Dayton Audio DMA90-4 4Ω
4 Ω · 85–20000 Hz
No current price
- Fs
- 88Hz
- Xmax
- 2.5mm
- SPL
- 87dB
- Pe
- 30W
- BL
- 3.5T·m
- Vd
- 10cm³
- Qts
- 0.45
- Vas
- 2L
Manufacturer response and impedance data, with source and trace details below. The left and right arrow keys read every shown curve at a frequency, a twelfth of an octave at a time, or an octave with Shift. Escape clears the reading.
Curve provenanceInspect 3 traces
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
15 degrees
Frequency response
240 plotted pointsMedium confidence1,405 selected pixels of 1,709 - Trace datasheet-response-trace-poc/v1
30 degrees
Frequency response
240 plotted pointsMedium confidence1,348 selected pixels of 2,060 - Trace datasheet-response-trace-poc/v1
45 degrees
Frequency response
221 plotted pointsMedium confidence1,185 selected pixels of 2,160
Dayton Audio DMA90-4 is a 3.5-inch 4 ohm LF driver rated at 30 W RMS. The validated T/S data includes Fs 88 Hz, Qts 0.45, Vas 2.3 L, Xmax 2.5 mm, sensitivity 86.5 dB, plus 10 cm³ Vd and 158 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 88Hz
- Qts
- 0.45
- Qes
- 0.56
- Qms
- 2.5
- Vas
- 2.3L
- Re
- 3.8Ω
- Le
- 0.30mH
Motor and cone
- BL
- 3.5T·m
- Sd
- 39cm²
- Mms
- 3g
- Xmax
- 2.5mm
- Vd †
- 10cm³
Power and response
- Sensitivity †
- 86.5dB
- Manufacturer sensitivity
- 89.3dB
- Power
- 30W
- Impedance
- 4Ω
- Range
- 85–20000Hz
- EBP †
- 158 · Leans vented
Size and mounting
- Weight
- 0.18kg
Other published values
- Cms
- 1.03mm/N
- Power Peak
- 60
Sensitivity shows 86.5 dB, calculated from the T/S values. Dayton Audio publishes 89.3 dB, 2.8 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Dayton Audio lists
LF · Primary · 3.5″
- BL
- 3.5T·m
- Fs
- 88Hz
- Le
- 0.30mH
- Re
- 3.8Ω
- Sd
- 39cm²
- Cms
- 1.03mm/N
- Mms
- 3g
- Qes
- 0.56
- Qms
- 2.5
- Qts
- 0.45
- SPL
- 86.5dB
- Vas
- 2.3L
- Xmax
- 2.5mm
- Power
- 30W
- Impedance
- 4Ω
- Power Peak
- 60
- Sensitivity
- 89.3dB
- Low limit
- 85Hz
- Calculated sensitivity †
- 86.5dB
- High limit
- 20000Hz
- Manufacturer sensitivity
- 89.3dB
- Weight
- 0.18kg
02
Compare
Same-size drivers, compared with the DMA90-4. Clear differences are green when better and red when worse.
This driverDMA90-4
Best price
–
Fs
88 Hz
Qts
0.45
Vas
2.3 L
BL
3.5 T·m
Xmax
2.5 mm
Sensitivity
86.5 dB
Power
30 W
Dayton AudioDMA70-4
£17.51Fs113 Hz +28%, worse
Qts0.44 –
Vas0.57 L −75%, better
BL3.7 T·m +6%
Xmax2 mm −20%, worse
Sensitivity83.7 dB −2.8, worse
Sica3.5 H 1 CS
£18.42Fs85 Hz −4%
Qts0.53 +18%, worse
Vas1.8 L −21%, better
BL4.8 T·m +38%, better
Xmax2.5 mm –
Sensitivity84.9 dB −1.6
Dayton AudioDMA80-8
£19.17Fs98 Hz +11%, worse
Qts0.47 +4%
Vas1.1 L −50%, better
BL5.1 T·m +46%, better
Xmax2.5 mm –
Sensitivity84.4 dB −2.1, worse
Dayton AudioDSA90-8
£20.18Fs67 Hz −24%, better
Qts0.37 −18%, better
Vas2.3 L –
BL4.6 T·m +32%, better
Xmax2.5 mm –
Sensitivity83.8 dB −2.7, worse
FaitalPRO4FE32
£21.94Fs100 Hz +13%, worse
Qts0.53 +18%, worse
Vas2.5 L +10%, worse
BL3.7 T·m +6%
Xmax1.7 mm −31%, worse
Sensitivity88.1 dB +1.6
EminenceALPHA 3-8
£24.24Fs118 Hz +34%, worse
Qts0.50 +11%, worse
Vas0.95 L −58%, better
BL3.9 T·m +12%, better
Xmax2.4 mm −4%
Sensitivity86.7 dB –
CIAREPA087
£24.28Fs74 Hz −16%, better
Qts0.62 +38%, worse
Vas2.2 L –
BL3.5 T·m –
Xmax2 mm −20%, worse
