Wavecor WF166TU02 4Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverWF166TU series
Wavecor
Wavecor WF166TU02
Wavecor WF166TU02 is a 6.5" 4 ohm LF driver. The validated T/S data includes Fs 50Hz, Qts 0.48, Vas 22.3L, Xmax 3mm, sensitivity 89.5dB, plus 42cm³ Vd and 100 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6.5"
Impedance
4Ω
Sensitivity
89.5dB
EBP
100
Either alignment
Vd
42cm³
T/S Parameters
Valid
Fs50Hz
Qts0.48
Qes0.50
Qms9.8
Vas22.3L
Re3.2Ω
BL5.0Tm
Sd139cm²
Mms13g
XmaxDerived3.0mm
SPL90dB
Impedance4Ω
Voice Coil32mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Not enough T/S data
Missing Le, RMS power
BASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Not enough T/S data
Missing Le, RMS power
VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Not enough T/S data
Missing Le, RMS power
00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Diameter165.1mm
