Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespEminence DELTALITE 2510 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverDELTALITE series
Eminence
Eminence DELTALITE 2510
Eminence DELTALITE 2510 is a 10" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 53Hz, Qts 0.42, Vas 52.5L, Xmax 4.2mm, sensitivity 94.4dB, plus 147cm³ Vd and 118 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
10"
Impedance
8Ω
RMS Power
250W
Sensitivity
94.4dB
97.3dBmanufacturer; using T/S-derived value (2.9dB delta).
EBP
118
Vented alignment
Vd
147cm³
T/S Parameters
Valid
Fs53Hz
Qts0.42
Qes0.45
Qms5.8
Vas52.5L
Re5.1Ω
Le0.40mH
BL10.6Tm
Sd350cm²
Mms31g
Xmax4.2mm
SPL94dB
Power250W
Impedance8Ω
F Low60Hz
F High4000Hz
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight2.1kg
Diameter260.4mm
Overall Depth124.5mm
Cutout Diameter232.4mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eminence
DELTALITE 2510
10"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
79%
Similarity
£84.22
PRV Audio
10W650A-4
10"
Xmax4mm-5%
Qts0.39-7%
BL11.2Tm+6%
Vas41.2L-21%
Qes0.4-11%
74%
Similarity
£106.91
Eminence
BETA 10CX
10"
Xmax5mm+19%
Qts0.38-10%
BL10.9Tm+3%
Vas61.1L+16%
Qes0.41-9%
73%
Similarity
Lavoce
FBASS10-18
10"
Xmax4.5mm+7%
Qts0.43+2%
BL12.5Tm+18%
Vas32.4L-38%
Qes0.48+7%
70%
Similarity
Oberton
10CX
10"
Xmax4.3mm+1%
Qts0.38-10%
BL12.1Tm+14%
Vas32.3L-38%
Qes0.39-13%
70%
Similarity
PRV Audio
10MR650A-4
10"
Xmax5.2mm+24%
Qts0.39-7%
BL10Tm-6%
Vas44L-16%
Qes0.4-11%
70%
Similarity
CIARE
NDI10
10"
Xmax4.5mm+7%
Qts0.45+7%
BL12.6Tm+18%
Vas35L-33%
Qes0.49+9%
68%
Similarity
£167.63
Sica
10 FE 2.5 CP
10"
Xmax4mm-5%
Qts0.37-12%
BL12.8Tm+21%
Vas39.7L-24%
Qes0.4-11%
68%
Similarity
Oberton
10M150
10"
Xmax3.3mm-23%
Qts0.43+2%
BL11.6Tm+10%
Vas25.9L-51%
Qes0.450%
66%
Similarity
£79.75
CIARE
FXI10
10"
Xmax4.5mm+7%
Qts0.38-10%
BL13.3Tm+25%
Vas38.5L-27%
Qes0.41-9%
65%
Similarity
£55.54
Lavoce
WSF102.00
10"
Xmax5.2mm+24%
Qts0.45+7%
BL11.6Tm+10%
Vas34L-35%
Qes0.48+7%
65%
Similarity
Sica
10 N 2.5 PL
10"
Xmax4.5mm+7%
Qts0.36-14%
BL12.8Tm+21%
Vas40.9L-22%
Qes0.39-13%
64%
Similarity
PRV Audio
10MR650A-NDY
10"
Xmax3.5mm-17%
Qts0.38-10%
BL12.7Tm+20%
Vas40.7L-22%
Qes0.4-11%
