Overview
LF DriverTF series
Monacor
Monacor TF1525E/4
Monacor TF1525E/4 is a 15" 4 ohm LF driver rated at 300W RMS. The validated T/S data includes Fs 48Hz, Qts 0.47, Vas 141.8L, Xmax 5.3mm, sensitivity 96.6dB, plus 449cm³ Vd and 90 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
15"
Impedance
4Ω
RMS Power
300W
Sensitivity
96.6dB
EBP
90
Either alignment
Vd
449cm³
T/S Parameters
Valid
Fs48Hz
Qts0.47
Qes0.53
Qms4.5
Vas141.8L
Re6.8Ω
Le1.31mH
BL17.8Tm
Sd855cm²
Mms82g
Xmax5.3mm
SPL97dB
Power300W
Impedance4Ω
F Low45Hz
F High3500Hz
Voice Coil64mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.8kg
Diameter385.0mm
Overall Depth163.0mm
Cutout Diameter352.0mm
