Overview
LF DriverSC series
Visaton
Visaton SC 13
Visaton SC 13 is a 5" 8 ohm LF driver rated at 40W RMS. The validated T/S data includes Fs 78Hz, Qts 0.71, Vas 7.4L, Xmax 7.5mm, sensitivity 87.8dB, plus 59cm³ Vd and 83 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
5"
Impedance
8Ω
RMS Power
40W
Sensitivity
87.8dB
90.0dBmanufacturer; using T/S-derived value (2.2dB delta).
EBP
83
Either alignment
Vd
59cm³
T/S Parameters
Valid
Fs78Hz
Qts0.71
Qes0.94
Qms3.0
Vas7.4L
Re7.2Ω
Le0.70mH
BL4.2Tm
Sd79cm²
Mms5g
Xmax7.5mm
SPL88dB
Power40W
Impedance8Ω
F High13000Hz
Voice Coil20mm
Flux Density1.00T
Pricing & availability
Price definitionsOffers & B-stock
1 hidden from price comparisons
Vendor offers
1 vendorsoundimports
Updated 11 Sept 2026
Source: inc VAT
£28.31
inc VAT
Out of stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.6kg
Diameter130.0mm
Cutout Diameter113.0mm
