T/S Parameters
Valid
Fs95Hz
Qts0.40
Qes0.45
Qms3.2
Vas16.0L
Re5.6Ω
Le0.60mH
BL14.9Tm
Sd346cm²
Mms30g
Xmax2.0mm
Power150W
Impedance8Ω
Voice Coil50mm
Pricing & availability
Price movement
Best current price
Updated 17 May 2026
leanaudio
£50.00
inc VAT
Dimensions & Physical
Weight1.5kg
Diameter256.0mm
Overall Depth110.0mm
Cutout Diameter229.0mm
Bolt Circle Diameter245.0mm
