PeerlessFSL-1020R02-08
£49.92Fs65 Hz −7%
Qts0.36 –
Vas38.5 L +60%, worse
BL13.6 T·m –
Xmax5.1 mm +27%, better
Sensitivity96.3 dB +1
10-inch LF driver · FS series · 250 W
Eminence FS10.25A8 8Ω
8 Ω · 70–2000 Hz
No current price
- Fs
- 70Hz
- Xmax
- 4mm
- SPL
- 95dB
- Pe
- 250W
- BL
- 14T·m
- Vd
- 139cm³
- Qts
- 0.37
- Vas
- 24L
Eminence FS10.25A8 is a 10-inch 8 ohm LF driver rated at 250 W RMS. The validated T/S data includes Fs 70 Hz, Qts 0.37, Vas 24 L, Xmax 4 mm, sensitivity 95.3 dB, plus 139 cm³ Vd and 179 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 70Hz
- Qts
- 0.37
- Qes
- 0.39
- Qms
- 6.8
- Vas
- 24L
- Re
- 4.8Ω
- Le
- 0.47mH
Motor and cone
- BL
- 14T·m
- Sd
- 346cm²
- Mms
- 36g
- Xmax
- 4mm
- Vd †
- 139cm³
Power and response
- Sensitivity †
- 95.3dB
- Manufacturer sensitivity
- 97.5dB
- Power
- 250W
- Impedance
- 8Ω
- Range
- 70–2000Hz
- EBP †
- 179 · Leans vented
Size and mounting
- Diameter
- 256.5mm
- Cutout
- 233.7mm
- Depth
- 114.3mm
- Weight
- 4.9kg
Other published values
- Power Program
- 500
Sensitivity shows 95.3 dB, calculated from the T/S values. Eminence publishes 97.5 dB, 2.2 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Eminence lists
LF · Primary · 10″
- BL
- 14T·m
- Fs
- 70Hz
- Le
- 0.47mH
- Re
- 4.8Ω
- Sd
- 346cm²
- Mms
- 36g
- Qes
- 0.39
- Qms
- 6.8
- Qts
- 0.37
- SPL
- 95.3dB
- Vas
- 24L
- Xmax
- 4mm
- Power
- 250W
- Impedance
- 8Ω
- Sensitivity
- 97.5dB
- Low limit
- 70Hz
- Power Program
- 500
- Calculated sensitivity †
- 95.3dB
- High limit
- 2000Hz
- Manufacturer sensitivity
- 97.5dB
- Weight
- 4.9kg
- Diameter
- 256.5mm
- Depth
- 114.3mm
- Cutout
- 233.7mm
02
