Overview
LF Driver
Sica
Sica 6 D 1.5 SL
Sica 6 D 1.5 SL is a 6" 8 ohm LF driver rated at 130W RMS. The validated T/S data includes Fs 110Hz, Qts 0.46, Vas 4L, Xmax 1.5mm, sensitivity 91.9dB, plus 18cm³ Vd and 200 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6"
Impedance
8Ω
RMS Power
130W
Sensitivity
91.9dB
93.9dBmanufacturer; using T/S-derived value (2.0dB delta).
EBP
200
Vented alignment
Vd
18cm³
T/S Parameters
Valid
Fs110Hz
Qts0.46
Qes0.55
Qms2.6
Vas4.0L
Re5.0Ω
Le0.22mH
BL8.3Tm
Sd123cm²
Mms11g
Xmax1.5mm
SPL92dB
Power130W
Impedance8Ω
Voice Coil38mm
Flux Density1.20T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.9kg
Diameter165.5mm
Overall Depth75.6mm
Cutout Diameter143.0mm
Bolt Circle Diameter155.0mm
