Overview
LF DriverFR series
Visaton
Visaton FR 10 WP
Visaton FR 10 WP is a 4" 4 ohm LF driver rated at 20W RMS. The validated T/S data includes Fs 120Hz, Qts 1.27, Vas 2.1L, Xmax 2mm, sensitivity 84.3dB, plus 10cm³ Vd and 56 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
4"
Impedance
4Ω
RMS Power
20W
Sensitivity
84.3dB
EBP
56
Either alignment
Vd
10cm³
T/S Parameters
Valid
Fs120Hz
Qts1.27
Qes2.14
Qms3.1
Vas2.1L
Re3.8Ω
Le0.30mH
BL2.8Tm
Sd50cm²
Mms5g
Xmax2.0mm
SPL84dB
Power20W
Impedance4Ω
F Low80Hz
F High16000Hz
Voice Coil20mm
Flux Density0.85T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.3kg
Diameter100.0mm
Cutout Diameter101.0mm
