GRS10PT-8
£32.04 · 70% less, betterFs47 Hz −64%, better
Qts0.48 −17%, better
Vas46.2 L +255%, worse
BL13.4 T·m –
Xmax7.8 mm +887%, better
Sensitivity91.8 dB −7, worse
10-inch LF driver · CANNABIS REX series · 50 W
Eminence CANNABIS REX 10 8Ω
8 Ω · 80–5300 Hz
£106.00
SteadyLean Business · All 2 offers
- Fs
- 130Hz
- Xmax
- 0.8mm
- SPL
- 99dB
- Pe
- 50W
- BL
- 13.2T·m
- Vd
- 29cm³
- Qts
- 0.58
- Vas
- 13L
Eminence CANNABIS REX 10 is a 10-inch 8 ohm LF driver rated at 50 W RMS. The validated T/S data includes Fs 130 Hz, Qts 0.58, Vas 13.0 L, Xmax 0.8 mm, sensitivity 98.8 dB, plus 29 cm³ Vd and 217 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £106.00.
The published T/S values agree with each other
Thiele/Small
- Fs
- 130Hz
- Qts
- 0.58
- Qes
- 0.60
- Qms
- 15.4
- Vas
- 13.0L
- Re
- 6.3Ω
- Le
- 0.49mH
Motor and cone
- BL
- 13.2T·m
- Sd
- 366cm²
- Mms
- 20g
- Xmax
- 0.8mm
- Vd †
- 29cm³
Power and response
- Sensitivity †
- 98.8dB
- Manufacturer sensitivity
- 99.3dB
- Power
- 50W
- Impedance
- 8Ω
- Range
- 80–5300Hz
- EBP †
- 217 · Leans vented
Size and mounting
- Diameter
- 256.8mm
- Cutout
- 231.9mm
- Depth
- 101.6mm
- Weight
- 3.3kg
Other published values
- Cms
- 0.07mm/N
† Calculated by bits from the published values
What this validation status means
Everything else Eminence lists
LF · Primary · 10″
- BL
- 13.2T·m
- Fs
- 130Hz
- Le
- 0.49mH
- Re
- 6.3Ω
- Sd
- 366cm²
- Cms
- 0.07mm/N
- Mms
- 20g
- Qes
- 0.60
- Qms
- 15.4
- Qts
- 0.58
- SPL
- 98.8dB
- Vas
- 13.0L
- Xmax
- 0.8mm
- Power
- 50W
- Impedance
- 8Ω
- Sensitivity
- 99.3dB
- Low limit
- 80Hz
- Calculated sensitivity †
- 98.8dB
- High limit
- 5300Hz
- Manufacturer sensitivity
- 99.3dB
- Weight
- 3.3kg
- Diameter
- 256.8mm
- Depth
- 101.6mm
- Cutout
- 231.9mm
02
Compare
Same-size drivers, compared with the CANNABIS REX 10. Clear differences are green when better and red when worse.
This driverCANNABIS REX 10
Best price
£106.00
Fs
130 Hz
Qts
0.58
Vas
13.0 L
BL
13.2 T·m
Xmax
0.8 mm
Sensitivity
98.8 dB
Power
50 W
GRS10SMP-8
£38.74 · 63% less, betterFs29 Hz −78%, better
Qts0.58 –
Vas81 L +522%, worse
BL9.6 T·m −27%, worse
Xmax5 mm +533%, better
Sensitivity86.4 dB −12.4, worse
LavoceWSF101.70G
£47.05 · 56% less, betterFs78 Hz −40%, better
Qts0.50 −14%, better
Vas36 L +176%, worse
BL11.9 T·m −10%
Xmax2.7 mm +242%, better
Sensitivity97.1 dB −1.7
Dayton AudioPA255-8
£55.88 · 47% less, betterFs51 Hz −61%, better
Qts0.61 +5%
Vas41.2 L +216%, worse
BL10.6 T·m −19%, worse
Xmax5 mm +533%, better
Sensitivity91.1 dB −7.7, worse
LavoceSSF102.40
£56.92 · 46% less, betterFs39 Hz −70%, better
Qts0.57 –
Vas39.5 L +204%, worse
BL14.0 T·m +6%
Xmax8.3 mm +951%, better
Sensitivity87.9 dB −10.9, worse
SB AcousticsSB26SFCL38-8
£58.42 · 45% less, betterFs28 Hz −79%, better
Qts0.53 −9%
Vas107 L +722%, worse
BL9.6 T·m −27%, worse
Xmax8.2 mm +938%, better
Sensitivity87.7 dB −11.1, worse
EminenceALPHA-10A
£60.00 · 43% less, betterFs50 Hz −62%, better
Qts0.59 –
Vas82.2 L +531%, worse
BL7.5 T·m −43%, worse
Xmax3.2 mm +305%, better
Sensitivity94 dB −4.8, worse
PeerlessSLS-P830668
£66.85 · 37% less, betterFs35 Hz −73%, better
Qts0.59 –
Vas62.9 L +383%, worse
BL10.3 T·m −22%, worse
Xmax10.9 mm +1280%, better
Sensitivity88.2 dB −10.6, worse
FaitalPRO10FE300
£67.00 · 37% less, betterFs50 Hz −62%, better
Qts0.52 −10%, better
Vas50.5 L +288%, worse
BL11.3 T·m −14%, worse
Xmax5.5 mm +599%, better
Sensitivity92.7 dB −6.1, worse
REDCATT101NPM
£83.54 · 21% less, betterFs53 Hz −59%, better
Qts0.55 −5%
Vas49.7 L +282%, worse
BL9.6 T·m −27%, worse
Xmax3.3 mm +311%, better
Sensitivity92.9 dB −5.9, worse
EminenceBETA-10B
£88.07 · 17% less, betterFs52 Hz −60%, better
Qts0.51 −12%, better
Vas61.4 L +371%, worse
