Overview
LF Driver
Sica
Sica 6 D 1.5 CS
Sica 6 D 1.5 CS is a 6" 8 ohm LF driver rated at 100W RMS. The validated T/S data includes Fs 109Hz, Qts 0.63, Vas 4.4L, Xmax 1.5mm, sensitivity 90.6dB, plus 18cm³ Vd and 137 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6"
Impedance
8Ω
RMS Power
100W
Sensitivity
90.6dB
91.7dBmanufacturer; using T/S-derived value (1.1dB delta).
EBP
137
Vented alignment
Vd
18cm³
T/S Parameters
Valid
Fs109Hz
Qts0.63
Qes0.79
Qms3.2
Vas4.4L
Re6.0Ω
Le0.20mH
BL7.4Tm
Sd123cm²
Mms10g
Xmax1.5mm
SPL91dB
Power100W
Impedance8Ω
Voice Coil38mm
Flux Density0.95T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.4kg
Diameter165.5mm
Overall Depth72.1mm
Cutout Diameter143.0mm
Bolt Circle Diameter155.0mm
