Eminence CANNABIS REX 10 8Ω

LF Driver
WatchWatch priceSimSimulate
  1. Home
  2. /Drivers
  3. /Eminence
  4. /CANNABIS REX 10

Media

Eminence CANNABIS REX 10 10 inch 8 ohm loudspeaker driver view 1
Eminence CANNABIS REX 10 10 inch 8 ohm loudspeaker driver view 2
Auto-advancing

Overview

LF DriverCANNABIS REX series
Eminence

Eminence CANNABIS REX 10

Eminence CANNABIS REX 10 is a 10" 8 ohm LF driver rated at 50W RMS. The validated T/S data includes Fs 130Hz, Qts 0.58, Vas 13.0L, Xmax 0.8mm, sensitivity 98.8dB, plus 29cm³ Vd and 217 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £106.00.

Size
10"
Impedance
8Ω
RMS Power
50W
Sensitivity
98.8dB
EBP
217
Vented alignment
Vd
29cm³

T/S Parameters

Valid
Canonical
Fs130Hz
Qts0.58
Qes0.60
Qms15.4
Vas13.0L
Re6.3Ω
Le0.49mH
BL13.2Tm
Sd366cm²
Mms20g
Xmax0.8mm
SPL99dB
Power50W
Impedance8Ω
F Low80Hz
F High5300Hz
What this validation status means

Pricing & availability

Price definitions

Price movement

Best current price

Updated 25 Sept 2026

leanbusiness
£106.00
inc VAT
Buy now

Use this driver

Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.

Files use canonical values. Required mechanical fields are derived only where the target format needs them.

Hornresp

.txt · Hornresp driver database

Driver file ready to place in Hornresp’s Drivers folder.

Download for Hornresp

WinISD

.wdr · WinISD driver editor

Native WinISD driver record with the required SI conversions.

Download for WinISD

BASTA!

.bastaelement · BASTA! loudspeaker simulator

Native BASTA! element file using its documented SI-unit fields.

Download for BASTA!

VituixCAD

.wdr · VituixCAD 2 Enclosure

A WinISD driver file that VituixCAD imports directly.

Download for VituixCAD

00 Simulator

Direct import · Web app

Start a new enclosure simulation with this driver already loaded.

Open in 00 Simulator

Copy spec sheet

Plain text · Clipboard

Copy the available values as a clean label-and-value list.

Dimensions & Physical

Weight3.3kg
Diameter256.8mm
Overall Depth101.6mm
Cutout Diameter231.9mm