BL15.1 T·m +15%, better
Xmax3 mm +280%, better
Sensitivity93.7 dB −5.1, worse
EminenceRAGIN CAJUN
£91.87 · 13% less, betterFs84 Hz −35%, better
Qts0.51 −12%, better
Vas34.1 L +162%, worse
BL11.8 T·m −10%, worse
Xmax0.5 mm −39%, worse
Sensitivity97.8 dB −1
EminenceLIL' BUDDY
£99.00 · 7% less, betterFs149 Hz +15%, worse
Qts0.84 +45%, worse
Vas10 L −23%, better
BL11.7 T·m −11%, worse
Xmax0.8 mm –
Sensitivity97.5 dB −1.3
PeerlessGBS-250F38CP01-04
£117.75 · 11% more, worseFs38 Hz −71%, better
Qts0.51 −12%, better
Vas22.8 L +75%, worse
BL12.9 T·m –
Xmax9.2 mm +1061%, better
Sensitivity85.6 dB −13.2, worse
Dayton AudioDCS255-4
£121.10 · 14% more, worseFs38 Hz −71%, better
Qts0.46 −21%, better
Vas32.1 L +147%, worse
BL12.6 T·m −4%
Xmax8.3 mm +951%, better
Sensitivity87.4 dB −11.4, worse
Eighteen Sound10W650
£142.92 · 35% more, worseFs67 Hz −48%, better
Qts0.48 −17%, better
Vas26 L +100%, worse
BL12.4 T·m −6%
Xmax5.7 mm +622%, better
Sensitivity93.9 dB −4.9, worse
Dayton AudioUMII10-22
£200.54 · 89% more, worseFs39 Hz −70%, better
Qts0.57 –
Vas21.2 L +63%, worse
BL13.4 T·m –
Xmax20 mm +2432%, better
Sensitivity84.4 dB −14.4, worse
Dayton AudioRSS265HF-8
£213.37 · 101% more, worseFs25 Hz −81%, better
Qts0.49 −16%, better
Vas52.5 L +303%, worse
BL15 T·m +14%, better
Xmax14.3 mm +1710%, better
Sensitivity83.4 dB −15.4, worse
WavecorSW275BD01
£560.80 · 429% more, worseFs31 Hz −76%, better
Qts0.57 –
Vas31 L +138%, worse
BL12.1 T·m −8%
Xmax16 mm +1925%, better
Sensitivity83.9 dB −14.9, worse
P.Audio10NT-65MB
No current priceFs70 Hz −46%, better
Qts0.56 −3%
Vas18.5 L +42%, worse
BL15.4 T·m +17%, better
Xmax3.5 mm +343%, better
Sensitivity92.1 dB −6.7, worse
JensenJN10-100TR-8
No current priceFs82 Hz −37%, better
Qts0.58 –
Vas26 L +100%, worse
BL10.5 T·m −20%, worse
Xmax1 mm +27%, better
Sensitivity95.8 dB −3, worse
Cube AudioF10 SELECT V2
No current priceFs28 Hz −78%, better
Qts0.58 –
Vas185 L +1321%, worse
BL9.2 T·m −30%, worse
Xmax2.5 mm +216%, better
Sensitivity90.1 dB −8.7, worse
Acoustic EleganceIB10AU-8
No current priceFs25 Hz −81%, better
Qts0.48 −17%, better
Vas68 L +422%, worse
BL12.4 T·m −6%
Xmax18 mm +2178%, better
Sensitivity84.8 dB −14, worse
B&C10CLX64
No current priceFs70 Hz −46%, better
Qts0.63 +9%
Vas21 L +61%, worse
BL11.4 T·m −13%, worse
Xmax5.5 mm +596%, better
Sensitivity92.3 dB −6.5, worse
PRV Audio69MR500-PHP-4
No current priceFs92 Hz −29%, better
Qts0.65 +12%, worse
Vas15.2 L +16%, worse
BL6.8 T·m −48%, worse
Xmax2.9 mm +263%, better
Sensitivity94.4 dB −4.4, worse
Oberton10NCX1
No current priceFs68 Hz −48%, better
Qts0.41 −29%, better
Vas12.0 L −8%
BL12.0 T·m −9%
Xmax4.8 mm +501%, better
Sensitivity91.5 dB −7.3, worse
PeerlessFSL-1025R03-06
No current priceFs66 Hz −49%, better
Qts0.46 −21%, better
Vas18.1 L +39%, worse
BL14.3 T·m +9%
Xmax6.3 mm +694%, better
Sensitivity92.1 dB −6.7, worse
HiViD10G
No current priceFs26 Hz −80%, better
Qts0.46 −21%, better
Vas117.3 L +801%, worse
BL13.2 T·m –
Xmax8.3 mm +951%, better
Sensitivity88.2 dB −10.6, worse
Sica10 SR 2 CP
No current priceFs33 Hz −75%, better
Qts0.49 −16%, better
Vas73 L +461%, worse
BL10.8 T·m −18%, worse
Xmax7 mm +786%, better
Sensitivity88.7 dB −10.1, worse
No photo
PHL Audio3005NDU
No current priceFs53 Hz −59%, better
Qts0.46 −21%, better
Vas31.8 L +144%, worse
BL12.6 T·m −4%
Xmax9 mm +1039%, better
Sensitivity91.8 dB −7, worse
Tune the match
Choose the published values that matter to your design. Size stays matched to this driver.
Qts
Qes
VasL
Xmaxmm
BLTm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Lean Business | £106.00, the lowest price | Stock not listed | Visit shop at Lean Business |
Best price over time
Tracked since 1 Apr
