5-inch LF driver · WSF051 series · 25 mm voice coil · 60 W

Lavoce WSF051.02 8Ω

Name: Lavoce WSF051.02 8 Ohm
Brand: Lavoce
SKU: WSF051.02

8 Ω · 100–5000 Hz

No price for delivery to the UK

All 1 offer

Open in 00 Simulator

Fs: 106Hz
Xmax: 3.1mm
SPL: 90dB
Pe: 60W
BL: 6.4T·m
Vd: 27cm³
Qts: 0.60
Vas: 3L

See all 24 specs

Specifications

Published by Lavoce

Manufacturer page

Lavoce WSF051.02 is a 5-inch 8 ohm LF driver rated at 60 W RMS. The validated T/S data includes Fs 106 Hz, Qts 0.60, Vas 3.3 L, Xmax 3.1 mm, sensitivity 89.7 dB, plus 27 cm³ Vd and 161 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

The published T/S values agree with each other

Thiele/Small

Fs: 106Hz
Qts: 0.60
Qes: 0.66
Qms: 7.0
Vas: 3.3L
Re: 5.6Ω
Le: 0.27mH

Motor and cone

BL: 6.4T·m
Sd: 86cm²
Mms: 7g
Xmax: 3.1mm
Vd †: 27cm³
Voice coil: 25mm

Power and response

Sensitivity †: 89.7dB
Manufacturer sensitivity: 91.5dB
Power: 60W
Impedance: 8Ω
Min. impedance: 6.1Ω
Range: 100–5000Hz
EBP †: 161 · Leans vented

Size and mounting

Weight: 0.9kg

Other published values

Cms: 0.31mm/N
Xmech: 4.9
Power Program: 120

Sensitivity shows 89.7 dB, calculated from the T/S values. Lavoce publishes 91.5 dB, 1.8 dB apart.

† Calculated by bits from the published values

What this validation status means

Everything else Lavoce lists

LF · Primary · 5″

BL: 6.4T·m
Fs: 106Hz
Le: 0.27mH
Re: 5.6Ω
Sd: 86cm²
Cms: 0.31mm/N
Mms: 7g
Qes: 0.66
Qms: 7.0
Qts: 0.60
SPL: 89.7dB
Vas: 3.3L
Xmax: 3.1mm
Xmech: 4.9
Power: 60W
Impedance: 8Ω
Sensitivity: 91.5dB
Low limit: 100Hz
Power Program: 120
Calculated sensitivity †: 89.7dB
High limit: 5000Hz
Manufacturer sensitivity: 91.5dB
Min. impedance: 6.1Ω
Voice coil: 25mm
Weight: 0.9kg

Compare

Same-size drivers, compared with the WSF051.02. Clear differences are green when better and red when worse.

