Dayton AudioDC160-8
£26.10 · Same priceFs36 Hz −61%, better
Qts0.34 –
Vas17.9 L +170%, worse
BL10.7 T·m –
Xmax3.1 mm −17%, worse
Sensitivity85.3 dB −8.1, worse
6.5-inch LF driver · WSF061 series · 38 mm voice coil · 125 W
Lavoce WSF061.52 8Ω
8 Ω · 90–5000 Hz
£26.27
SteadyBlue Aran · 14 in stock · All 1 offer
- Fs
- 91Hz
- Xmax
- 3.8mm
- SPL
- 93dB
- Pe
- 125W
- BL
- 10.8T·m
- Vd
- 54cm³
- Qts
- 0.34
- Vas
- 7L
Lavoce WSF061.52 is a 6.5-inch 8 ohm LF driver rated at 125 W RMS. The validated T/S data includes Fs 91 Hz, Qts 0.34, Vas 6.6 L, Xmax 3.8 mm, sensitivity 93.4 dB, plus 54 cm³ Vd and 253 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £26.27.
The published T/S values agree with each other
Thiele/Small
- Fs
- 91Hz
- Qts
- 0.34
- Qes
- 0.36
- Qms
- 5.4
- Vas
- 6.6L
- Re
- 5.5Ω
- Le
- 0.42mH
Motor and cone
- BL
- 10.8T·m
- Sd
- 143cm²
- Mms
- 13g
- Xmax
- 3.8mm
- Vd †
- 54cm³
- Voice coil
- 38mm
Power and response
- Sensitivity †
- 93.4dB
- Manufacturer sensitivity
- 95dB
- Power
- 125W
- Impedance
- 8Ω
- Min. impedance
- 6.4Ω
- Range
- 90–5000Hz
- EBP †
- 253 · Leans vented
Size and mounting
- Weight
- 2kg
Other published values
- Cms
- 0.23mm/N
- Xmech
- 6.3
- Power Program
- 250
Sensitivity shows 93.4 dB, calculated from the T/S values. Lavoce publishes 95.0 dB, 1.6 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 6.5″
- BL
- 10.8T·m
- Fs
- 91Hz
- Le
- 0.42mH
- Re
- 5.5Ω
- Sd
- 143cm²
- Cms
- 0.23mm/N
- Mms
- 13g
- Qes
- 0.36
- Qms
- 5.4
- Qts
- 0.34
- SPL
- 93.4dB
- Vas
- 6.6L
- Xmax
- 3.8mm
- Xmech
- 6.3
- Power
- 125W
- Impedance
- 8Ω
- Sensitivity
- 95dB
- Low limit
- 90Hz
- Power Program
- 250
- Calculated sensitivity †
- 93.4dB
- High limit
- 5000Hz
- Manufacturer sensitivity
- 95dB
- Min. impedance
- 6.4Ω
- Voice coil
- 38mm
- Weight
- 2kg
02
Compare
Same-size drivers, compared with the WSF061.52. Clear differences are green when better and red when worse.
This driverWSF061.52
Best price
£26.27
Fs
91 Hz
Qts
0.34
Vas
6.6 L
BL
10.8 T·m
Xmax
3.8 mm
Sensitivity
93.4 dB
Power
125 W
FaitalPRO6FE400
£37.20 · 42% more, worseFs100 Hz +10%
Qts0.36 +6%
Vas5 L −24%, better
BL10.5 T·m –
Xmax4.8 mm +26%, better
Sensitivity93 dB –
Beyma6CMV2
£40.92 · 56% more, worseFs90 Hz –
Qts0.34 –
Vas6.5 L –
BL9.4 T·m −13%, worse
Xmax5.7 mm +50%, better
Sensitivity92.3 dB −1.1
HiViF6
£41.87 · 59% more, worseFs45 Hz −51%, better
Qts0.35 –
Vas16.4 L +148%, worse
BL9 T·m −17%, worse
Xmax4.3 mm +13%, better
Sensitivity88 dB −5.4, worse
MonacorSPH-6M
£58.68 · 123% more, worseFs39 Hz −57%, better
Qts0.30 −12%, better
Vas17.6 L +166%, worse
BL9.7 T·m −10%, worse
Xmax4 mm +5%
Sensitivity86.8 dB −6.6, worse
CIAREFXI6
£62.87 · 139% more, worseFs70 Hz −23%, better
Qts0.33 –
Vas8 L +21%, worse
BL10.6 T·m –
Xmax5.3 mm +39%, better
Sensitivity90.7 dB −2.7, worse
PRV Audio6MB550FT
£67.09 · 155% more, worseFs85 Hz −7%
Qts0.34 –
Vas8.2 L +24%, worse
BL9.8 T·m −10%
Xmax5.4 mm +42%, better
Sensitivity93.3 dB –
B&C6MBX44
£74.45 · 183% more, worseFs113 Hz +24%, worse
Qts0.31 −9%
Vas4.1 L −38%, better
BL11.7 T·m +8%
Xmax3.5 mm −8%
Sensitivity94.4 dB +1
FaitalPRO6PR160
£82.98 · 216% more, worseFs90 Hz –
Qts0.33 –
Vas5.9 L −11%, better
BL11 T·m –
Xmax5 mm +32%, better
Sensitivity92.9 dB −0.5
FaitalPRO6PR150
