Media
Auto-advancing
Size
8"
Impedance
8Ω
RMS Power
200W
EBP
180
Vented alignment
Vd
110cm³
Overall Parameters
Valid
Fs81Hz
Qts0.40
Qes0.45
Qms3.5
Vas14.8L
Re5.9Ω
Le0.46mH
BL11.0Tm
Sd220cm²
Mms18g
Xmax5.0mm
Power200W
Impedance8Ω
Min Impedance6.9Ω
F Low75Hz
F High20000Hz
Voice Coil51mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
Pricing & availability
No standard offers found
Check the manufacturer website for current pricing.
Dimensions & Physical
Weight3.0kg
Driver Components
LF
Fs81 Hz
Qts0.40
Qes0.45
Qms3.5
Vas14.8 L
Re5.9 Ω
Le0.46 mH
BL11.0 Tm
Sd220 cm²
Mms18 g
Xmax5.0 mm
Power200 W
Impedance8 Ω
Min Impedance6.9 Ω
F Low75 Hz
F High5500 Hz
Voice Coil51 mm
Cms0.216
Power Program400
Sensitivity96
Xmech9
Section dimensions
Weight3000.0 kg
HF
Power35 W
Impedance8 Ω
Min Impedance7.5 Ω
F Low1500 Hz
F High20000 Hz
Xover2200 Hz
Throat25 mm
Voice Coil35 mm
Flux Density1.50 T
Power Program70
Sensitivity103.5
