Overview
LF DriverBETA series
Eminence
Eminence BETA 10CX
Eminence BETA 10CX is a 10" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 49Hz, Qts 0.38, Vas 61.1L, Xmax 5mm, sensitivity 94.5dB, plus 172cm³ Vd and 120 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £82.50.
Size
10"
Impedance
8Ω
RMS Power
250W
Sensitivity
94.5dB
EBP
120
Vented alignment
Vd
172cm³
T/S Parameters
Valid
Fs49Hz
Qts0.38
Qes0.41
Qms6.2
Vas61.1L
Re5.5Ω
Le0.67mH
BL10.9Tm
Sd345cm²
Mms29g
Xmax5.0mm
SPL95dB
Power250W
Impedance8Ω
F Low60Hz
F High4000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£82.50
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.3kg
Diameter256.0mm
Overall Depth101.1mm
Cutout Diameter233.2mm
Bolt Circle Diameter245.4mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eminence
BETA 10CX
10"
Best current price
£82.50
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
53%
Similarity
33% cheaper£55.28
FaitalPRO
10FE400
10"
Lower price
Xmax5.4mm+8%
Qts0.47+24%
BL11.5Tm+6%
Vas35.3L-42%
Qes0.52+27%
62%
Similarity
33% cheaper£55.54
Lavoce
WSF102.00
10"
Lower price
Xmax5.2mm+4%
Qts0.45+18%
BL11.6Tm+7%
Vas34L-44%
Qes0.48+17%
47%
Similarity
29% cheaper£58.35
PRV Audio
10W650A
10"
Lower price
Xmax4.5mm-10%
Qts0.46+21%
BL14.1Tm+30%
Vas34L-44%
Qes0.47+15%
46%
Similarity
24% cheaper£63.00
Celestion
TF1020
10"
Lower price
Xmax4mm-20%
Qts0.32-15%
BL14.1Tm+30%
Vas28.8L-53%
Qes0.37-9%
53%
Similarity
22% cheaper£64.34
PRV Audio
10MR650A
10"
Lower price
Xmax5.7mm+14%
Qts0.47+24%
BL12.3Tm+13%
Vas41.9L-31%
Qes0.48+17%
54%
Similarity
20% cheaper£65.89
Dayton Audio
DS270-8
10"
Lower price
Xmax5.5mm+10%
Qts0.44+16%
BL10.1Tm-7%
Vas87.7L+44%
Qes0.54+32%
74%
Similarity
3% cheaper£79.75
CIARE
FXI10
10"
Lower price
Xmax4.5mm-10%
Qts0.380%
BL13.3Tm+22%
Vas38.5L-37%
Qes0.410%
73%
Similarity
£82.37
Dayton Audio
DSA270-8
10"
Xmax5.5mm+10%
Qts0.39+3%
BL11.2Tm+3%
Vas88.1L+44%
Qes0.47+15%
79%
Similarity
4% more£85.99
B&C
10CL51
10"
Higher price
Xmax5.5mm+10%
Qts0.380%
BL11.6Tm+7%
Vas36L-41%
Qes0.42+2%
38%
Similarity
18% more£97.30
PRV Audio
10MB800FT
10"
Higher price
Xmax3.5mm-30%
Qts0.32-16%
BL14.4Tm+32%
Vas36.7L-40%
Qes0.33-20%
Image unavailable
46%
Similarity
27% more£104.85
Eminence
DELTA-10A-2
10"
Higher price
Xmax6.4mm+28%
Qts0.44+16%
BL12.2Tm+12%
Vas29.7L-51%
Qes0.48+17%
58%
Similarity
33% more£109.82
FaitalPRO
10PR310
10"
Higher price
Xmax4.9mm-2%
Qts0.34-11%
BL14.4Tm+32%
Vas32.2L-47%
Qes0.36-12%
