10S-8

LF Driver
Simulate

Media

10S-8 view 1
10S-8 view 2
10S-8 view 3
10S-8 view 4
10S-8 view 5
10S-8 view 6
Auto-advancing

Overview

LF Driver
GRS

10S-8

Size
4"
Impedance
8Ω
RMS Power
25W
Sensitivity
87dB
EBP
72
Either alignment
Vd
8cm³
Datasheet

T/S Parameters

Valid
Manufacturer
Fs151Hz
Qts1.65
Qes2.10
Qms7.7
Vas1.8L
Re7.2Ω
Le0.21mH
BL2.8Tm
Sd53cm²
Mms2g
Xmax1.5mm
SPL87dB
Power25W
Impedance8Ω
F Low150Hz
F High20Hz
Voice Coil15mm

Pricing & availability

Price movement

Best current price

Updated 17 May 2026

soundimports
£9.48
inc VAT
Buy now

Dimensions & Physical

Diameter94.4mm
Overall Depth39.7mm
