Overview
LF DriverSC series
Visaton
Visaton SC 8 N
Visaton SC 8 N is a 3.5" 8 ohm LF driver rated at 30W RMS. The validated T/S data includes Fs 110Hz, Qts 0.97, Vas 1.5L, Xmax 3mm, sensitivity 83.9dB, plus 8cm³ Vd and 84 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
3.5"
Impedance
8Ω
RMS Power
30W
Sensitivity
83.9dB
81.0dBmanufacturer; using T/S-derived value (2.9dB delta).
EBP
84
Either alignment
Vd
8cm³
T/S Parameters
Valid
Fs110Hz
Qts0.97
Qes1.31
Qms3.7
Vas1.5L
Re7.0Ω
Le0.30mH
BL2.4Tm
Sd26cm²
Mms2g
Xmax3.0mm
SPL84dB
Power30W
Impedance8Ω
F Low70Hz
F High20000Hz
Voice Coil20mm
Flux Density0.90T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.3kg
Diameter80.0mm
Cutout Diameter73.0mm
