REDCATT 101NPM 8Ω
8 Ω
No price for delivery to the UK
- Fs
- 53Hz
- Xmax
- 3.3mm
- SPL
- 93dB
- Pe
- 150W
- BL
- 9.6T·m
- Vd
- 118cm³
- Qts
- 0.55
- Vas
- 50L
REDCATT 101NPM is a 10-inch 8 ohm LF driver rated at 150 W RMS. The validated T/S data includes Fs 53 Hz, Qts 0.55, Vas 49.7 L, Xmax 3.3 mm, sensitivity 92.9 dB, plus 118 cm³ Vd and 87 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £84.44.
The published T/S values agree with each other
Thiele/Small
- Fs
- 53Hz
- Qts
- 0.55
- Qes
- 0.61
- Qms
- 5.5
- Vas
- 49.7L
- Re
- 5Ω
- Le
- 0.53mH
Motor and cone
- BL
- 9.6T·m
- Sd
- 363cm²
- Mms
- 33g
- Xmax
- 3.3mm
- Vd †
- 118cm³
- Voice coil
- 51mm
Power and response
- Sensitivity †
- 92.9dB
- Manufacturer sensitivity
- 94.6dB
- Power
- 150W
- Impedance
- 8Ω
- EBP †
- 87 · Sealed or vented
Size and mounting
- Diameter
- 262mm
- Cutout
- 230mm
- Bolt circle
- 246mm
- Weight
- 2.0kg
Other published values
- Xmech
- 11.25
- Power Peak
- 600
Other dimensions
- Mounting Depth
- 111.5
Sensitivity shows 92.9 dB, calculated from the T/S values. REDCATT publishes 94.6 dB, 1.7 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 10″
- BL
- 9.6T·m
- Fs
- 53Hz
- Le
- 0.53mH
- Re
- 5Ω
- Sd
- 363cm²
- Mms
- 33g
- Qes
- 0.61
- Qms
- 5.5
- Qts
- 0.55
- SPL
- 92.9dB
- Vas
- 49.7L
- Xmax
- 3.3mm
- Xmech
- 11.25
- Power
- 150W
- Impedance
- 8Ω
- Power Peak
- 600
- Sensitivity
- 94.6dB
- Calculated sensitivity †
- 92.9dB
- Manufacturer sensitivity
- 94.6dB
- Voice coil
- 51mm
- Weight
- 2.0kg
- Diameter
- 262mm
- Mounting Depth
- 111.5
- Cutout
- 230mm
- Bolt circle
- 246mm
