T/S Parameters
Valid
Fs51Hz
Qts0.35
Qes0.37
Qms7.6
Vas81.7L
Re5.7Ω
Le0.84mH
BL15.3Tm
Sd532cm²
Mms48g
Xmax4.6mm
SPL99dB
Power400W
Impedance8Ω
F Low52Hz
F High4000Hz
Pricing & availability
No standard offers found
Check the manufacturer website for current pricing.
Dimensions & Physical
Weight7.4kg
Diameter314.5mm
Overall Depth158.0mm
Cutout Diameter281.2mm
Bolt Circle Diameter296.9mm
Similar Drivers
Keep size fixed, then add or remove T/S params to change the ranking and the comparison rows.
Reference
Eminence
DELTA PRO
12"
