Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespVisaton W 200 S 4Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverW series
Visaton
Visaton W 200 S
Visaton W 200 S is a 8" 4 ohm LF driver rated at 75W RMS. The validated T/S data includes Fs 29Hz, Qts 0.35, Vas 65L, Xmax 10mm, sensitivity 88.2dB, plus 214cm³ Vd and 76 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £58.80.
Size
8"
Impedance
4Ω
RMS Power
75W
Sensitivity
88.2dB
EBP
76
Either alignment
Vd
214cm³
T/S Parameters
Valid
Fs29Hz
Qts0.35
Qes0.38
Qms4.0
Vas65.0L
Re3.4Ω
Le1.50mH
BL7.7Tm
Sd214cm²
Mms28g
Xmax10.0mm
SPL88dB
Power75W
Impedance4Ω
F High6000Hz
Voice Coil35mm
Flux Density1.10T
Pricing & availability
Price definitionsPrice movement
Other offers
2 vendorssoundimports
Updated 11 Sept 2026· 4Ω
Source: inc VAT
£55.80
inc VAT
Out of stock
impactaudio
Updated 8 Sept 2026· 4Ω
Source: ex VAT · 20%
£67.14
inc VAT
In stock
Best current price
Updated 11 Sept 2026
partsexpress
£58.80
Avg £62.97£4.17 below avg (-6.6%)
inc VAT·1 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.5kg
Diameter200.0mm
Cutout Diameter184.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Visaton
W 200 S
8"
Best current price
£58.80
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
80%
Similarity
47% cheaper£31.27
SB Acoustics
SB20PFCR30-4
8"
Lower price
Xmax11.5mm+15%
Qts0.33-6%
BL6.6Tm-14%
Vas66.2L+2%
Qes0.37-3%
82%
Similarity
41% cheaper£34.95
SB Acoustics
SB20PFCR30-8
8"
Lower price
Xmax11.5mm+15%
Qts0.37+6%
BL7.7Tm0%
Vas66.2L+2%
Qes0.43+13%
65%
Similarity
23% cheaper£45.49
Peerless
HDS-P830869
8"
Lower price
Xmax7.5mm-25%
Qts0.38+9%
BL9.3Tm+21%
Vas57.6L-11%
Qes0.4+6%
63%
Similarity
7% more£63.09
CIARE
HWB200
8"
Higher price
Xmax7mm-30%
Qts0.39+11%
BL8.9Tm+16%
Vas59L-9%
Qes0.41+8%
84%
Similarity
14% more£67.14
Visaton
W 200 S - 8 OHM
8"
Higher price
Xmax10mm0%
Qts0.33-6%
BL9Tm+17%
Vas70L+8%
Qes0.36-5%
61%
Similarity
44% more£84.41
SB Acoustics
SB23NRXS45-8
8"
Higher price
Xmax13mm+30%
Qts0.38+9%
BL7.5Tm-3%
Vas94L+45%
Qes0.41+8%
53%
Similarity
44% more£84.41
SB Acoustics
SB23NRXS45-4
8"
Higher price
Xmax13mm+30%
Qts0.3-14%
BL6.9Tm-10%
Vas87.5L+35%
Qes0.32-16%
57%
Similarity
68% more£98.70
SB Acoustics
SB23NBACS45-4
8"
Higher price
Xmax13mm+30%
Qts0.33-6%
BL6.7Tm-13%
Vas95L+46%
Qes0.35-8%
55%
Similarity
68% more£98.70
SB Acoustics
SB23NBACS45-8
8"
Higher price
Xmax13mm+30%
Qts0.4+14%
BL7.9Tm+3%
Vas93.4L+44%
Qes0.43+13%
57%
Similarity
94% more£114.02
SB Acoustics
SB23CACS45-4
8"
Higher price
Xmax13mm+30%
Qts0.33-6%
BL6.7Tm-13%
Vas95L+46%
Qes0.35-8%
57%
Similarity
94% more£114.02
SB Acoustics
SB23CACS45-8
8"
Higher price
Xmax13mm+30%
Qts0.4+14%
BL7.9Tm+3%
Vas87L+34%
Qes0.44+16%
86%
Similarity
138% more£140.05
Visaton
GF 200
8"
Higher price
Xmax10mm0%
Qts0.34-3%
BL9.2Tm+19%
Vas68L+5%
Qes0.37-3%
