Visaton FR 8 JS 8Ω

LF Driver
WatchWatch priceSimSimulate
  1. Home
  2. /Drivers
  3. /Visaton
  4. /FR 8 JS

Media

Visaton FR 8 JS 3.5 inch 8 ohm loudspeaker driver view 1
Visaton FR 8 JS 3.5 inch 8 ohm loudspeaker driver view 2
Visaton FR 8 JS 3.5 inch 8 ohm loudspeaker driver view 3
Visaton FR 8 JS 3.5 inch 8 ohm loudspeaker driver view 4
Auto-advancing

Overview

LF DriverFR series
Visaton

Visaton FR 8 JS

Visaton FR 8 JS is a 3.5" 8 ohm LF driver rated at 10W RMS. The validated T/S data includes Fs 130Hz, Qts 1.24, Vas 0.8L, Xmax 2mm, sensitivity 82.3dB, plus 6cm³ Vd and 75 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £10.54.

Size
3.5"
Impedance
8Ω
RMS Power
10W
Sensitivity
82.3dB
EBP
75
Either alignment
Vd
6cm³
Datasheet

Datasheet traces

Frequency and impedance curves traced from the manufacturer PDF.

2 curves
10798898071501002005001k2k5k10kHzdBfrequency response
frequency response240 ptsp1medium
Curve provenanceInspect 2 tracesHide details

These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works

  • frequency response

    Frequency response

    Trace datasheet-response-trace-poc/v2
    240 plotted pointsSource file SHA-256 198b6dd134e0…Medium confidence749 selected pixels of 1,764
    Manufacturer datasheet, page 1

  • impedance

    Impedance response

    Trace datasheet-response-trace-poc/v2
    240 plotted pointsSource file SHA-256 198b6dd134e0…Medium confidence738 selected pixels of 738
    Manufacturer datasheet, page 1

T/S Parameters

Valid
Canonical
Fs130Hz
Qts1.24
Qes1.74
Qms4.3
Vas0.8L
Re7.2Ω
Le0.60mH
BL2.8Tm
Sd30cm²
Mms2g
Xmax2.0mm
SPL82dB
Power10W
Impedance8Ω
F Low80Hz
F High20000Hz
Voice Coil15mm
Flux Density1.40T
What this validation status means

Pricing & availability

Price definitions

Price movement

Best current price

Updated 28 Sept 2026

RumoH
£10.54
inc VAT
Buy now

Use this driver

Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.

Files use canonical values. Required mechanical fields are derived only where the target format needs them.

Hornresp

.txt · Hornresp driver database

Driver file ready to place in Hornresp’s Drivers folder.

Download for Hornresp

WinISD

.wdr · WinISD driver editor

Native WinISD driver record with the required SI conversions.

Download for WinISD

BASTA!

.bastaelement · BASTA! loudspeaker simulator

Native BASTA! element file using its documented SI-unit fields.

Download for BASTA!

VituixCAD

.wdr · VituixCAD 2 Enclosure

A WinISD driver file that VituixCAD imports directly.

Download for VituixCAD

00 Simulator

Direct import · Web app

Start a new enclosure simulation with this driver already loaded.

Open in 00 Simulator

Copy spec sheet

Plain text · Clipboard

Copy the available values as a clean label-and-value list.

Dimensions & Physical

Weight0.2kg
Diameter80.0mm
Cutout Diameter75.0mm

Similar Drivers

Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.

Search Similar
Visaton FR 8 JS 3.5 inch 8 ohm loudspeaker driver similar-driver reference
Reference
Visaton
FR 8 JS
3.5"
Best current price
£10.54
Compare on

Matches sit inside every range. Size stays fixed automatically.

Qts
Qes
Vas
L
Xmax
mm
BL
Tm

5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.

12 matches

Compare a specific driver

Added drivers stay at the front of the list, whatever the ranges say.

Visaton FR 8 3.5 inch 8 ohm loudspeaker driver similar driver
74%
Similarity
1% cheaper£10.39
Visaton
FR 8
3.5"
Lower price
Xmax2mm0%
Qts1.09-12%
BL2.5Tm-10%
Vas0.7L-17%
Qes1.38-21%
Visaton FR 8 3.5 inch 4 ohm loudspeaker driver similar driver
60%
Similarity
1% cheaper£10.39
Visaton
FR 8
3.5"
Lower price
Xmax2mm0%
Qts1.05-15%
BL2.1Tm-24%
Vas0.6L-29%
Qes1.3-25%
Visaton FRS 8 3.5 inch 8 ohm loudspeaker driver similar driver
55%
Similarity
26% more£13.29
Visaton
FRS 8
3.5"
Higher price
Xmax2.5mm+25%
Qts1.04-16%
BL3.2Tm+16%
Vas0.9L+7%
Qes1.32-24%
Sica 3 L 0.8 SL 3 inch 8 ohm loudspeaker driver similar driver
53%
Similarity
161% more£27.49
Sica
3 L 0.8 SL
3"
Higher price
Xmax1.5mm-25%
Qts1.01-19%
BL2.8Tm+1%
Vas0.8L-5%
Qes1.28-26%
Visaton FR 8 JS - 8 Ohm 3.5 inch 8 ohm loudspeaker driver similar driver
100%
Similarity
Visaton
FR 8 JS - 8 Ohm
3.5"
Xmax2mm0%
Qts1.240%
BL2.8Tm0%
Vas0.8L0%
Qes1.740%
Visaton FR 87 3.5 inch 4 ohm loudspeaker driver similar driver
67%
Similarity
Visaton
FR 87
3.5"
Xmax2mm0%
Qts1.25+1%
BL2.1Tm-24%
Vas1.3L+55%
Qes1.56-10%
Visaton FR 87 - 4 OHM 3.5 inch 4 ohm loudspeaker driver similar driver
67%
Similarity
Visaton
FR 87 - 4 OHM
3.5"
Xmax2mm0%
Qts1.25+1%
BL2.1Tm-24%
Vas1.3L+55%
Qes1.56-10%
Visaton FR 8 - 4 OHM 3.5 inch 4 ohm loudspeaker driver similar driver
60%
Similarity
Visaton
FR 8 - 4 OHM
3.5"
Xmax2mm0%
Qts1.05-15%
BL2.1Tm-24%
Vas0.6L-29%
Qes1.3-25%
Visaton FRS 8 - 8 Ohm 3.5 inch 8 ohm loudspeaker driver similar driver
55%
Similarity
Visaton
FRS 8 - 8 Ohm
3.5"
Xmax2.5mm+25%
Qts1.04-16%
BL3.2Tm+16%
Vas0.9L+7%
Qes1.32-24%
SEAS H1600-08 FU10RB 4 inch 8 ohm loudspeaker driver similar driver
48%
Similarity
SEAS
H1600-08 FU10RB
4"
Xmax2mm0%
Qts0.96-23%
BL3.6Tm+29%
Vas1L+19%
Qes1.36-22%
Wavecor FR084OM02 3 inch 8 ohm loudspeaker driver similar driver
42%
Similarity
Wavecor
FR084OM02
3"
Xmax2.3mm+13%
Qts1.06-15%
BL3.4Tm+23%
Vas1.1L+29%
Qes1.2-31%
Wavecor FR070OM02 3 inch 8 ohm loudspeaker driver similar driver
39%
Similarity
Wavecor
FR070OM02
3"
Xmax2.5mm+25%
Qts1-19%
BL2.9Tm+5%
Vas0.6L-29%
Qes1.08-38%
