REDCATT 61XR 4Ω
4 Ω
No current price
- Fs
- 64Hz
- Xmax
- 8.1mm
- SPL
- 86dB
- Pe
- 100W
- BL
- 4.8T·m
- Vd
- 107cm³
- Qts
- 0.72
- Vas
- 9L
REDCATT 61XR is a 6-inch 4 ohm LF driver rated at 100 W RMS. The validated T/S data includes Fs 64 Hz, Qts 0.72, Vas 8.6 L, Xmax 8.1 mm, sensitivity 85.7 dB, plus 107 cm³ Vd and 67 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 64Hz
- Qts
- 0.72
- Qes
- 0.96
- Qms
- 2.9
- Vas
- 8.6L
- Re
- 3.1Ω
- Le
- 0.06mH
Motor and cone
- BL
- 4.8T·m
- Sd
- 133cm²
- Mms
- 17g
- Xmax
- 8.1mm
- Vd †
- 107cm³
- Voice coil
- 45mm
Power and response
- Sensitivity †
- 85.7dB
- Manufacturer sensitivity
- 87dB
- Power
- 100W
- Impedance
- 4Ω
- EBP †
- 67 · Sealed or vented
Size and mounting
- Diameter
- 181.5mm
- Cutout
- 151mm
- Bolt circle
- 169.5mm
- Weight
- 1.5kg
Other published values
- Xmech
- 16.6
- Power Peak
- 400
Other dimensions
- Mounting Depth
- 94
Sensitivity shows 85.7 dB, calculated from the T/S values. REDCATT publishes 87.0 dB, 1.3 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 6″
- BL
- 4.8T·m
- Fs
- 64Hz
- Le
- 0.06mH
- Re
- 3.1Ω
- Sd
- 133cm²
- Mms
- 17g
- Qes
- 0.96
- Qms
- 2.9
- Qts
- 0.72
- SPL
- 85.7dB
- Vas
- 8.6L
- Xmax
- 8.1mm
- Xmech
- 16.6
- Power
- 100W
- Impedance
- 4Ω
- Power Peak
- 400
- Sensitivity
- 87dB
- Calculated sensitivity †
- 85.7dB
- Manufacturer sensitivity
- 87dB
- Voice coil
- 45mm
- Weight
- 1.5kg
- Diameter
- 181.5mm
- Mounting Depth
- 94
- Cutout
- 151mm
- Bolt circle
- 169.5mm
