Visaton R 10 SC SPEZIAL – 4″ 20W Woofer, 8 Ohm

Visaton R 10 SC SPEZIAL 8Ω

LF Driver

WatchWatch price SimSimulate

Media

Visaton R 10 SC SPEZIAL 4 inch 8 ohm loudspeaker driver view 1

Visaton R 10 SC SPEZIAL 4 inch 8 ohm loudspeaker driver view 2

Visaton R 10 SC SPEZIAL 4 inch 8 ohm loudspeaker driver view 3

Auto-advancing

Overview

LF DriverR series

Visaton R 10 SC SPEZIAL

Visaton R 10 SC SPEZIAL is a 4" 8 ohm LF driver rated at 20W RMS. The validated T/S data includes Fs 165Hz, Qts 1.76, Vas 2.3L, Xmax 1.5mm, sensitivity 88dB, plus 8cm³ Vd and 63 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

Size

4"

Impedance

8Ω

RMS Power

20W

Sensitivity

88.0dB

90.0dBmanufacturer; using T/S-derived value (2.0dB delta).

EBP

63

Either alignment

V_d

8cm³

T/S Parameters

Valid

Canonical

Fs165Hz

Qts1.76

Qes2.63

Qms5.3

Vas2.3L

Re7.4Ω

Le0.50mH

BL2.4Tm

Sd56cm²

Mms2g

Xmax1.5mm

SPL88dB

Power20W

Impedance8Ω

F Low100Hz

F High13000Hz

Voice Coil15mm

Flux Density0.95T

What this validation status means

Pricing & availability

Price definitions

No standard offers found

Check the manufacturer website for current pricing.

Use this driver

Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.

Files use canonical values. Required mechanical fields are derived only where the target format needs them.

Hornresp

.txt · Hornresp driver database

Driver file ready to place in Hornresp’s Drivers folder.

Download for Hornresp

WinISD

.wdr · WinISD driver editor

Native WinISD driver record with the required SI conversions.

Download for WinISD

BASTA!

.bastaelement · BASTA! loudspeaker simulator

Native BASTA! element file using its documented SI-unit fields.

Download for BASTA!

VituixCAD

.wdr · VituixCAD 2 Enclosure

A WinISD driver file that VituixCAD imports directly.

Download for VituixCAD

00 Simulator

Direct import · Web app

Start a new enclosure simulation with this driver already loaded.

Open in 00 Simulator

Copy spec sheet

Plain text · Clipboard

Copy the available values as a clean label-and-value list.

Dimensions & Physical

Weight0.2kg

Diameter100.0mm

Cutout Diameter93.0mm
