8-inch LF driver · WAF082 series · 51 mm voice coil · 250 W
Lavoce WAF082.01 8Ω
8 Ω · 70–5000 Hz
No current price
- Fs
- 76Hz
- Xmax
- 5.8mm
- SPL
- 95dB
- Pe
- 250W
- BL
- 17.9T·m
- Vd
- 128cm³
- Qts
- 0.21
- Vas
- 10L
Lavoce WAF082.01 is an 8-inch 8 ohm LF driver rated at 250 W RMS. The validated T/S data includes Fs 76 Hz, Qts 0.21, Vas 10.2 L, Xmax 5.8 mm, sensitivity 95.1 dB, plus 128 cm³ Vd and 345 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 76Hz
- Qts
- 0.21
- Qes
- 0.22
- Qms
- 3.8
- Vas
- 10.2L
- Re
- 5.1Ω
- Le
- 0.11mH
Motor and cone
- BL
- 17.9T·m
- Sd
- 220cm²
- Mms
- 29g
- Xmax
- 5.8mm
- Vd †
- 128cm³
- Voice coil
- 51mm
Power and response
- Sensitivity †
- 95.1dB
- Manufacturer sensitivity
- 97dB
- Power
- 250W
- Impedance
- 8Ω
- Min. impedance
- 6.9Ω
- Range
- 70–5000Hz
- EBP †
- 345 · Leans vented
Size and mounting
- Weight
- 5.3kg
Other published values
- Cms
- 0.15mm/N
- Xmech
- 11.3
- Power Program
- 500
Sensitivity shows 95.1 dB, calculated from the T/S values. Lavoce publishes 97.0 dB, 1.9 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 8″
- BL
- 17.9T·m
- Fs
- 76Hz
- Le
- 0.11mH
- Re
- 5.1Ω
- Sd
- 220cm²
- Cms
- 0.15mm/N
- Mms
- 29g
- Qes
- 0.22
- Qms
- 3.8
- Qts
- 0.21
- SPL
- 95.1dB
- Vas
- 10.2L
- Xmax
- 5.8mm
- Xmech
- 11.3
- Power
- 250W
- Impedance
- 8Ω
- Sensitivity
- 97dB
- Low limit
- 70Hz
- Power Program
- 500
- Calculated sensitivity †
- 95.1dB
- High limit
- 5000Hz
- Manufacturer sensitivity
- 97dB
- Min. impedance
- 6.9Ω
- Voice coil
- 51mm
- Weight
- 5.3kg
