10-inch LF driver · SBP series · 500 W
Acoustic Elegance SBP10-8 8Ω
8 Ω
No current price
- Fs
- 28Hz
- Xmax
- 14mm
- SPL
- 87dB
- Pe
- 500W
- BL
- 13.1T·m
- Vd
- 484cm³
- Qts
- 0.41
- Vas
- 63L
Acoustic Elegance SBP10-8 is a 10-inch 8 ohm LF driver rated at 500 W RMS. The validated T/S data includes Fs 28 Hz, Qts 0.41, Vas 62.8 L, Xmax 14 mm, sensitivity 87 dB, plus 484 cm³ Vd and 63 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 28Hz
- Qts
- 0.41
- Qes
- 0.45
- Qms
- 3.5
- Vas
- 62.8L
- Re
- 5.5Ω
- Le
- 0.30mH
Motor and cone
- BL
- 13.1T·m
- Sd
- 346cm²
- Mms
- 80g
- Xmax
- 14mm
- Vd †
- 484cm³
Power and response
- Sensitivity †
- 87dB
- Manufacturer sensitivity
- 87.2dB
- Power
- 500W
- Nominal power
- 500W
- Impedance
- 8Ω
- EBP †
- 63 · Sealed or vented
Other published values
- Cms
- 0.40mm/N
- Rms
- 4kg/s
- Xmech
- 18
† Calculated by bits from the published values
What this validation status means
Everything else Acoustic Elegance lists
LF · Primary · 10″
- BL
- 13.1T·m
- Fs
- 28Hz
- Le
- 0.30mH
- Re
- 5.5Ω
- Sd
- 346cm²
- Cms
- 0.40mm/N
- Mms
- 80g
- Qes
- 0.45
- Qms
- 3.5
- Qts
- 0.41
- Rms
- 4kg/s
- SPL
- 87dB
- Vas
- 62.8L
- Xmax
- 14mm
- Xmech
- 18
- Power
- 500W
- Impedance
- 8Ω
- Sensitivity
- 87.2dB
- Nominal power
- 500W
- Calculated sensitivity †
- 87dB
- Manufacturer sensitivity
- 87.2dB
