Overview
LF DriverLIL series
Eminence
Eminence LIL' BUDDY
Eminence LIL' BUDDY is a 10" 8 ohm LF driver rated at 50W RMS. The validated T/S data includes Fs 149Hz, Qts 0.84, Vas 10L, Xmax 0.8mm, sensitivity 97.5dB, plus 29cm³ Vd and 160 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £99.00.
Size
10"
Impedance
8Ω
RMS Power
50W
Sensitivity
97.5dB
98.8dBmanufacturer; using T/S-derived value (1.3dB delta).
EBP
160
Vented alignment
Vd
29cm³
T/S Parameters
Valid
Fs149Hz
Qts0.84
Qes0.93
Qms9.1
Vas10.0L
Re6.3Ω
Le0.46mH
BL11.7Tm
Sd366cm²
Mms22g
Xmax0.8mm
SPL98dB
Power50W
Impedance8Ω
F Low80Hz
F High5000Hz
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorleanaudio
Updated 25 Sept 2026· 8Ω
Source: inc VAT · 20%
£99.50
inc VAT
Out of stock
Best current price
Updated 25 Sept 2026
leanbusiness
£99.00
inc VAT
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight2.9kg
Diameter256.8mm
Overall Depth109.2mm
Cutout Diameter231.9mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eminence
LIL' BUDDY
10"
Best current price
£99.00
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
1 match
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
62%
Similarity
Jensen
JP10-100BB-8
10"
Xmax1mm+25%
Qts0.8-5%
BL10.4Tm-11%
Vas14.1L+41%
Qes0.89-4%
