Overview
LF DriverGF series
Visaton
Visaton GF 200
Visaton GF 200 is a 8" 8 ohm LF driver rated at 120W RMS. The validated T/S data includes Fs 30Hz, Qts 0.34, Vas 68L, Xmax 10mm, sensitivity 89dB, plus 214cm³ Vd and 81 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £140.05.
Size
8"
Impedance
8Ω
RMS Power
120W
Sensitivity
89.0dB
88.0dBmanufacturer; using T/S-derived value (1.0dB delta).
EBP
81
Either alignment
Vd
214cm³
T/S Parameters
Valid
Fs30Hz
Qts0.34
Qes0.37
Qms4.1
Vas68.0L
Re5.8Ω
Le1.10mH
BL9.2Tm
Sd214cm²
Mms25g
Xmax10.0mm
SPL89dB
Power120W
Impedance8Ω
F High8000Hz
Voice Coil38mm
Flux Density1.30T
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorimpactaudio
Updated 8 Sept 2026· 8Ω
Source: ex VAT · 20%
£163.14
inc VAT
In stock
Best current price
Updated 11 Sept 2026
partsexpress
£140.05
Avg £151.60£11.54 below avg (-7.6%)
inc VAT·1 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight2.5kg
Diameter200.0mm
Cutout Diameter190.0mm