£85.46 · 225% more, worseFs100 Hz +10%
Qts0.34 –
Vas4.9 L −26%, better
BL11.6 T·m +7%
Xmax2.6 mm −30%, worse
Sensitivity93.5 dB –
B&C6PS44
£86.62 · 230% more, worseFs71 Hz −22%, better
Qts0.33 –
Vas7 L +6%
BL11 T·m –
Xmax4.5 mm +18%, better
Sensitivity90.7 dB −2.7, worse
Beyma6P200FE
£88.47 · 237% more, worseFs66 Hz −27%, better
Qts0.35 –
Vas8.8 L +33%, worse
BL13.6 T·m +26%, better
Xmax4 mm +5%
Sensitivity90.3 dB −3.1, worse
B&C6PS38
£89.63 · 241% more, worseFs75 Hz −18%, better
Qts0.30 −12%, better
Vas8 L +21%, worse
BL10.8 T·m –
Xmax6 mm +58%, better
Sensitivity92.4 dB −1
Eighteen Sound6NMB420
£115.20 · 339% more, worseFs110 Hz +21%, worse
Qts0.33 –
Vas6.1 L −8%
BL9 T·m −17%, worse
Xmax3 mm −21%, worse
Sensitivity95.3 dB +1.9
Sica5.5 C 1.5 CP
£121.50 · 363% more, worseFs62 Hz −32%, better
Qts0.31 −9%
Vas5.4 L −18%, better
BL7.9 T·m −27%, worse
Xmax4 mm +5%
Sensitivity87.8 dB −5.6, worse
B&C6FHX51
£129.07 · 391% more, worseFs85 Hz −7%
Qts0.37 +9%
Vas5 L −24%, better
BL11.3 T·m +5%
Xmax5.7 mm +50%, better
Sensitivity90.9 dB −2.5, worse
FaitalPRO6HX150
£155.14 · 491% more, worseFs88 Hz −3%
Qts0.34 –
Vas6.3 L −5%
BL12 T·m +11%, better
Xmax4.3 mm +14%, better
Sensitivity92.9 dB −0.5
Eighteen Sound6NTLW2000
£157.59 · 500% more, worseFs86 Hz −5%
Qts0.35 –
Vas4.6 L −31%, better
BL11.6 T·m +7%
Xmax4.9 mm +29%, better
Sensitivity90.9 dB −2.5, worse
Sica6 N 2 PL
No current priceFs68 Hz −25%, better
Qts0.33 –
Vas8.7 L +31%, worse
BL9.5 T·m −12%, worse
Xmax3.5 mm −8%
Sensitivity90.8 dB −2.6, worse
Sica6 NR 2 PL
No current priceFs61 Hz −34%, better
Qts0.33 –
Vas9.4 L +42%, worse
BL9.9 T·m −9%
Xmax4 mm +5%
Sensitivity89.9 dB −3.5, worse
LavoceWSN061.52
No current priceFs90 Hz –
Qts0.39 +15%, worse
Vas5.9 L −11%, better
BL9.9 T·m −9%
Xmax3.8 mm –
Sensitivity92.1 dB −1.3
PRV Audio6MB550FT-4
No current priceFs86 Hz −5%
Qts0.34 –
Vas6.6 L –
BL8.6 T·m −20%, worse
Xmax5.4 mm +42%, better
Sensitivity92.9 dB −0.5
REDCATT61NPM
No current priceFs92 Hz –
Qts0.36 +6%
Vas7 L +6%
BL9.8 T·m −9%
Xmax2.3 mm −39%, worse
Sensitivity93.6 dB –
B&C6CLA51
No current priceFs96 Hz +5%
Qts0.32 −6%
Vas4.3 L −35%, better
BL11.4 T·m +5%
Xmax4.8 mm +26%, better
Sensitivity92.3 dB −1.1
Oberton6NCX
No current priceFs89 Hz –
Qts0.36 +7%
Vas7.0 L +6%
BL9 T·m −17%, worse
Xmax4.8 mm +25%, better
Sensitivity93.1 dB –
LavoceMAN062.00
No current priceFs103 Hz +13%, worse
Qts0.30 −12%, better
Vas4.1 L −39%, better
BL12.7 T·m +18%, better
Xmax3.9 mm –
Sensitivity93.3 dB –
BMS6CN160
No current priceFs79 Hz −13%, better
Qts0.34 –
Vas8.9 L +34%, worse
BL10 T·m −7%
Xmax5 mm +32%, better
Sensitivity92.7 dB −0.7
HiViD6.4MKII
No current priceFs53 Hz −42%, better
Qts0.35 –
Vas8.5 L +28%, worse
BL7.8 T·m −27%, worse
Xmax3.5 mm −8%
Sensitivity86.9 dB −6.5, worse
PurifiPTT6.5M08-NFA-01
No current priceFs52 Hz −43%, better
Qts0.34 –
Vas13.2 L +99%, worse
BL9.8 T·m −9%
Xmax2.9 mm −24%, worse
Sensitivity89 dB −4.4, worse
CelestionNTR06-17X
No current priceFs60 Hz −34%, better
Qts0.32 −6%
Vas13.2 L +99%, worse
BL10.4 T·m −4%
Xmax4.5 mm +18%, better
Sensitivity91.4 dB −2, worse
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Blue Aran | £26.27, the lowest price | 14 in stock | Visit shop at Blue Aran |
Best price over time
Tracked since 1 Apr
