Overview
LF DriverKappaLITE series
Eminence
Eminence KAPPALITE 3015LF
Eminence KAPPALITE 3015LF is a 15" 8 ohm LF driver rated at 450W RMS. The validated T/S data includes Fs 44Hz, Qts 0.46, Vas 150.9L, Xmax 9.6mm, sensitivity 96.3dB, plus 846cm³ Vd and 92 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £220.00.
Size
15"
Impedance
8Ω
RMS Power
450W
Sensitivity
96.3dB
98.4dBmanufacturer; using T/S-derived value (2.1dB delta).
EBP
92
Either alignment
Vd
846cm³
T/S Parameters
Valid
Fs44Hz
Qts0.46
Qes0.48
Qms9.0
Vas150.9L
Re5.5Ω
Le0.93mH
BL17.0Tm
Sd881cm²
Mms93g
Xmax9.6mm
SPL96dB
Power450W
Impedance8Ω
F Low40Hz
F High1000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£220.00
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.9kg
Diameter389.1mm
Overall Depth184.2mm
Cutout Diameter356.4mm
Bolt Circle Diameter369.8mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eminence
KAPPALITE 3015LF
15"
Best current price
£220.00
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
70%
Similarity
58% cheaper£93.10
SB Audience
BIANCO-15W200
15"
Lower price
Xmax8.5mm-11%
Qts0.54+17%
BL17Tm0%
Vas123.5L-18%
Qes0.57+19%
82%
Similarity
57% cheaper£94.10
SB Audience
BIANCO-15MW350
15"
Lower price
Xmax7.4mm-23%
Qts0.48+4%
BL16.9Tm-1%
Vas157.5L+4%
Qes0.49+2%
79%
Similarity
43% cheaper£126.45
SB Audience
BIANCO-15SW400
15"
Lower price
Xmax9.2mm-4%
Qts0.48+4%
BL19.8Tm+16%
Vas111.5L-26%
Qes0.49+2%
73%
Similarity
35% cheaper£143.24
RCF
L15P530
15"
Lower price
Xmax7mm-27%
Qts0.48+4%
BL15.3Tm-10%
Vas160L+6%
Qes0.51+6%
81%
Similarity
32% cheaper£149.39
Beyma
15MCS500
15"
Lower price
Xmax8mm-17%
Qts0.48+4%
BL17.6Tm+4%
Vas134L-11%
Qes0.5+4%
47%
Similarity
31% cheaper£152.08
RCF
L15P540
15"
Lower price
Xmax7mm-27%
Qts0.39-15%
BL21.4Tm+26%
Vas100L-34%
Qes0.41-15%
69%
Similarity
30% cheaper£155.00
Celestion
FTR15-3070E
15"
Lower price
Xmax7.8mm-19%
Qts0.38-18%
BL17.9Tm+5%
Vas145.8L-3%
Qes0.43-11%
55%
Similarity
26% cheaper£161.93
FaitalPRO
15HP1010
15"
Lower price
Xmax9.8mm+2%
Qts0.37-20%
BL22Tm+29%
Vas107.5L-29%
Qes0.38-21%
82%
Similarity
21% cheaper£173.88
Beyma
15MC500
15"
Lower price
Xmax8mm-17%
Qts0.45-2%
BL18.3Tm+8%
Vas134L-11%
Qes0.47-2%
55%
Similarity
21% cheaper£173.94
BishopSound
BDP15
15"
Lower price
Xmax12.2mm+27%
Qts0.42-9%
BL21.3Tm+25%
Vas103.4L-31%
Qes0.44-8%
67%
Similarity
20% cheaper£176.66
SB Audience
ROSSO-15SW800
15"
Lower price
Xmax11.3mm+18%
Qts0.460%
BL21.1Tm+24%
Vas87.6L-42%
Qes0.480%
69%
Similarity
18% cheaper£181.46
B&C
15FW88
15"
Lower price
Xmax8mm-17%
Qts0.43-7%
BL19.3Tm+13%
Vas103.7L-31%
Qes0.45-6%
