Visaton KT 100 V – 4″ 25W Woofer, 4 Ohm – Specs & Price

Visaton KT 100 V 4Ω

LF Driver

WatchWatch price SimSimulate

Media

Visaton KT 100 V 4 inch 4 ohm loudspeaker driver view 1

Visaton KT 100 V 4 inch 4 ohm loudspeaker driver view 2

Visaton KT 100 V 4 inch 4 ohm loudspeaker driver view 3

Visaton KT 100 V 4 inch 4 ohm loudspeaker driver view 4

Visaton KT 100 V 4 inch 4 ohm loudspeaker driver view 5

Auto-advancing

Overview

LF DriverKT series

Visaton KT 100 V

Visaton KT 100 V is a 4" 4 ohm LF driver rated at 25W RMS. The validated T/S data includes Fs 42Hz, Qts 0.56, Vas 7.5L, Xmax 7mm, sensitivity 81.1dB, plus 37cm³ Vd and 61 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £28.74.

Size

4"

Impedance

4Ω

RMS Power

25W

Sensitivity

81.1dB

80.0dBmanufacturer; using T/S-derived value (1.1dB delta).

EBP

61

Either alignment

V_d

37cm³

T/S Parameters

Valid

Canonical

Fs42Hz

Qts0.56

Qes0.69

Qms2.9

Vas7.5L

Re3.7Ω

BL3.3Tm

Sd53cm²

Mms8g

Xmax7.0mm

SPL81dB

Power25W

Impedance4Ω

F Low32Hz

F High9500Hz

Voice Coil25mm

What this validation status means

Pricing & availability

Price definitions

Price movement

Best current price

Updated 8 Sept 2026

impactaudio

£28.74

inc VAT·In stock

Use this driver

Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.

Files use canonical values. Required mechanical fields are derived only where the target format needs them.

Hornresp

.txt · Hornresp driver database

Driver file ready to place in Hornresp’s Drivers folder.

Not enough T/S data

Missing Le

WinISD

.wdr · WinISD driver editor

Native WinISD driver record with the required SI conversions.

Not enough T/S data

Missing Le

BASTA!

.bastaelement · BASTA! loudspeaker simulator

Native BASTA! element file using its documented SI-unit fields.

Not enough T/S data

Missing Le

VituixCAD

.wdr · VituixCAD 2 Enclosure

A WinISD driver file that VituixCAD imports directly.

Not enough T/S data

Missing Le

00 Simulator

Direct import · Web app

Start a new enclosure simulation with this driver already loaded.

Open in 00 Simulator

Copy spec sheet

Plain text · Clipboard

Copy the available values as a clean label-and-value list.

Dimensions & Physical

Weight0.5kg

Diameter100.0mm

Cutout Diameter92.0mm
