Overview
LF Driver
Eighteen Sound
Eighteen Sound 15LW1500
Eighteen Sound 15LW1500 is a 15" 8 ohm LF driver rated at 1000W RMS. The validated T/S data includes Fs 34Hz, Qts 0.28, Vas 195L, Xmax 9mm, sensitivity 96.2dB, plus 765cm³ Vd and 117 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £284.97.
Size
15"
Impedance
8Ω
RMS Power
1000W
Sensitivity
96.2dB
EBP
117
Vented alignment
Vd
765cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
frequency response240 ptsp2medium
Curve provenanceInspect 1 traceHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
frequency response
Frequency response
240 plotted pointsMedium confidence10,352 selected pixels of 10,659
T/S Parameters
Valid
Fs34Hz
Qts0.28
Qes0.29
Qms11.5
Vas195.0L
Re5.0Ω
Le2.40mH
BL22.1Tm
Sd850cm²
Mms130g
Xmax9.0mm
SPL96dB
Power1000W
Power Nominal1000W
Impedance8Ω
F Low40Hz
F High2000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£284.97
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight12.4kg
Diameter387.0mm
Overall Depth165.0mm
Cutout Diameter353.0mm
Bolt Circle Diameter370.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Eighteen Sound
15LW1500
15"
Best current price
£284.97
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
50%
Similarity
56% cheaper£125.00
Celestion
TF1530E
15"
Lower price
Xmax6.5mm-28%
Qts0.33+17%
BL17Tm-23%
Vas191.6L-2%
Qes0.37+29%
58%
Similarity
51% cheaper£138.54
B&C
15CL76
15"
Lower price
Xmax7mm-22%
Qts0.33+18%
BL21Tm-5%
Vas135L-31%
Qes0.34+17%
63%
Similarity
47% cheaper£152.00
B&C
15CL76
15"
Lower price
Xmax7mm-22%
Qts0.25-11%
BL19.1Tm-14%
Vas140L-28%
Qes0.27-7%
75%
Similarity
46% cheaper£153.86
Eminence
KAPPA PRO-15LF
15"
Lower price
Xmax6.7mm-26%
Qts0.3+7%
BL21.6Tm-2%
Vas198.8L+2%
Qes0.32+10%
63%
Similarity
39% cheaper£173.91
SB Audience
ROSSO-15MW500
15"
Lower price
Xmax8.4mm-7%
Qts0.33+18%
BL23.2Tm+5%
Vas121.3L-38%
Qes0.35+21%
63%
Similarity
36% cheaper£181.89
Eighteen Sound
15W700
15"
Lower price
Xmax6.5mm-28%
Qts0.3+7%
BL18.4Tm-17%
Vas217L+11%
Qes0.33+14%
81%
Similarity
36% cheaper£182.15
RCF
LF15G401
15"
Lower price
Xmax9mm0%
Qts0.26-7%
BL24.6Tm+11%
Vas150L-23%
Qes0.27-7%
66%
Similarity
35% cheaper£184.99
B&C
15NDL76
15"
Lower price
Xmax7mm-22%
Qts0.22-21%
BL22.5Tm+2%
Vas195L0%
Qes0.24-17%
62%
Similarity
32% cheaper£193.05
Eighteen Sound
15W930
15"
Lower price
Xmax7.5mm-17%
Qts0.22-21%
BL22.1Tm0%
Vas240L+23%
Qes0.23-21%
69%
Similarity
32% cheaper£194.97
BMS
15S330
15"
Lower price
Xmax8mm-11%
Qts0.32+14%
BL23Tm+4%
Vas152L-22%
Qes0.34+17%
88%
Similarity
30% cheaper£198.42
FaitalPRO
15FH510
15"
Lower price
Xmax9.3mm+3%
Qts0.26-7%
BL21Tm-5%
Vas191.8L-2%
Qes0.27-7%
70%
Similarity
30% cheaper£199.99
B&C
15PZB100
15"
Lower price
Xmax8mm-11%
Qts0.29+4%
BL25.8Tm+17%
Vas110L-44%
Qes0.3+3%