This driverWSF051.02

Best price

–

106 Hz

Qts

0.60

Vas

3.3 L

6.4 T·m

Xmax

3.1 mm

Sensitivity

89.7 dB

Power

60 W

PRV Audio4MR60-4

£14.89

Fs90 Hz −15%

Qts0.68 +13%

Vas3.3 L –

BL3.4 T·m −47%

Xmax2.9 mm −7%

Sensitivity87 dB −2.7

REDCATT5FR

£15.83

Fs92 Hz −13%

Qts0.69 +15%

Vas3.8 L +17%

BL6.3 T·m –

Xmax2 mm −35%

Sensitivity88.1 dB −1.6

Dayton AudioPA130-8

£17.94

Fs83 Hz −21%

Qts0.51 −15%

Vas4.0 L +21%

BL6.4 T·m –

Xmax2 mm −35%

Sensitivity87.8 dB −1.9

Sica5 D 1 CS

£19.68

Fs79 Hz −25%

Qts0.52 −13%

Vas5.5 L +69%

BL5.7 T·m −10%

Xmax3 mm −3%

Sensitivity88.7 dB −1

Dayton AudioDA135-8

£20.93

Fs57 Hz −47%

Qts0.54 −10%

Vas7.4 L +127%

BL5.3 T·m −17%

Xmax3 mm −3%

Sensitivity85 dB −4.7

FaitalPRO4FE32

£21.94

Fs100 Hz −6%

Qts0.61 –

Vas2.3 L −29%

BL4.8 T·m −25%

Xmax2.7 mm −12%

Sensitivity87.2 dB −2.5

LavoceCSF051.21

£29.17

Fs110 Hz +4%

Qts0.64 +7%

Vas4.1 L +25%

BL5.9 T·m −8%

Xmax3.4 mm +10%

Sensitivity90.7 dB +1

Dayton AudioND105-8

£30.48

Fs67 Hz −37%

Qts0.66 +10%

Vas3.0 L −9%

BL5.4 T·m −15%

Xmax4 mm +29%

Sensitivity82.8 dB −6.9

CIAREPA100

£30.98

Fs100 Hz −6%

Qts0.59 –

Vas2.5 L −23%

BL4.4 T·m −31%

Xmax2.5 mm −19%

Sensitivity87.6 dB −2.1

Dayton AudioLW150-4

£41.13

Fs63 Hz −41%

Qts0.64 +7%

Vas3.5 L +7%

BL6.5 T·m –

Xmax4 mm +29%

Sensitivity82.8 dB −6.9

Dayton AudioRS125T-8

£47.22

Fs76 Hz −28%

Qts0.50 −17%

Vas3.6 L +9%

BL5.0 T·m −21%

Xmax2.8 mm −10%

Sensitivity86.1 dB −3.6

WavecorWF146WA02

£57.60

Fs58 Hz −45%

Qts0.51 −15%

Vas10 L +207%

BL6.4 T·m –

Xmax3 mm −3%

Sensitivity87.6 dB −2.1

EminenceBETA-6A

£64.09

Fs123 Hz +16%

Qts0.56 −7%

Vas3.5 L +8%

BL8.1 T·m +27%

Xmax4.5 mm +45%

Sensitivity92 dB +2.3

Sica5 N 1.5 PL

£65.31

Fs111 Hz +4%

Qts0.56 −7%

Vas3 L −8%

BL6.2 T·m –

Xmax3 mm −3%

Sensitivity89.5 dB –

CelestionTFX0412

£69.00

Fs95 Hz −10%

Qts0.59 –

Vas2.2 L −33%

BL5.4 T·m −16%

Xmax4 mm +29%

Sensitivity86.5 dB −3.2

WavecorWF118WA06

£82.89

Fs66 Hz −38%

Qts0.55 −8%

Vas3.5 L +7%

BL5.6 T·m −13%

Xmax3 mm −3%

Sensitivity84.3 dB −5.4

FaitalPRO5HX220

£184.17

Fs135 Hz +27%

Qts0.59 –

Vas2.2 L −33%

BL7.7 T·m +20%

Xmax4.6 mm +47%

Sensitivity91.4 dB +1.7

AccutonC90-6-724

£527.46

Fs83 Hz −22%

Qts0.60 –

Vas5.1 L +56%

BL6.0 T·m −7%

Xmax3 mm −3%

Sensitivity88.4 dB −1.3

MonacorSP-4/60PRO

No current price

Fs92 Hz −13%

Qts0.60 –

Vas3 L −8%

BL5.8 T·m −9%

Xmax2.3 mm −26%

Sensitivity87.5 dB −2.2

PeerlessFSL-0512R01-08

No current price

Fs120 Hz +13%

Qts0.58 −3%

Vas3.5 L +7%

BL6.4 T·m –

Xmax4.3 mm +40%

Sensitivity91 dB +1.3

Dayton AudioE150MR-8

No current price

Fs74 Hz −30%

Qts0.58 −3%

Vas8 L +145%

BL6.1 T·m −4%

Xmax2.7 mm −13%

Sensitivity88.9 dB −0.8

HiViB4N

No current price

Fs56 Hz −47%

Qts0.52 −13%

Vas4.5 L +38%

BL5.1 T·m −20%

Xmax3.2 mm +3%

Sensitivity83 dB −6.7

CelestionTF0512HE

No current price

Fs85 Hz −20%

Qts0.54 −11%

Vas3.5 L +6%

BL6.7 T·m +5%

Xmax4.8 mm +53%

Sensitivity87.7 dB −2

PRV Audio6MB400-4

No current price

Fs125 Hz +18%

Qts0.52 −13%

Vas5.3 L +63%

BL6.6 T·m –

Xmax3 mm −3%

Sensitivity94.7 dB +5

WavecorMR120BD03

No current price

Fs73 Hz −31%

Qts0.56 −7%

Vas3.1 L −5%

BL5.2 T·m −19%

Xmax1.5 mm −52%

Sensitivity85.1 dB −4.6

WavecorMR120BD04

No current price

Fs72 Hz −32%

Qts0.55 −8%

Vas3.2 L –

BL5.2 T·m −19%

Xmax1.5 mm −52%

Sensitivity85.1 dB −4.6

Dayton AudioCFC120-8

No current price

Fs60 Hz −43%

Qts0.56 −7%

Vas4.6 L +41%

BL5.1 T·m −20%

Xmax2.5 mm −19%

Sensitivity83.6 dB −6.1

WavecorWF120BD13

No current price

Fs59 Hz −44%

Qts0.47 −22%

Vas3.8 L +17%

BL5.3 T·m −17%

Xmax3 mm −3%

Sensitivity84 dB −5.7

WavecorWF120BD07

No current price

Fs72 Hz −33%

Qts0.51 −15%

Vas3.3 L –

BL5.5 T·m −14%

Xmax4 mm +29%

Sensitivity85.3 dB −4.4

Tang BandW4-2356

No current price

Fs70 Hz −34%

Qts0.45 −25%

Vas4.0 L +22%

BL4.9 T·m −23%

Xmax3 mm −3%

Sensitivity85.7 dB −4

Search similar

Tune the match

Choose the published values that matter to your design. Size stays matched to this driver.

Qts

Qes

Vas

Xmax
