · Leans vented
Size and mounting
- Weight
- 3.2kg
Other published values
- Cms
- 0.20mm/N
- Xmech
- 9.4
- Power Program
- 350
Sensitivity shows 94.9 dB, calculated from the T/S values. Lavoce publishes 97.0 dB, 2.1 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 10″
- BL
- 11.6T·m
- Fs
- 65Hz
- Le
- 0.50mH
- Re
- 5.2Ω
- Sd
- 350cm²
- Cms
- 0.20mm/N
- Mms
- 30g
- Qes
- 0.48
- Qms
- 5.7
- Qts
- 0.45
- SPL
- 94.9dB
- Vas
- 34.0L
- Xmax
- 5.2mm
- Xmech
- 9.4
- Power
- 175W
- Impedance
- 8Ω
- Sensitivity
- 97dB
- Low limit
- 60Hz
- Power Program
- 350
- Calculated sensitivity †
- 94.9dB
- High limit
- 4000Hz
- Manufacturer sensitivity
- 97dB
- Min. impedance
- 5.9Ω
- Voice coil
- 51mm
- Weight
- 3.2kg
02
Compare
Same-size drivers, compared with the WSF102.00. Clear differences are green when better and red when worse.
This driverWSF102.00
Best price
£55.54
Fs
65 Hz
Qts
0.45
Vas
34.0 L
BL
11.6 T·m
Xmax
5.2 mm
Sensitivity
94.9 dB
Power
175 W
PRV Audio10MR650A
£63.52 · 14% more, worseFs65 Hz –
Qts0.47 +4%
Vas41.9 L +23%, worse
BL12.3 T·m +5%
Xmax5.7 mm +10%
Sensitivity95.8 dB +0.9
FaitalPRO10FE400
£66.15 · 19% more, worseFs60 Hz −8%
Qts0.47 +4%
Vas35.3 L +4%
BL11.5 T·m –
Xmax5.4 mm +4%
Sensitivity93.7 dB −1.2
CIAREPWA10.50
£82.89 · 49% more, worseFs57 Hz −12%, better
Qts0.40 −11%, better
Vas39.9 L +17%, worse
BL11.4 T·m –
Xmax5.8 mm +12%, better
Sensitivity94.2 dB −0.7
B&C10CL51
£84.00 · 51% more, worseFs58 Hz −11%, better
Qts0.38 −16%, better
Vas36 L +6%
BL11.6 T·m –
Xmax5.5 mm +6%
Sensitivity94.3 dB −0.6
Eighteen Sound10W400
£99.70 · 80% more, worseFs70 Hz +8%
Qts0.40 −11%, better
Vas31 L −9%
BL11.7 T·m –
Xmax5.5 mm +6%
Sensitivity95.9 dB +1
PeerlessSDF-250F75PR01-06
£117.82 · 112% more, worseFs34 Hz −48%, better
Qts0.46 –
Vas32.9 L −3%
BL14.6 T·m +26%, better
Xmax15.3 mm +194%, better
Sensitivity86.3 dB −8.6, worse
Dayton AudioDCS255-4
£121.33 · 118% more, worseFs38 Hz −42%, better
Qts0.46 –
Vas32.1 L −6%
BL12.6 T·m +8%
Xmax8.3 mm +60%, better
Sensitivity87.4 dB −7.5, worse
LavoceCSF102.50K
£141.89 · 155% more, worseFs65 Hz –
Qts0.45 –
Vas29.9 L −12%, better
BL12.9 T·m +11%, better
Xmax6.3 mm +20%, better
Sensitivity94.4 dB −0.5
Eighteen Sound10W650
£143.18 · 158% more, worseFs67 Hz +3%
Qts0.48 +7%
Vas26 L −24%, better
BL12.4 T·m +7%
Xmax5.7 mm +10%
Sensitivity93.9 dB −1
CelestionFTX1025
£165.00 · 197% more, worseFs72 Hz +10%, worse
Qts0.44 –
Vas25.9 L −24%, better
BL12.3 T·m +6%
Xmax5 mm −4%
Sensitivity94.6 dB –
SB AudienceROSSO-10CX300
£174.95 · 215% more, worseFs58 Hz −11%, better
Qts0.45 –
Vas40.5 L +19%, worse
BL11.9 T·m –
Xmax8.2 mm +58%, better
Sensitivity94.2 dB −0.7
B&C10FCX64
£237.42 · 327% more, worseFs63 Hz −3%
Qts0.42 −7%
Vas25 L −27%, better
BL13.4 T·m +15%, better
Xmax6 mm +15%, better
Sensitivity93.6 dB −1.3
WavecorSW280WA03
