3-inch LF driver · FR070WA series · 22 mm voice coil

Wavecor FR070WA02 8Ω

Name: Wavecor FR070WA02 8 Ohm
Brand: Wavecor
SKU: FR070WA02
Availability: InStock

8 Ω

£81.82

Steady

Lautsprechershop · Ships from Germany · All 2 offers

Open in 00 Simulator

Fs: 114Hz
Xmax: 2mm
SPL: 84dB
Pe: –
BL: 3.6T·m
Vd: 4cm³
Qts: 0.53
Vas: 0.61L

See all 18 specs

Specifications

Published by Wavecor

Manufacturer page

Datasheet PDF

Wavecor FR070WA02 is a 3-inch 8 ohm LF driver. The validated T/S data includes Fs 114 Hz, Qts 0.53, Vas 0.6 L, Xmax 2 mm, sensitivity 84.2 dB, plus 4 cm³ Vd and 207 EBP. bits tracks UK, EU and US shop prices, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £81.07.

The published T/S values agree with each other

Thiele/Small

Fs: 114Hz
Qts: 0.53
Qes: 0.55
Qms: 12
Vas: 0.6L
Re: 6.4Ω

Motor and cone

BL: 3.6T·m
Sd: 21cm²
Mms: 2g
Xmax Derived: 2mm
Vd †: 4cm³
Voice coil: 22mm

Power and response

Sensitivity †: 84.2dB
Impedance: 8Ω
EBP †: 207 · Leans vented

Size and mounting

Diameter: 69.8mm

Other published values

Cms: 0.97mm/N
Rms: 0.12kg/s

† Calculated by bits from the published values

What this validation status means

Everything else Wavecor lists

LF · Primary · 3″

BL: 3.6T·m
Fs: 114Hz
Re: 6.4Ω
Sd: 21cm²
Cms: 0.97mm/N
Mms: 2g
Qes: 0.55
Qms: 12
Qts: 0.53
Rms: 0.12kg/s
SPL: 84.2dB
Vas: 0.6L
Xmax: 2mm
Impedance: 8Ω
Calculated sensitivity †: 84.2dB
Voice coil: 22mm
Diameter: 69.8mm

Compare

Same-size drivers, compared with the FR070WA02. Clear differences are green when better and red when worse.

