8-inch LF driver · FBASS08 series · 45 mm voice coil · 150 W
Lavoce FBASS08-18 8Ω
8 Ω · 50–5000 Hz
No current price
- Fs
- 53Hz
- Xmax
- 4.5mm
- SPL
- 91dB
- Pe
- 150W
- BL
- 11.4T·m
- Vd
- 106cm³
- Qts
- 0.40
- Vas
- 24L
Lavoce FBASS08-18 is an 8-inch 8 ohm LF driver rated at 150 W RMS. The validated T/S data includes Fs 53 Hz, Qts 0.40, Vas 23.6 L, Xmax 4.5 mm, sensitivity 91.2 dB, plus 106 cm³ Vd and 123 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 53Hz
- Qts
- 0.40
- Qes
- 0.43
- Qms
- 6.9
- Vas
- 23.6L
- Re
- 5.6Ω
- Le
- 0.59mH
Motor and cone
- BL
- 11.4T·m
- Sd
- 235cm²
- Mms
- 30g
- Xmax
- 4.5mm
- Vd †
- 106cm³
- Voice coil
- 45mm
Power and response
- Sensitivity †
- 91.2dB
- Manufacturer sensitivity
- 92.5dB
- Power
- 150W
- Impedance
- 8Ω
- Min. impedance
- 6.2Ω
- Range
- 50–5000Hz
- EBP †
- 123 · Leans vented
Size and mounting
- Weight
- 3kg
Other published values
- Cms
- 0.30mm/N
- Xmech
- 7
- Power Program
- 300
Sensitivity shows 91.2 dB, calculated from the T/S values. Lavoce publishes 92.5 dB, 1.3 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Lavoce lists
LF · Primary · 8″
- BL
- 11.4T·m
- Fs
- 53Hz
- Le
- 0.59mH
- Re
- 5.6Ω
- Sd
- 235cm²
- Cms
- 0.30mm/N
- Mms
- 30g
- Qes
- 0.43
- Qms
- 6.9
- Qts
- 0.40
- SPL
- 91.2dB
- Vas
- 23.6L
- Xmax
- 4.5mm
- Xmech
- 7
- Power
- 150W
- Impedance
- 8Ω
- Sensitivity
- 92.5dB
- Low limit
- 50Hz
- Power Program
- 300
- Calculated sensitivity †
- 91.2dB
- High limit
- 5000Hz
- Manufacturer sensitivity
- 92.5dB
- Min. impedance
- 6.2Ω
- Voice coil
- 45mm
- Weight
- 3kg