£241.98 · 336% more, worseFs35 Hz −47%, better
Qts0.46 –
Vas29.7 L −13%, better
BL12.5 T·m +8%
Xmax6 mm +15%, better
Sensitivity86.1 dB −8.8, worse
WavecorSW280WA04
£241.98 · 336% more, worseFs34 Hz −48%, better
Qts0.45 –
Vas30.5 L −10%, better
BL15.5 T·m +33%, better
Xmax6 mm +15%, better
Sensitivity86.1 dB −8.8, worse
Dayton AudioRSS265HO-44
£293.02 · 428% more, worseFs28 Hz −58%, better
Qts0.45 –
Vas34.8 L –
BL9.4 T·m −19%, worse
Xmax13.3 mm +155%, better
Sensitivity83.7 dB −11.2, worse
WavecorSW280WA01
£408.94 · 636% more, worseFs27 Hz −59%, better
Qts0.41 −9%
Vas41.4 L +22%, worse
BL13.4 T·m +15%, better
Xmax6 mm +15%, better
Sensitivity84.5 dB −10.4, worse
CIARENDI10
No current priceFs57 Hz −12%, better
Qts0.45 –
Vas35 L –
BL12.6 T·m +8%
Xmax4.5 mm −13%, worse
Sensitivity93.2 dB −1.7
JensenBS10N250A-8
No current priceFs58 Hz −11%, better
Qts0.43 −4%
Vas30.9 L −9%
BL12.9 T·m +11%, better
Xmax5 mm −4%
Sensitivity93.2 dB −1.7
LavoceFBASS10-18
No current priceFs65 Hz –
Qts0.43 −4%
Vas32.4 L −5%
BL12.5 T·m +7%
Xmax4.5 mm −13%, worse
Sensitivity94.7 dB –
PRV Audio10W650A
No current priceFs72 Hz +11%, worse
Qts0.46 –
Vas34.0 L –
BL14.1 T·m +21%, better
Xmax4.5 mm −13%, worse
Sensitivity96.4 dB +1.5
CelestionTF1018
No current priceFs70 Hz +8%
Qts0.41 −9%
Vas33.8 L –
BL11.6 T·m –
Xmax2 mm −62%, worse
Sensitivity95.8 dB +0.9
No photo
PHL Audio3020
No current priceFs60 Hz −8%
Qts0.38 −16%, better
Vas36.8 L +8%
BL12.8 T·m +10%, better
Xmax5 mm −4%
Sensitivity94.9 dB –
No photo
PHL Audio3005NDU
No current priceFs53 Hz −18%, better
Qts0.46 –
Vas31.8 L −7%
BL12.6 T·m +8%
Xmax9 mm +73%, better
Sensitivity91.8 dB −3.1, worse
EminenceFS10.20A8
No current priceFs56 Hz −14%, better
Qts0.48 +7%
Vas45 L +32%, worse
BL10.4 T·m −10%, worse
Xmax5.5 mm +6%
Sensitivity93.7 dB −1.2
Oberton10M150
No current priceFs74 Hz +14%, worse
Qts0.43 −4%
Vas25.9 L −24%, better
BL11.6 T·m –
Xmax3.3 mm −38%, worse
Sensitivity95.7 dB +0.8
CIARECMI250
No current priceFs55 Hz −15%, better
Qts0.50 +11%, worse
Vas34 L –
BL9 T·m −23%, worse
Xmax4.5 mm −13%, worse
Sensitivity92.4 dB −2.5, worse
CIARECMI250ND
No current priceFs59 Hz −9%
Qts0.50 +11%, worse
Vas34 L –
BL9 T·m −23%, worse
Xmax4.5 mm −13%, worse
Sensitivity93.3 dB −1.6
CelestionTF1020RE
No current priceFs53 Hz −19%, better
Qts0.39 −14%, better
Vas44.5 L +31%, worse
BL12.0 T·m +4%
Xmax5.9 mm +13%, better
Sensitivity93.6 dB −1.3
PRV Audio10MR650A-4
No current priceFs62 Hz −4%
Qts0.39 −13%, better
Vas44 L +29%, worse
BL10.0 T·m −14%, worse
Xmax5.2 mm –
Sensitivity96.2 dB +1.3
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Blue Aran | £55.54, the lowest price | 3 in stock | Visit shop at Blue Aran | |
Parts Express Import VAT and duty may apply | £63.58 | 15% above the lowest price | 2 in stock | Visit shop at Parts Express |
Best price over time
Tracked since 1 Apr