This driverFR070WA02

Best price

£81.07

114 Hz

Qts

0.53

Vas

0.6 L

3.6 T·m

Xmax

2 mm

Sensitivity

84.2 dB

Power

–

REDCATT20NFR

£9.95 · 88% less

Fs185 Hz +62%

Qts0.52 –

Vas0.09 L −85%

BL3.2 T·m −10%

Xmax3 mm +50%

Sensitivity82.3 dB −1.9

Dayton AudioCE4895-8

£10.82 · 87% less

Fs123 Hz +8%

Qts0.53 –

Vas0.55 L −10%

BL5.2 T·m +44%

Xmax1.8 mm −10%

Sensitivity84.5 dB –

Dayton AudioPC83-4

£13.08 · 84% less

Fs80 Hz −30%

Qts0.54 –

Vas2.0 L +225%

BL2.9 T·m −19%

Xmax2 mm –

Sensitivity84 dB –

Dayton AudioDMA70-4

£17.48 · 78% less

Fs113 Hz –

Qts0.44 −17%

Vas0.57 L −7%

BL3.7 T·m –

Xmax2 mm –

Sensitivity83.7 dB −0.5

MonacorSP-60/8

£18.22 · 78% less

Fs65 Hz −43%

Qts0.49 −8%

Vas6 L +884%

BL4.1 T·m +14%

Xmax2 mm –

Sensitivity86.1 dB +1.9

MonacorSPX-32M

£18.39 · 77% less

Fs110 Hz −4%

Qts0.56 +6%

Vas1.6 L +162%

BL3.7 T·m –

Xmax1.1 mm −45%

Sensitivity87.5 dB +3.3

Dayton AudioDMA70-8

£20.81 · 74% less

Fs114 Hz –

Qts0.50 −6%

Vas0.57 L −7%

BL4.7 T·m +31%

Xmax2 mm –

Sensitivity82.6 dB −1.6

VisatonKT 100 V

£24.20 · 70% less

Fs42 Hz −63%

Qts0.56 +6%

Vas7.5 L +1130%

BL3.3 T·m −8%

Xmax2 mm –

Sensitivity81.1 dB −3.1

CIAREPA087

£24.24 · 70% less

Fs74 Hz −35%

Qts0.62 +17%

Vas2.2 L +261%

BL3.5 T·m −4%

Xmax2 mm –

Sensitivity83 dB −1.2

EminenceALPHA 3-8

£24.34 · 70% less

Fs118 Hz +4%

Qts0.50 −6%

Vas0.95 L +56%

BL3.9 T·m +9%

Xmax2.4 mm +20%

Sensitivity86.7 dB +2.5

MonacorSP-60/4

£24.99 · 69% less

Fs65 Hz −43%

Qts0.49 −8%

Vas6 L +884%

BL2.9 T·m −19%

Xmax2 mm –

Sensitivity86.1 dB +1.9

VisatonW 100 S

£26.08 · 68% less

Fs63 Hz −45%

Qts0.54 –

Vas5.4 L +787%

BL4.3 T·m +19%

Xmax2 mm –

Sensitivity85.1 dB +0.9

Tang BandW3-871B

£27.58 · 66% less

Fs110 Hz −4%

Qts0.52 –

Vas1.2 L +93%

BL3.7 T·m –

Xmax0.5 mm −75%

Sensitivity86.1 dB +1.9

Tang BandW3-315E

£32.14 · 60% less

Fs100 Hz −12%

Qts0.52 –

Vas1.7 L +175%

BL3.9 T·m +8%

Xmax1.3 mm −38%

Sensitivity86.7 dB +2.5

WavecorFR070WA04

£33.35 · 59% less

Fs114 Hz –

Qts0.87 +64%

Vas0.6 L –

BL2.9 T·m −19%

Xmax2 mm –

Sensitivity81.9 dB −2.3

CIARECM100

£40.27 · 50% less

Fs160 Hz +40%

Qts0.43 −19%

Vas1.8 L +195%

BL4.1 T·m +14%

Xmax1.9 mm −5%

Sensitivity93.5 dB +9.3

Tang BandW3-2345S

£45.13 · 44% less

Fs45 Hz −61%

Qts0.48 −9%

Vas0.64 L +5%

BL5.9 T·m +63%

Xmax7.7 mm +285%

Sensitivity72.2 dB −12

SB AcousticsSB12NRXF25-4

£45.28 · 44% less

Fs61 Hz −46%

Qts0.48 −9%

Vas4.1 L +572%

BL3.6 T·m –

Xmax5 mm +150%

Sensitivity84.5 dB –

Scanspeak5F/8422T01

£53.41 · 34% less

Fs93 Hz −18%

Qts0.61 +15%

Vas0.5 L −18%

BL3.1 T·m −14%

Xmax2 mm –

Sensitivity79.7 dB −4.5

VisatonB 100

£73.80 · 9% less

Fs75 Hz −34%

Qts0.52 –

Vas5.3 L +764%

BL4.1 T·m +14%

Xmax1.6 mm −18%

Sensitivity88.2 dB +4

WavecorFR070WA01

£81.07 · Same price

Fs121 Hz +6%

Qts0.56 +6%

Vas0.54 L −11%

BL3 T·m −17%

Xmax2 mm –

Sensitivity84.2 dB –

VisatonHX 10

£99.54 · 23% more

Fs80 Hz −30%

Qts0.50 −6%

Vas5.1 L +736%

BL3.9 T·m +8%

Xmax1.5 mm −25%

Sensitivity88.3 dB +4.1

WavecorFR070WA05

£100.21 · 24% more

Fs89 Hz −22%

Qts0.47 −11%

Vas0.6 L –

BL3.8 T·m +4%

Xmax2.7 mm +35%

Sensitivity81.4 dB −2.8

Dayton AudioDMA58-4

No current price

Fs166 Hz +45%

Qts0.46 −13%

Vas0.14 L −77%

BL3.7 T·m –

Xmax2 mm –

Sensitivity82.6 dB −1.6

CIAREFXI3.21

No current price

Fs90 Hz −21%

Qts0.44 −17%

Vas1.8 L +195%

BL3.7 T·m –

Xmax2 mm –

Sensitivity86.3 dB +2.1

WavecorFR055WA04

No current price

Fs128 Hz +12%

Qts0.51 −4%

Vas0.33 L −46%

BL3.3 T·m −8%

Xmax1.4 mm −32%

Sensitivity83 dB −1.2

Tang BandW3-1053SC

No current price

Fs100 Hz −12%

Qts0.52 –

Vas1.8 L +190%

BL3.7 T·m +3%

Xmax0.75 mm −63%

Sensitivity87 dB +2.8

Tang BandW3-926SDF

No current price

Fs100 Hz −12%

Qts0.49 −8%

Vas1.9 L +210%

BL3.7 T·m +3%

Xmax0.75 mm −63%

Sensitivity87.5 dB +3.3

Dayton AudioDMA105-4

No current price

Fs73 Hz −36%

Qts0.51 −4%

Vas4.2 L +596%

BL3.4 T·m −6%

Xmax2.5 mm +25%

Sensitivity86.2 dB +2

Dayton AudioDMA90-4

No current price

Fs88 Hz −23%

Qts0.45 −15%

Vas2.3 L +271%

BL3.5 T·m –

Xmax2.5 mm +25%

Sensitivity86.5 dB +2.3

Search similar

Tune the match

Choose the published values that matter to your design. Size stays matched to this driver.

Qts

Qes

Vas

Xmax

Where to buy

Prices for delivery to the UK, including VAT. How prices work

Watch price

Shop	Price	Against the lowest	Stock	Link
Lautsprechershop Checked 30 Oct 2026 · Ships from Germany · 8 Ω · Source: inc VAT · 19% Import VAT and duty may apply	£81.82, the lowest price		Stock not listed	Visit shop at Lautsprechershop