Sensitivity83 dB −3.5, worse
Dayton AudioDMA105-4
£30.10Fs73 Hz −18%, better
Qts0.51 +13%, worse
Vas4.2 L +87%, worse
BL3.4 T·m –
Xmax2.5 mm –
Sensitivity86.2 dB –
VisatonW 100 S
£30.10Fs65 Hz −26%, better
Qts0.46 –
Vas4.5 L +98%, worse
BL3.7 T·m +6%
Xmax2 mm −20%, worse
Sensitivity85.6 dB −0.9
Tang BandW3-315E
£32.19Fs100 Hz +13%, worse
Qts0.52 +16%, worse
Vas1.7 L −26%, better
BL3.9 T·m +11%, better
Xmax1.3 mm −50%, worse
Sensitivity86.7 dB –
WavecorWF095WA02
£41.14Fs86 Hz –
Qts0.62 +38%, worse
Vas1.6 L −29%, better
BL3.6 T·m –
Xmax2.7 mm +8%
Sensitivity83.7 dB −2.8, worse
Tang BandW4-1052SDF
£47.37Fs70 Hz −21%, better
Qts0.42 −7%
Vas5.2 L +130%, worse
BL4.1 T·m +17%, better
Xmax2.6 mm +4%
Sensitivity87.9 dB +1.4
Tang BandW4-2417
£64.39Fs65 Hz −26%, better
Qts0.44 –
Vas4.6 L +101%, worse
BL5.4 T·m +53%, better
Xmax2.5 mm –
Sensitivity85.8 dB −0.7
Scanspeak10F/8414G10
£66.31Fs100 Hz +13%, worse
Qts0.51 +13%, worse
Vas1.6 L −31%, better
BL4.3 T·m +23%, better
Xmax2.3 mm −8%
Sensitivity85.9 dB −0.6
WavecorSW070WA01
£95.79Fs84 Hz −5%
Qts0.39 −13%, better
Vas0.7 L −70%, better
BL3.9 T·m +10%, better
Xmax2.5 mm –
Sensitivity81.8 dB −4.7, worse
WavecorFR070WA05
£100.39Fs89 Hz –
Qts0.47 +4%
Vas0.6 L −74%, better
BL3.8 T·m +7%
Xmax2.7 mm +8%
Sensitivity81.4 dB −5.1, worse
Dayton AudioDMA80-4
No current priceFs94 Hz +6%
Qts0.41 −9%
Vas1.4 L −38%, better
BL3.7 T·m +6%
Xmax2.5 mm –
Sensitivity85.6 dB −0.9
Tang BandW4-2099
No current priceFs60 Hz −32%, better
Qts0.47 +4%
Vas2.8 L +22%, worse
BL3.7 T·m +6%
Xmax3 mm +20%, better
Sensitivity82.5 dB −4, worse
CIAREFXI3.21
No current priceFs90 Hz –
Qts0.44 –
Vas1.8 L −21%, better
BL3.7 T·m +6%
Xmax2 mm −20%, worse
Sensitivity86.3 dB –
Dayton AudioCFC120-4
No current priceFs57 Hz −35%, better
Qts0.45 –
Vas4.5 L +97%, worse
BL4.2 T·m +21%, better
Xmax2.5 mm –
Sensitivity83.9 dB −2.6, worse
Tang BandW3-926SDF
No current priceFs100 Hz +13%, worse
Qts0.49 +9%
Vas1.9 L −17%, better
BL3.7 T·m +6%
Xmax0.75 mm −70%, worse
Sensitivity87.5 dB +1
Tang BandW3-926SD
No current priceFs110 Hz +25%, worse
Qts0.46 –
Vas1.9 L −17%, better
BL3.8 T·m +10%
Xmax0.75 mm −70%, worse
Sensitivity89 dB +2.5, better
CIARECM100
No current priceFs160 Hz +81%, worse
Qts0.43 −4%
Vas1.8 L −21%, better
BL4.1 T·m +17%, better
Xmax1.9 mm −24%, worse
Sensitivity93.5 dB +7, better
WavecorSW084OM01
No current priceFs74 Hz −16%, better
Qts0.44 –
Vas1.7 L −25%, better
BL3.6 T·m –
Xmax4.5 mm +80%, better
Sensitivity83.8 dB −2.7, worse
Tang BandW3-1053SC
No current priceFs100 Hz +13%, worse
Qts0.52 +16%, worse
Vas1.8 L −22%, better
BL3.7 T·m +6%
Xmax0.75 mm −70%, worse
Sensitivity87 dB +0.5
Tang BandW3-316B
No current priceFs100 Hz +13%, worse
Qts0.44 –
Vas1.9 L −17%, better
BL4.1 T·m +18%, better
Xmax1.2 mm −52%, worse
Sensitivity88 dB +1.5
PeerlessTG9FC02-04
No current priceFs150 Hz +70%, worse
Qts0.43 −4%
Vas0.84 L −63%, better
BL3.9 T·m +10%, better
Xmax3.0 mm +21%, better
Sensitivity89.4 dB +2.9, better
CIARECX102
No current priceFs125 Hz +42%, worse
Qts0.43 −4%
Vas1.5 L −34%, better
BL4.3 T·m +23%, better
Xmax1.9 mm −24%, worse
Sensitivity89.6 dB +3.1, better
Tang BandW3-2088S0F
No current priceFs45 Hz −49%, better
Qts0.48 +7%
Vas2.1 L −7%
BL5.7 T·m +61%, better
Xmax7 mm +180%, better
Sensitivity77.4 dB −9.1, worse
